User Manual for Range hood
Model Name: CXW-300-T2C
This product implements national standards:
GB 4706.1 2005
GB 4706.28 2008
GB 29539-2013
GB/T 17713-2011
Content
1. Safety Precautions Safety precautions.................................................. 2
2 . Important Information...........................................................................4
3. Product Information............................................................................... 4
4. Installation Instructions..........................................................................6
5.Instructions for operation..................................................................... 11
6. Maintenance..........................................................................................12
7 .Troubleshooting.................................................................................... 13
8. After-sales Service.................................................................................14
1
Advertisement
Related Manuals for Macro CXW-300-T2C
Summary of Contents for Macro CXW-300-T2C
-
Page 1: Table Of Contents
User Manual for Range hood Model Name: CXW-300-T2C This product implements national standards: GB 4706.1 2005 GB 4706.28 2008 GB 29539-2013 GB/T 17713-2011 Content 1. Safety Precautions Safety precautions..........2 2 . Important Information................4 3. Product Information................4 4. Installation Instructions................6 5.Instructions for operation.............. -
Page 2: Safety Precautions Safety Precautions
1. Safety Precautions Safety precautions. In order to avoid harm and property damage to users and other personnel, please carefully read the following important safety matters, please strictly abide by, and on the basis of full understanding of the content of the correct use. Before use, please read this manual carefully and use in strict accordance with the instructions. - Page 3 run, the after-sales service personnel shall explain the use method to the user while there is no abnormal phenomenon. If you need to clean the inside of the range hood, please contact Macro after-sales personnel for professional cleaning.
-
Page 4: Important Information
2 . Important Information If the range hood is not in use for a long time, remove the power plug from the socket. When installing a new range hood, if the accessories do not conform to the instructions, contact your local dealer or service center immediately. - Page 5 Main Technical Data Name of Product Range hood Product Model Number CXW-300-T2C Rated voltage 220V~ Rated frequency 50Hz Rated input power of main motor 300W Maximum lighting power Rated input power of the device 302W Power of cleaning 360W...
-
Page 6: Installation Instructions
4. Installation Instructions Installation precautions ★ Special note: Macro products must be installed and maintained by our authorized installation and maintenance service providers, otherwise we will not be responsible for the accidents caused by installation and maintenance. If your kitchen is under renovation, do not expose the range hood, because construction ... - Page 7 Name of main parts Preparing for Installation The surroundings The range hood should avoid being installed in too many doors and Windows, forming too much air convection, and affecting the effect of lampblack removal. Preparing Tools Before installing a range hood, prepare the following tools: 1.
- Page 8 Mounting size drawing Installation dimensions are shown in Figure 3.
- Page 9 Opening size of Cabinet or ceiling for chimney pipe The size of the cabinet or ceiling smoke pipe is shown in Figure 4. Installation Procedure Mounting plate As shown in Figure 5, accurately determine the mounting holes for the hanging plate at corresponding positions on the wall, drill the mounting holes in the holes with a drill bit, firmly bury the plastic expansion tube, and then tighten the wooden screws.
- Page 10 Installing a chimney pipe Insert the pipe into the check valve as shown in Figure 7, then lock it with the self-tapping screw and wrap it with the aluminum foil. Mounting the body Lift the whole machine as shown in Figure 8. The mounting holes on the back of the box are aligned with the hooks on the mounting plate.
-
Page 11: Instructions For Operation
Installation Confirmation After the installation is complete, check whether the range hood is firm, switch on the power supply for the trial operation of the range hood, check whether the functions of the range hood are normal and whether the body has abnormal vibration, and then use it after confirming that it is correct. -
Page 12: Maintenance
6. Maintenance Warning: In order to give full play to the best performance of the range hood and extend its service life, you should pay attention to regular maintenance, which must be carried out by professionals. Precautions When the range hood is running, do not put your hands into the operating area of the range ... -
Page 13: Troubleshooting
7 .Troubleshooting How to handle exceptions Note: Non-technical personnel do not disassemble and repair Common Faults Cause of failure Treatment Method No power supply at home； Wait for the power supply to work in Poor contact between plug and your home and try again, The motor does not run socket Have it checked by a professional... -
Page 14: After-Sales Service
8. After-sales Service If your range hood does not work normally, please contact the special maintenance department designated by the company or the service center in each region of the company. We will serve you warmly. Thank you for your cooperation! Attached: Electrical schematic diagram (circuit subject to change without notice!)
