G3441/G3641/G3941
G3441R/G3641R/G3941R
G3641FR/G3941FR Griddles
INSTALLATION and
SERVICING INSTRUCTIONS
This appliance must be installed and serviced by a competent person as stipulated by the Gas
Safety (Installation & Use) Regulations.
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions and
National Regulations in force at the time of installation. Particular attention MUST be paid to:
Gas Safety (Installation & Use) Regulations
Health And Safety At Work etc. Act
Local and National Building Regulations
Fire Precautions Act
These appliances have been UKCA/CE-marked based on compliance with the Gas Appliance
Regulations/Product Safety and Metrology Regulations for the Countries, Gas Types and Pressures as
stated on the data plate.
WARNING
On completion of the installation, these instructions should be left with the Engineer-in-Charge for
reference during servicing. Further to this, The Users Instructions should be handed over to the User,
having had a demonstration of the operation and cleaning of the Appliance.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING
AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED
PROCEDURES MAY RESULT IN DAMAGE OR THE NEED FOR A SERVICE CALL.
PREVENTATIVE MAINTENANCE CONTRACT
To obtain maximum performance from this unit regular servicing of the appliance should be undertaken to
ensure correct operation, it is functioning as intended, and safe to use. We recommend servicing in
accordance with SFG20 Maintenance Schedules and as a minimum, after 2,500 hours of use, or annually,
whichever comes
first and
may then be made at agreed intervals to carry out adjustments and repairs.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement
parts in a safe manner, via a licensed waste handler.
Units are designed to be dismantled easily and recycling
of all material is encouraged whenever practicable.
Falcon Foodservice Equipment
HEAD OFFICE AND WORKS
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
Phone: 01786 455200
1
TO PREVENT SHOCKS, ALL APPLIANCES WHETHER
:
GAS OR ELECTRIC, MUST BE EARTHED.
that a maintenance contract be arranged with an appointed service contact. Visits
Detailed recommendations are contained in Institute
of Gas Engineers published documents:
IGE/UP1, IGE/UP/2
BS6173 and BS5440
T100765 Ref. 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dominator Plus G3441 and is the answer not in the manual?

Questions and answers

Related Manuals for Falcon Dominator Plus G3441

Summary of Contents for Falcon Dominator Plus G3441

  • Page 1 Units are designed to be dismantled easily and recycling of all material is encouraged whenever practicable. Falcon Foodservice Equipment HEAD OFFICE AND WORKS T100765 Ref. 10 Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.

  • Page 2: Section 1 - Installation

    SITING The appliance may be installed on a non-combustible surface, counter top, or alternatively on the purpose made stand supplied by Falcon. Installation should be made in accordance with local and/ or national regulations applying at the time. A competent installer MUST be employed.
  • Page 3 HEAT INPUTS There is a single burner on a G3441, two burners on a G3641 and three on a G3941. Model kW (net) Btu/hr (gross) G3441 19,900 G3641 41,300 G3941 16.5 62,000 INJECTOR SIZES Main Burner Model Natural Gas Propane Gas G3441 Ø1.95mm Amal 190...

  • Page 4: Section 2 - Assembly And Commissioning

    SECTION 2 - ASSEMBLY and COMMISSIONING ASSEMBLY 2.1.1 Unpacking Remove any packing material etc. and ensure that burners are correctly located over injectors and located properly at rear. 2.1.2 Positioning Position unit and level using feet adjusters. If it is to be mounted on a purpose floor stand, refer to instructions supplied with stand.

  • Page 5: Section 3 - Servicing And Conversion

    1. Model number – found on data plate 2. Serial number – found on data plate 3. Brief description of the issue To contact Falcon for a warranty issue dial (UK only) 01786 455 200 and select Warranty Issues from the menu. MAINTENANCE CHECK Regular servicing of the appliance should be undertaken to ensure correct operation, it is functioning as intended, and safe to use.
  • Page 6 GAS CONVERSION For conversion to NATURAL GAS, add correct governor and set burner pressure. For conversion to PROPANE GAS, remove governor from gas circuit. Conversion kits with full fitting instructions are available upon request. Other considerations CHANGE INJECTORS CHANGE BY-PASS SCREW CHANGE BURNER AERATION SETTING (3641/3941) CHANGE BURNER AERATION SETTING (3441) Refer to Section 2.5.2.
  • Page 7 THERMOCOUPLE To remove proceed as follows:- a) Remove control panel as detailed in Section 3.1.1. b) Undo tubing nut at pilot assembly and gas control. c) Maneuver thermocouple clear. d) Replace in reverse order. When fitting a replacement thermocouple, coil excess in a similar manner to original and take care not to bend capillary to less than 12mm radius.

  • Page 8: Section 4 - Spare Parts

    SECTION 4 - SPARE PARTS When ordering spares, always quote the appliance type and serial number. This information will be found on the data plate.
