- Page 1 User Manual ® ROLENCE ULTRASONIC SCALER (Piezo) ® ELiTEDENT PS-1/PS-1(LED) ROLENCE ENTERPRISE INC. No. 18-3, Lane 231, Pu Chung Rd., Chungli, Taoyuan 32083, Taiwan TEL: 886-3-4631999 FAX: 886-3-4631997 www.rolence.com.tw S-19-01-1204-U0001 V1.7...
-
Page 2: Table Of Contents
Table Of Contents Section Section Title Page Number Description of Contents Number Safety Precautions…………………………………………………………………………………..3 Introduction…………………………………………………………………………………………..4 Application………………………………………………………………………………………………4 Specification…………………………………………………………………………………………...4 Contraindications and Warnings…………………………………………………………………5 5.1 Contraindications 5.2 Warnings Infection Control……………………………………………………………………………………….5 6.1 General Infection Control Recommendations 6.2 Water Supply Recommendations Installation Instructions……………………………………………………………………………6 7.1 General Information 7.2 Water Line Requirements 7.3 Electrical Requirements 7.4 Unpacking the System... -
Page 3: Safety Precautions
Section 1: Safety Precautions Prior to installation and start-up of the ultrasonic scaler, carefully read the instructions provided herein! 1.1 Precautions for All Systems Do not place the ultrasonic scaler on or next to a radiator or other heat source. Excessive heat may damage the ultrasonic scaler’s electronics. -
Page 4: Introduction
Section 2: Introduction Rolence Enterprise Inc. is an ISO 9001, ISO 13485 2.2 Supplies and Replacement Parts certified manufacturer of Ultrasonic Scalers. All the Contact your local Rolence dealer to order supplies products are FDA registered and compliant with EN or replacement parts. -
Page 5: Contraindications And Warnings
Section 5: Contraindications and Warnings 5.1 Contraindications ® ‧ Ultrasonic Systems should not be used for Remark: EMS is the registered trademark of the restorative dental procedures involving the Electro Medical Systems. condensation of amalgam or porcelain. 5.2 Warnings ‧ This device is designed to work with ultrasonic ‧... -
Page 6: Installation Instructions
Section 7: Installation Instructions 4. Autoclavable Handpiece 7.1 General Information 5. Ultrasonic tips and torque wrench. ® If the installation of your ELiTEDENT ultrasonic 6. User Direction Manual. scaler is performed by someone other than 7.5 System Installation ® trained Rolence distributor personnel, care should ‧... -
Page 7: System Controls
® Section 8: ELiTEDENT Ultrasonic Scaler Description 8.1 System Controls – Rear Panel Handpiece tubing outlet Power Socket Solenoid Water Inlet Handpiece Holder Securely holds the Foot Pedal Connector Handpiece when system Connect foot switch here, is not being used. ensure it is firmly seated. -
Page 8: Installation Of Handpiece And Ultrasonic Tips
8.2 Installation of Handpiece and ultrasonic Tips ® The ultrasonic scaler is designed working with all EMS tips. The system will automatically track the working frequency by microcomputer inside, no need to switch any button. Use torque wrench to mount ultrasonic Tips onto the appropriate handpiece gently. Note: The tip must be screwed and moderately tightened. -
Page 9: Use Of Tips
8.4 Use of Tips ® ® The ultrasonic Tips is for use in dentistry with Rolence ELiTEDENT Ultrasonic scaler. Rolence offers 5 different kinds of ultrasonic Tips. The longer and thinner Tips is, the better becomes its access to periodontal pockets and inter-proximal areas. Also, at a constant power setting on the unit, a longer and thinner Tips delivers less clinical power. - Page 10 Tips A Tips A is used for general supragingival deposit removal on all tooth surfaces in all quadrants. Tip A Tips C Tips C is designed for the removal of heavy deposits on anterior teeth. It can also be used for the removal of orthodontic cements.
-
Page 11: Accessories
Tips PS Tips PS is for general subgingival de-posit removal on all root surfaces and can also be used for supragingival maintenance therapy. It is suitable as well for periodontal pocket irrigation with antimicrobial delivery. Tip PS 8.5 Scaling tip worn out When is a scaling tip worn out? The shape and mass of the individual tips are determining characteristics for achieving maximum ultrasonic generator efficiency. -
Page 12: Scaling Tip Worn Out
Section 10: Techniques For Use 10.1 Patient Positioning ‧ In general, it is suggested a "feather-light-touch" be used both supra and subgingivally. The motion ‧ For optimal access to both the upper and lower of the activated tip and acoustic effects of the arches, the backrest of the chair should be irrigating fluid, in most cases, is adequate to adjusted to a 45∘... -
Page 13: System Maintenance And Care
Section 11: System Maintenance and Care Daily Maintenance for 30 seconds. It is recommended that you perform the following 4. When ready, place a sterilized Tips into the maintenance procedures to help minimize bio-film handpiece. ® 5. The handpiece can be autoclaved up to 135℃.. formation in the water path of your ELiTEDENT ultrasonic scaler which could affect the water flow to the ultrasonic tips, and scaling performance. -
Page 14: Trouble Shooting
Section 12: Trouble shooting ® Although service and repair of the ELiTEDENT (Power Indicator Light is lit.) PS-1/PS-1(LED) Ultrasonic Scaler should be 1. Check that the Foot Pedal Connector is fully performed by ROLENCE dealer personnel, the seated in the Foot Pedal Receptacle on the back of following are some basic trouble shooting the System. -
Page 15: Disposable Of Unit
Section 14: Disposal of Unit ® ‧ Keep original packaging until the ELiTEDENT Ultrasonic Scaler is to be disposed of permanently. You can ® use it for shipping or storing your ELiTEDENT Ultrasonic Scaler at any time. ® ‧ Dispose of the ELiTEDENT Ultrasonic Scaler in accordance with local and national laws. -
Page 16: Glossary Of Symbols
Section 17: Glossary of Symbols Attention, Consult accompanying Documents Alternating Current Power off Power on Manufacturer Type BF Applied Part; Type BF Equipment - Protection against electric shock Equipment class: Class II (IEC601-1) - double insulated The equipment complies with the requirements in the Medical Device Directive 93/42 EEC.
