- Page 1 User Manual PM11- HF01 & HF03 Online UPS 17 Honeydew Business Park, 1503 Citrus Street, Laser Park Honeydew Tel: 0861 444 445 Email: sales@powerman.co.za Web: www.powerman.co.za...
-
Page 2: Important Safety Instructions
Clean the UPS with a dry cloth. Do not use liquid or aerosol cleaners. Never block or insert any objects into the ventilation holes or other openings of the UPS. Do not place the UPS power cord where it might be damaged. PowerMan Online 1-3k UPS User Manual... -
Page 3: Table Of Contents
5.2.3 Rack Installation ....................12 5.3 Operating procedure for connecting the long backup time model UPS with the external .......................13 battery 6. Controls and Indicators ...................... 15 ..............15 6.1 Operation and Display Panel PowerMan Online 1KVA & 3KVA User Manual... -
Page 4: Contents
10.2 Adjust the factors caused the problem Annex A. Intelligent Slot ......................29 Annex B. EPO ........................30 Annex C. Rated Parameters Setting ..................29 Annex D. Battery Kit Assembly (option) ................. 34 PowerMan Online 1KVA & 3KVA User Manual... -
Page 6: Electromagnetic Compatibility
Electromagnetic Compatibility 1.Electromagnetic Compatibility * Safety IEC/EN 62040-1-1 * EMI Conducted Emission..IEC/EN 62040-2 Class A Radiated Emission....IEC/EN 62040-2 Class A *EMS ESD........IEC/EN 61000-4-2 Level 4 RS........IEC/EN 61000-4-3 Level 3 EFT........IEC/EN 61000-4-4 Level 4 SURGE......IEC/EN 61000-4-5 Level 4 Low Frequency Signals....:IEC/EN 61000-2-2 Warning: This is a product for commercial and industrial application in the second environment-installation restrictions or additional measures may be needed to prevent disturbances. -
Page 7: Introduction
Introduction 2. Introduction Congratulations on your choice of the uninterruptible power system(UPS), the UPS comes in nominal power ratings of 1000VA,2000VA and 3000VA. It is designed to provide conditioned power to microcomputers and other sensitive electronic equipment. When it is generated, alternating current is clean and stable. However, during transmission and distribution it may be subject to voltage sags, spikes and complete power failure that may interrupt computer operations, cause data loss and even damage equipment. - Page 8 Introduction Fig.2 Rear View PowerMan Online 1KVA & 3KVA User Manual...
- Page 9 Output Socket IEC C19 In addition, in view of the long backup time requirements, Specially designed the battery pack, the diagram below: Fig.3-1Front View of Battery pack Fig.3-2 Rear View of Battery pack PowerMan Online 1KVA & 3KVA User Manual...
-
Page 10: System Description
3.4 Battery Charger The battery charger utilizes energy from the utility power and precisely regulates it to continuously float charge the batteries. The batteries are being charged whenever the UPS is PowerMan Online 1KVA & 3KVA User Manual... -
Page 11: Dc-To-Dc Converter
UPS automatically transfers the connected load to bypass. Bypass operation is indicated by an audible alarm and illuminated amber Bypass LED. NOTICE：The bypass power path does NOT protect the connected equipment from disturbances in the utility supply. PowerMan Online 1KVA & 3KVA User Manual... -
Page 12: Product Specification And Performance
Voltage 200V/208V/220V/230V/240V Output 15/14.4/13.5/12.9/12. Current 5/4.8/4.5/4.3/4.2A 10/9.6/9/8.6/8.4A Dimension 438*477*86（L） 438*426*86（L/S） (WxDxH) mm 438*477*173（S） Standard 11.5 13.5 Weight (kg) Long 2. Electrical Performance Input Model Voltage Frequency Power Factor 1-3KVA Single-phase 40-70Hz >0.98(Full load) PowerMan Online 1KVA & 3KVA User Manual... - Page 13 NOTICE：If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated in use, please refer to the following: Altitude (M) 1000 1500 2000 2500 3000 3500 4000 4500 5000 Derating Power 100% PowerMan Online 1KVA & 3KVA User Manual...
-
Page 14: Installation
Otherwise there are hazards of electric shock. 5.2.2 Tower Installation Various installation configurations are available: single UPS, single UPS with single or multiple battery cabinets. Their installation methods are all the same. PowerMan Online 1KVA & 3KVA User Manual... - Page 15 Fig.4-2 Installing support bases with spacers Step 3: Adjust the direction of UPS operation and display panel and LOGO. 1. Remove the front plastic bezel cover gently, as shown in Fig.4-3. Fig.4-3 Removing the front plastic bezel cover PowerMan Online 1KVA & 3KVA User Manual...
- Page 16 4. Restore the front plastic bezel cover to the UPS. At this point, the UPS operation and display panel and LOGO have been rotated 90 degrees clockwise, which provides upright viewing for users. PowerMan Online 1KVA & 3KVA User Manual...
-
Page 17: Rack Installation
Installation method: 1. Take out two brackets and six M4 × 10 screws from the accessories, and fix the brackets onto the UPS using the screws through installation hole, as shown in Fig.4-7. PowerMan Online 1KVA & 3KVA User Manual... -
Page 18: Operating Procedure For Connecting The Long Backup Time Model Ups With The External Battery
5.3 Operating procedure for connecting the long backup time model UPS with the external battery Notice: Please connect the external battery at least 40AH while the charge current is 8A, at least 20AH for 4A.otherwise may cause damage to the battery. PowerMan Online 1KVA & 3KVA User Manual... - Page 19 Notice: DO NOT connect the battery plug to the battery socket of UPS first, otherwise, it may cause electric shock. 4. Connect the external battery plug to the battery socket on the rear panel. PowerMan Online 1KVA & 3KVA User Manual...
-
Page 20: Controls And Indicators
1.Press FUNC button to transfer in different menus 2.Press FUNC button for 2.5 seconds to mute off FUNC 3.Press FUNC and ON/OFF together for 2.5 seconds to set rated parameters when only power supply is on Indicators Description PowerMan Online 1KVA & 3KVA User Manual... - Page 21 Battery indicator: yellow—battery discharge or charged yellow flicker—battery is not connected, battery is low or charger is failure dark—battery is connected Fig 6. LCD Main Menu PowerMan Online 1KVA & 3KVA User Manual...
- Page 22 UPS ID(1-9) in setting mode Load information Load percent(%) Active load(kW) Apparent load(kVA) Protocol code in setting mode Output information Output voltage(VAC) Output frequency(Hz) Output current(A) Note: Press “FUNC” button to see different information. PowerMan Online 1KVA & 3KVA User Manual...
-
Page 23: Audible Alarm
Controls and Indicators 6.2 Audible Alarm Condition Alarm Battery discharge Sounding every 2 minutes Low battery Sounding every 6 seconds Overload Continuous beeping Input voltage abnormal Sounding every 2 minutes PowerMan Online 1KVA & 3KVA User Manual... -
Page 24: Operation
NOTICE：Please turn off the connected loads before turning on the UPS and turn on the loads one by one after the UPS is working in INV mode. Turn off all of the connected loads before turning off the UPS. PowerMan Online 1KVA & 3KVA User Manual... -
Page 25: Battery Maintenance
Step 1: Gently remove the front plastic bezel cover from the UPS. Step 2: Loosen and remove the screws on the battery door, as shown in Fig.7-1. Lay the battery door aside for reassembly. PowerMan Online 1KVA & 3KVA User Manual... - Page 26 Battery Maintenance Fig.7-1 Removing the front plastic bezel cover and battery door PowerMan Online 1KVA & 3KVA User Manual...
- Page 27 Step 3: Gently pull the battery wire out and disconnect battery wires, as shown in Fig.7-2. Fig.8-2 Disconnect battery wires Step 4: Grasp the battery handle, and pull the internal battery pack out of the UPS, as shown in Fig.7-3. PowerMan Online 1KVA & 3KVA User Manual...
- Page 28 NOTICE：Do not replace the internal battery pack while the UPS is operating in Battery Mode. This will result in a loss of output power and will drop the connected load. Moreover, it will jeopardize personnel safety！ PowerMan Online 1KVA & 3KVA User Manual...
-
Page 29: Notes For Battery Disposal And Replacement Procedures
Remove metal bars which are used to fasten batteries. Replace batteries one by one. Screw metal bars back to UPS. Connect the battery wires one by one. Take care of electrical shock while connecting the last wire. PowerMan Online 1KVA & 3KVA User Manual... -
Page 30: Trouble Shooting
UPS rear panel. If not ,contact with distributer or service center. If yes, please check PE wire in input power socket Warn: Bypass Bypass voltage is out Check if utility power is indeed out of PowerMan Online 1KVA & 3KVA User Manual... - Page 31 Fault: Rectifier Bus over voltage, bus Please contact with distributer or fault unbalance, rectifier service center. starting failure, under voltage, input fuse is off PowerMan Online 1KVA & 3KVA User Manual...
- Page 32 Charge the battery for more than 10 time diminishes been fully charged hours UPS is overload Check the loads and remove some devices Battery aged Replace batteries. Please contact with distributer or service center obtain replacement PowerMan Online 1KVA & 3KVA User Manual...
- Page 33 Please provide the following information when reporting fault UPS: The UPS model and serial NO. The warn and fault code happened Detail of fault, include LED indicates, buzzer beeps, power condition, load capacity and configuration of battery(long backup time model) PowerMan Online 1KVA & 3KVA User Manual...
-
Page 34: Annex A. Intelligent Slot
Pin7 to pin5 is NO if battery voltage is low. If not, NC. Normal mode Pin8 to pin5 is NC if UPS works in normal mode. If not, NO. Utility fail Pin9 to pin5 is NO if utility is failure. If not, NC. PowerMan Online 1KVA & 3KVA User Manual... -
Page 35: Annex B. Epo
Normal, EPO terminals without short, When emergencies happen to short the EPO terminals, EPO effect function, UPS close the rectifier ,inverter output immediately, schematic diagram is as follows: effect function Fig.9 EPO PowerMan Online 1KVA & 3KVA User Manual... -
Page 36: Annex C. Rated Parameters Setting
Mode setting: press ON/OFF to choose frequency and enter in mode setting, press FUNC to change mode. First code: n-normal mode, E-ECO mode. Second code indicated current voltage/frequency are listed in description of main menu in section 6. PowerMan Online 1KVA & 3KVA User Manual... - Page 37 The ID number of the UPS is displayed as 01-09, default 01. Protocol setting: press ON/OFF to choose mode and enter in protocol setting. Codes are shown in LOAD, press FUNC to change protocol. First code: 0-Modbus, 1-SNT, “CC”-current protocol. PowerMan Online 1KVA & 3KVA User Manual...
- Page 38 10) If you want to exit from setting mode and give up saving, press ON/OFF and FUNC together for 2.5 seconds when in setting mode. 11) Restart and check if the setting is right. PowerMan Online 1KVA & 3KVA User Manual...
-
Page 39: Annex D. Battery Kit Assembly (Option)
Battery Kit Assembly (option) Annex D. Battery Kit Assembly (option) 1k battery kit PowerMan Online 1KVA & 3KVA User Manual... - Page 40 Battery Kit Assembly (option) 2k battery kit PowerMan Online 1KVA & 3KVA User Manual...
- Page 41 Battery Kit Assembly (option) 3k battery kit PowerMan Online 1KVA & 3KVA User Manual...
- Page 42 66001- 00218 V1.9 17 Honeydew Business Park, 1503 Citrus Street, Laser Park Honeydew Tel: 0861 444 445 Email: sales@powerman.co.za Web: www.powerman.co.za...
