- Page 1 Multi-port RS-232 to Ethernet Data Gateway Model Number: MSD-SRF4X Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/09/2024...
- Page 2 Thank you for purchasing Coolgear’s Multi-port RS-232 to Ethernet Data Gateway. The MSD-SRF4X 4 port RS-232 to Ethernet data gateway will address the need to add 2 RS-232C devices to an IP-based Ethernet LAN on your system, and has a built-in watchdog function for hardware hangs.
- Page 3 – Installation Guide Multi-port RS-232 to Ethernet Data Gatewa 2. Connector Layout Need help? Visit: coolgear.com/support...
- Page 4 4. Connect the data gateway’s serial ports to your serial devices. 5. Use the wall mounting Kit if you want to place the data gateway on the wall. Need help? Visit: coolgear.com/support...
- Page 5 To run the Em.exe utility, please insert the driver CD supplied with the data gateway. Open (double click) the program at the following location (assume the CD-ROM drive is at E) E:\Utility\82500\Em.exe Need help? Visit: coolgear.com/support...
- Page 6 When you enter the Setup Menu of the data gateway, the following page will be available for your access. Please click the Update button after you change your settings. Please also remember your password because you need it when you are going to enter this setup menu next time. Need help? Visit: coolgear.com/support...
- Page 7 5. Male Db9 Pin Assignments and Cable Wiring 6. Environmental Information Power requirements: 5V DC, 250mA (max) Operating temp.: 0 to 55 (32 to 131 ° ° Operating humidity: 5 to 95% RH Dimensions (LxWxH): 5.90”(L)x2.61”(W)x1.02”(H) (15.00 x 6.65 x 2.60 cm Need help? Visit: coolgear.com/support...
- Page 8 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 9 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
