xcore-200 Evaluation Kit (XK-EVK-XE216) Hardware Manual
Publication Date: 2024/4/10
Document Number: XM007647A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XK-EVK-XE216 and is the answer not in the manual?

Questions and answers

Summary of Contents for XMOS XK-EVK-XE216

  • Page 1 Evaluation Kit (XK-EVK-XE216) Hardware Manual Publication Date: 2024/4/10 Document Number: XM007647A...
  • Page 2 RoHS and REACH xCORE-200 evaluation kit is an evaluation board for the configurable xCORE-200 multicore microcontroller products from XMOS. It’s easy to use and provides lots of advanced features on a small, extremely low cost platform. xCORE lets you software-configure the interfaces that you need for your system; so with xCORE-200 evaluation kit you can configure the board to match your exact requirements.
  • Page 3 Evaluation Kit (XK-EVK-XE216) Hardware Manual 1 Features A block diagram of the xCORE-200 evaluation kit is shown below: Figure 1: xCORE-200 evaluation kit block diagram It includes the following features: A: xCORE-200 (XE216-512-TQ128) Multicore Microcontroller device B: 32 GPIO connections from tile 0, arranged on a 0.1” grid C: 21 GPIO connections from tile 1, arranged on a 0.1”...
  • Page 4 Evaluation Kit (XK-EVK-XE216) Hardware Manual N: A general purpose RGB LED O: A QSPI flash P: A green 3.3v power-good LED Q, R: Two power supply headers S: 24MHz Oscillator 2 xCORE Multicore Microcontroller Device xCORE-200 evaluation kit is based on a two-tile xCORE-200 device (XE216-512-TQ128).
  • Page 5 Evaluation Kit (XK-EVK-XE216) Hardware Manual 3 GPIO headers (J1 & J3) J1 and J3 provide a rich set of IO that can be readily connected to off-board components. Figure 3: GPIO connectors The xCORE ports are mapped to the GPIO connector pins as shown in Figure...
  • Page 6 Evaluation Kit (XK-EVK-XE216) Hardware Manual Signal Port GPIO J1 Signal GPIO J1 X0D31 P4F3 X0D30 P4F2 X0D29 P4F1 X0D28 P4F0 X0D33 P4E3 X0D32 P4E2 X0D27 P4E1 X0D26 P4E0 X0D35 X0D34 X0D25 X0D24 X0D19 P4D3 X0D18 P4D2 X0D17 P4D1 X0D16...
  • Page 7: Usb Connections

    Evaluation Kit (XK-EVK-XE216) Hardware Manual Signal GPIO J3 Signal Port GPIO J3 X1D35 X1D38 X1D39 X1D16 P4D0 X1D17 P4D1 X1D18 P4D2 X1D19 P4D3 X1D14 P4C0 X1D15 P4C1 X1D20 P4C2 X1D21 P4C3 X1D04 P4B0 X1D05 P4B1 X1D06 P4B2 X1D07 P4B3...
  • Page 8 The xSYS connector is provided to interface to an xTAG debug adapter. The xTAG debug adapter (included in the XK-EVK-XE216 kit) allows the XTC tools to interrogate the applica- tion running on the xCORE-200 device using the XMOS debugger and the xSCOPE library which provides non-intrusive program instrumentation.
  • Page 9: Servo Connectors

    Evaluation Kit (XK-EVK-XE216) Hardware Manual Figure 9: General Port BUTTON purpose X0D26 P4E0 push-button switches X0D27 P4E1 8 Servo connectors Up to six servos can be connected to the xCORE-200 evaluation kit using the header sockets provided. Note that it is up to the user to ensure that sufficient supply power is available to drive the servos.
  • Page 10: Qspi Flash

    Evaluation Kit (XK-EVK-XE216) Hardware Manual The green LED and each colour terminal of the RGB LED are connected to a different pin as described in Figure 13: Port X0D28 P4F0 Green X0D29 P4F1 RGB (blue term) X0D30 P4F2 RGB (green term)
  • Page 11: Operating Requirements

    13 Operating requirements A USB 2.0 high-speed compliant cable of less than 3m in length should be used when operating the xCORE-200 evaluation kit. XMOS cannot guarantee correct operation of the xCORE-200 evaluation kit should any other cable be used.
  • Page 12 Evaluation Kit (XK-EVK-XE216) Hardware Manual 15 xCORE-200 evaluation kit Portmap The table below provides a full description of the port-pin mappings described throughout this document. link 1-bit 4-bit 8-bit 16-bit 32-bit GPIO BUTTON uplink RGMII 1A 0 X0D00 MISO...
  • Page 13 Evaluation Kit (XK-EVK-XE216) Hardware Manual link 1-bit 4-bit 8-bit 16-bit 32-bit GPIO BUTTON uplink RGMII H 2 in 1A 0 J3 40 X1D00 H 1 in 1B 0 J3 42 X1D01 E 0 in 4A 0 8A 0 16A 0...
  • Page 14 Xmos Ltd. is the owner or licensee of this design, code, or Information (collectively, the “Information”) and is providing it to you “AS IS” with no warranty of any kind, express or implied and shall have no liability in relation to its use. Xmos Ltd.
