Wallace Pumps 10BTWINUV55 Installation, Maintenance & Service Instructions

G:\INSTRUCT\FILTRATION\Instruction manual for TWIN Water Filters + UV systems R1.docx 23/07/2021 page no 1
TWIN 10" & 20"JUMBO WATER FILTERS
COMPLETE WITH UV SYSTEMS.
Model nos. "10BTWINUV55", "10BTWINUV90" and
INSTALLATION, MAINTENANCE & SERVICING MANUAL
PLEASE READ ALL INSTRUCTIONS PRIOR TO PROCEEDING WITH ANY WORK
These are TWIN 10" and 20" Jumbo Water filter packages complete with UV systems, mainly designed
for treating rainwater. System for treating mains water is available with appropriate filter cartridges.
These units includes Twin Filter housing of size ordered includes 1 X 20µ Pleated and 1 X 1µ Poly-Spun
PP Filter cartridges and complete UV55 OR UV90 ultraviolet system as per order.
Before deciding to install the product, you must consult with your local respective authorities for
regulations and any approval / permit that may need to be obtain before installation.
AFTER INSTALLATION, THE INSTALLER MUST HAND THIS MANUAL TO THE OWNER
FOR THE PROPER OPERATION AND MAINTENANCE OF THE UNIT
Failure to do so will result in the installer being made liable under the current legislation for any future
claims resulting from any malfunction of unit &/or damage to property or person.
Congratulations on your purchase of 10" or 20" TWIN Jumbo water filter package complete with UV
system. For this product to meet its expected lifetime please ensure it is installed by a qualified
technician and follow these installation, servicing and maintenance instructions. For maintenance
schedule refer "Section 8" "Care & Servicing of Unit". Please keep a record of by whom and when the
maintenance /replacement was completed, that need to be provided to when asked for.
TWIN 10" JUMBO FILTERS
WITH UV55 PACKAGE
OR
TWIN 10" JUMBO FILTERS
WITH UV90 PACKAGE
PAGE INDEX
Section
1: Caution and warnings........................................................2
2: Design features, Technical details, Dimensions......2 & 3
3: List of items supplied & to be by arranged by others...4
4: Instructions for new installation..............................5 to 9
5: Guide for filter cartridge & UV use & limitations.9 & 10
Limitations: Wallace Pumps reserve the right to change these instructions & improve the product without prior notice.
AUCKLAND
PH 09 622 9100
"20BTWINUV90"
Please ask Wallace pumps.
WITH TRUE REVERSIBLE
SS MOUNTING BRACKET DESIGN
Page no Section
WELLINGTON
PH 027 543 8634
TWIN 20" JUMBO FILTERS
WITH UV90 PACKAGE
6: Instructions for replacing filter & UV lamp..10 & 11
7: Protection against water flooding & damage.......11
8: Care and servicing of unit........................................12
9: Warranty and limitations...............................12 & 13
CHRISTCHURCH
PH 027 532 9754
Page no
