INSTRUCTION MANUAL
Electric Stove
This product is only suitable for well insulated
This manual is for the following models:
HS93383
IMPORTANT
The fan will run for approximately 15 seconds after the heater is
turned off. This is to remove any residual heat from the stove to
prevent any potential overheating.
spaces or occasional use.
HS93384CR
www.firedupcorporation.com/manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fired Up Corporation HS93383
Summary of Contents for Fired Up Corporation HS93383
- Page 1 Electric Stove This product is only suitable for well insulated spaces or occasional use. This manual is for the following models: HS93383 HS93384CR IMPORTANT The fan will run for approximately 15 seconds after the heater is turned off. This is to remove any residual heat from the stove to prevent any potential overheating.
-
Page 2: Table Of Contents
Read ALL the instructions before use. These instructions are for your safety. Please read through them thoroughly before use and retain for future reference. Failure to follow them could cause injury and/or property damage. CONTENTS SECTION 01 Cautions 03-06 Introduction Handling SECTION 02 Unpacking &... -
Page 3: Cautions
CAUTIONS DO’S • Read ALL the instructions before using this product. • Only use this product for its intended use as described in this manual. • Always use the product in accordance with this guide. If in doubt obtain expert advice. •... - Page 4 • Never use aerosols or steam cleaners on or around the stove. • Never route the supply cord under carpeting and never cover the cord with throw rugs, runners, etc. Arrange the cord away from traffic areas and where it will not be tripped over.
- Page 5 IMPORTANT! • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 6 • CAUTION — Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present. • This heater is hot when in use. To avoid burns, do not touch hot surfaces such as surfaces around the grille in front of the heater.
-
Page 7: Introduction
INTRODUCTION Thank you for choosing this product. It is designed to meet the most stringent quality, performance, and safety requirements. This guide aims to improve your understand- ing and appreciation of your new product by providing simple and informative instructions. HANDLING Before continuing any further with the installation of this product please read the following:... -
Page 8: Product Dimensions
PRODUCT DIMENSIONS HS93383 HS93384CR... -
Page 9: Parts Supplied
INSTALLATION PARTS SUPPLIED Remote Control 2 x Batteries 6x Logs Vermiculite Crystals Natural Grey Slate Positioning the product The following considerations should be given when positioning the product: Ensure the product is positioned on a flat, even surface. Allow clearance of at least 900mm from the front of the stove to combustible matierals. -
Page 10: Arranging The Fuel Bed
Arranging the fuel bed Arrange the fuel bed and logs as shown, using the numbers shown underneath each log. Vermiculite Crystals Slate Control panel The control panel can be located as shown. *Image for illustrative purposes only Digital Display Power Heater Temp- Temp+... -
Page 11: Operation
Remote control Temperature Up Power Temperature Down Flame Brightness Heater Fuel Bed Brightness Timer Mode Time Setting OPERATION - Manual On/Off switch must be switched on for the stove to work. The switch is in the ON position when the side with the ‘I’ marking is ‘pressed in’ The brightness setting cannot be changed without the remote control. - Page 12 Powering the stove Press the power button to turn the stove on. The room temperature will be displayed and the functions can be used. Note: This stove has a memory function, the stove will turn on to the last heat setting when the power button is pressed Turn on heater...
- Page 13 Fuel bed brightness settings The brightness of the flame can be changed between three settings using the brightness button . The chosen setting will be shown on the display. - Highest setting - Medium - Lowest setting Note: The brightness setting cannot be changed without the remote.
- Page 14 Set day & time To show the day and time, press and hold the time setting button for 2 secs. Press the time setting button again to set the DAY. The DAY will flash on the display. Select the day using the + or - buttons. Press the time setting button again and the HOUR will flash.
- Page 15 Set timers The timer setting allows for two ON/OFF periods (M1 and M2) to be set for each day of the week. Press and hold the timer mode button for 2 secs. to begin setting the timer. The setting for the 1st period ON time (M1) for Monday will be shown.
-
Page 16: Additional Features
ADDIONAL FEATURES Open Window/Door Detection - If the heater is turned on and the ambient room temperature drops, the heater automatically turns off (and ECO is shown on the display). The heater can be turned back on using the heater button PLUG REPLACEMENT (for products fitted with BS plug) This appliance is supplied with a BS1363 3 pin plug fitted with a 13 Amp fuse. -
Page 17: Technical Parameters
TECHNICAL PARAMETERS L 193/88 Official Journal of the European Union 21.7.2015 Table 2 Information requirements for electric local space heaters Model identifier(s): EFS0043 Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only (select one) Nominal heat out... -
Page 18: Troubleshooting
TROUBLESHOOTING The fire does not switch on: • Check the mains supply if it is safe to do so. • Check the fuse in the plug. • Check the on/off switch is “On” and a red light behind the screen illuminates •... -
Page 19: Specification, Conformity & Environment
SPECIFICATION HS93383 HS93384CR Supply Voltage 220-240V~50Hz 220-240V~50Hz Rated Power 1700-2000W 1700-2000W Fuse Rating 13 Amp 13 Amp CONFORMITY WITH DIRECTIVES Conforms with relevant European Directives ENVIRONMENTAL PROTECTION • (WEEE) Waste Electrical and Electronic Equipment Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. -
Page 20: Guarantee & Contacts
This product guarantee does not affect your statutory rights. CUSTOMER HELPLINE +44 (0) 3300 882 069 customer.support@firedupcorporation.com Fired Up Corporation Ltd Fired Up Buildings HD1 3LF, UK www.firedupcorporation.com Fired Up Corporation (Ireland) Ltd...
