THANKS FOR
REMEMBERING
INSTRUCTION MANUAL
SPECIFICATIONS
Model
Diameter
Capacity
PACKING LIST
Components
Movable Pedal (4)
Accessories
Multipurpose Wrenches (2)
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
V. 2024.02.28
3-INCH RETRACTABLE
WORKBENCH CASTERS (4-PACK)
CA3060
3 Inches
Combined: 880 Pounds (Evenly Distributed)
Individual: 220 Pounds
Casters (4)
Leg Mounting Plate (4)
Hardware
M6x60 Hex Bolt (4)
M6x52 Hex Bolt (4)
NEED HELP? CONTACT US!
TECHSUPPORT@WENPRODUCTS.COM
MODEL CA3060
Wheel Mounting Plate (4)
M12 Hex Nut (4)
M6 Hex Nut (8)
M5x25 Screw (24)
Advertisement
Related Manuals for Wen CA3060
Summary of Contents for Wen CA3060
- Page 1 INSTRUCTION MANUAL MODEL CA3060 3-INCH RETRACTABLE WORKBENCH CASTERS (4-PACK) SPECIFICATIONS Model CA3060 Diameter 3 Inches Combined: 880 Pounds (Evenly Distributed) Capacity Individual: 220 Pounds PACKING LIST Components THANKS FOR REMEMBERING Movable Pedal (4) Casters (4) Leg Mounting Plate (4) Wheel Mounting Plate (4)
- Page 2 INSTRUCTION MANUAL ASSEMBLY & ADJUSTMENTS Fig. 3 1.9 in. ASSEMBLING THE CASTERS 1. Secure the movable pedal, leg mounting plate, and wheel mounting plate together using one M6x60 hex bolt (Fig. 1 - 1) and one M6 hex nut (Fig. 1 - 2) through the lower holes (A), and one M6x52 hex bolt (Fig. 1 - 3) and one M6 hex nut (Fig.
