Party Tents Direct High Peak Frame Assembly Instructions Manual

Weekender tent
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
16´-9˝
8´
20´
20´
HIGH PEAK FRAME
(
)
WEEKENDER
20´ x 20´
A S S E M B L Y I N S T R U C T I O N S

Advertisement

loading
Need help?

Need help?

Do you have a question about the High Peak Frame and is the answer not in the manual?

Questions and answers

Related Manuals for Party Tents Direct High Peak Frame

Summary of Contents for Party Tents Direct High Peak Frame

  • Page 1 16´-9˝ 8´ 20´ 20´ HIGH PEAK FRAME WEEKENDER 20´ x 20´ A S S E M B L Y I N S T R U C T I O N S...
  • Page 2 PARTYTENTSDIRECT.COM (716) 566-5804 High Peak Frame- Weekender Tent (OVERVIEW) Recommended Tools: • hard hat • sledge hammer • tape measure • work boots • 6 ft ladder Canopy Center Pole Center Pole Crown Hip Rafter Parts 1 & 5 Ratchet Spreader Parts 2 &...
  • Page 3 PARTYTENTSDIRECT.COM (716) 566-5804 STEP 1. CHECK ITEM LIST (20´x 20´ HPF-Weekender Tent) Item Part # Illustration (all parts available for replacement) Quantity HIP RAFTER SKU: BT-FHEP1 SPREADER SKU: BT-FHEP2 SPREADER SKU: BT-FHEP3 BOTTOM LEG SKU: BT-FHEP4 HIP RAFTER SKU: BT-FHEP5 CENTER POLE SKU: BT-FHEP6 CORNER FITTINGS...

  • Page 4: Step 2. Assemble Frame

    PARTYTENTSDIRECT.COM (716) 566-5804 STEP 2. ASSEMBLE FRAME Center Pole Crown Hip Rafter Parts 1 & 5 Spreader Parts 2 & 3 Corner Fitting • Locate tent position, spread out parts in this area (see illustration) • Start connecting the parts—first #2, #3 and #7, outside Spreaders and Corner Fittings •...
  • Page 5 PARTYTENTSDIRECT.COM (716) 566-5804 STEP 4. CENTER POLE and LEGS Center Pole Upper Legs Center Pole Crown • Lift one corner of completed frame insert first and then second Leg (top) • Put Center Pole in position and make contact with peak of Canopy— Turn Crown crank as needed, counter clockwise (Double Check this at the end of assembly) STEP 5.
  • Page 6 PARTYTENTSDIRECT.COM (716) 566-5804 STEP 6. BOTTOM LEGS and BASE PLATES Lower Legs (with extra hole) Base Plates • Connect the Lower Legs to Upper Legs (using nuts & bolts)—and connect the Base Plates STEP 7. ANCHOR STRAPS Long Ratchet Straps Anchor Stakes Small Ratchet •...
