- Page 1 Installation Guide Turret IPC & PoE+ NVR KIT...
-
Page 3: Table Of Contents
Contents Chapter 1 Hardware Overview ——————— 1 Chapter 2 Installation ——————————— 4 Mount the Camera ..........4 Installl the NVR ............6 Safety Precautions ..........7 Installation Tools ...........9 Hard Drive Installation ........9 Product Installation ..........12 Chapter 3 Hardware Connection —————— 14 Chapter 4 Configuration —————————— 15 Appendix FAQ ———————————————... -
Page 4: Chapter 1 Hardware Overview
*The camera’s standard power supply is 12V DC or PoE (802.3af/at). The power source should comply with Power Source Class 2 ( PS2) or Limited Power Source(LPS) of IEC 62368-1. *Some models do not have the power supply interface. You can check the detailed specifications on the product page at https://www.tp-link.com/. VIGI NVR2016H-16MP ■... - Page 5 Indication On: System is running normally. Off: System is running abnormally. On: Network is working properly. Flashing: Data is being transmitted or received. Off: Network is malfunctioning. On: The HDD is normal. Off: No HDD or the HDD is malfunctioning. On: The total PoE power reaches the warning threshold.
- Page 6 eSATA Connect to external hard drive. HDMI® Output port for high-definition audio and video signals. Connect your monitor to this port if it uses HDMI connection. Output port for analog video signals. Connect your monitor to this port if it uses VGA connection. Audio Input/Output Connector for audio input and output.
-
Page 7: Chapter 2 Installation
Chapter 2 Installation Mount the Camera Prepare the camera and the mounting accessories. Φ6 mm Φ3.5 mm Network Camera Anchors & Screws Mounting Waterproof Cable Waterproof L-shaped Hex Metal Template Attachments Seal Screwdriver 1. Stick the mounting template to the desired mounting place. Drill 4 screw holes and 1 cable hole (for the cable through wall/ceiling) according to the template. - Page 8 3. Insert anchors into the holes and use screws to affix the camera base. Identify the groove and alignment ridge on the camera. Begin by aligning the base's rim with the camera's groove, attaching the ridge side first for a correct fit. Once aligned, proceed to snap the rest of the camera onto the base to secure it.
-
Page 9: Installl The Nvr
Fix Nut Waterproof Waterproof Network O-ring Jacket Interface Ring 1. Route the network cable through the following components in order: fix nut, waterproof ring, and then the waterproof jacket. 2. Fix the O-ring to the network interface of the camera and connect the network cables. -
Page 10: Safety Precautions
Safety Precautions To avoid any device damage and bodily injury caused by improper use, you should observe the following rules. Safety Precautions ■ Keep the power off during the installation. ■ Wear an ESD-preventive wrist strap, and make sure that the wrist strap ■... - Page 11 The dust accumulated on the device can be absorbed by static electricity and result in poor contact of metal contact points. Some measures have been taken for the device to prevent static electricity, but too strong static electricity can cause deadly damage to the electronic elements on the internal circuit board.
-
Page 12: Installation Tools
Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, go to https://www.tp-link.com/ support, search the model number of your product and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/. - Page 13 also follow the steps below to reinstall the HDD. 1. Remove the fixing screws on the side and back panels to open the cover of the NVR. 2. Choose the right size to install hard disk drive (HDD). Both 3.5-inch HDD and 2.5-inch HDD are supported.
- Page 14 4. Connect one end of the power cable and data cable to the hard drive, and the other end to the NVR. 5. Replace the cover and fasten the screws of the NVR.
-
Page 15: Product Installation
Product Installation Desktop Installation ■ To install the device on the desktop, follow the steps: 1. Set the device on a flat surface which is strong enough to support the entire weight of the device with all fittings. 2. Remove the adhesive backing papers from the rubber feet. 3. - Page 16 3. After the brackets are attached to the device, use suitable screws (not provided) to secure the brackets to the rack, as illustrated in the following figure.
-
Page 17: Chapter 3 Hardware Connection
Chapter 3 Hardware Connection Follow the steps below to complete the hardware connection. Mouse PoE Cameras Network Device (e.g. Router, Switch) Monitor 1. Connect your monitor to the HDMI or VGA port according to the connection port it supports. 2. Connect your monitor to a power source and turn it on. 3. -
Page 18: Chapter 4 Configuration
If you want to add cameras manullay and change the settings, click Go To Manually Initialize to manually add cameras in your network and complete the setup. (Optional) 4. Click Bind TP-Link ID to bind your NVR to a TP-Link ID for remote access and management. Note: Make sure your NVR can get access to the internet before binding. - Page 19 Remotely view live video, manage NVR, and get instant alerts. 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add your NVR.
- Page 20 4. Try to add your cameras manually. 5. For other NVR brands, make sure you have activated the camera by setting a password via the VIGI Security Manager, TP-Link VIGI app or web management page. Q3. What can I do if my NVR fails to connect to the Internet? 1.
- Page 21 Safety Information For NVR This device is restricted to indoor use only. • Keep the device away from water, fire, humidity or hot environments. • Do not attempt to disassemble, repair, or modify the device. • Do not use damaged charger or USB cable to charge the device. •...
- Page 22 • Keep the device away from fire or hot environments. DO NOT immerse in water or any other liquid. EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.
- Page 23 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
- Page 24 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2024 TP-Link 7106511008 REV1.0.1...
