INSTALLATION GUIDE
Waterbridge Remote Tub Drain & Overflow
WB-RTDO
Feb 2014
General Theory of Operation: The WB-RTDO is basically a tube within a tube. The Control Knob
on top of the RTDO controls whether water fills the tub or allows the water to drain. When the knob is
in the "down" position (turn the knob until it slides down) the drain is "closed" allowing the tub to fill.
As the water fills the tub, it also fills the outer tube of the RTDO. The tub will fill until it reaches the
overflow level set when the RTDO was installed. Excess water entering the tub will then begin to
"overflow" into the inner tube of the RTDO, and down the drain. To drain the tub, simply lift and turn
the Control Knob until it rests in the up (or open) position.
|
|
