Linear Technology DC2435A-A Demo Manual page 9

parts list
ITEM QTY REFERENCE
20 1 Q22
21 1 R33
22 1 R35
23 2 R43, R78
24 2 R46, R48
25 1 R72
26 1 R75
27 1 R79
28 1 R81
29 1 R86
30 1 R92
31 1 RS1
32 1 RS2
33 1 U1
Additional Demo Board Circuit Components
1 0 C1, C2, C3, CIN5, C6, C59, C68
2 0 C36
3 0 C7, C39, C40, C51, C66, C67, C73, C74,
C78, C79
4 0 C55, C57, C60, C63, C65, C77
5 0 D3
6 0 D4
7 0 L3
8 0 Q9, Q11, Q18, Q19
9 11 R34, R36, R39, R40, R70, R80, R95,
R96, R103, R105, R108
10 0 R37, R51, R53, R55, R62, R85, R89,
R90, R91, R93, R94, R104, R106,
R107, R109, R110, R111
11 0 R82
12 0 R100
13 0 R101
14 1 R102
15 0 RS3
Hardware: For Demo Board Only
1 14 E1-E14
2 2 JP1, JP2
3 1 JP3
4 3 XJP1, XJP2, XJP3
5 6 J1, J2, J3, J4, J5, J6
6 0 J9, J10
7 4
DEMO MANUAL DC2435A-A/
DC2435A-B/DC2435A-C
PART DESCRIPTION
XSTR, N-CHANNEL MOSFET
RES., 9.76kΩ,1/10W, 1%, 0603
RES., 7.5kΩ,1/10W, 1%, 0603
RES., 332kΩ,1/10W, 1%, 0603
RES., 100kΩ,1/10W, 5%, 0603
RES., 37.4kΩ,1/10W, 1%, 0603
RES., 3.6kΩ,1/10W, 1%, 0603
RES., 21kΩ,1/10W, 1%, 0603
RES., 100Ω,1/10W, 5%, 0603
RES., 2.2ΩS,1/10W, 5%, 0603
RES., 90.9kΩ,1/10W, 1%, 0603
RES., SENSE, 0.008Ω,1/2W, 1%, 2010
RES., SENSE, 0.006Ω,1/2W, 1%, 2010
IC, LOW I , 60V BOOST + BUCK SYNCHRONOUS
Q
CONTROLLER
CAP ., OPTION, 1210
CAP ,. OPTION, 1206
CAP ., OPTION, 0805
CAP ., OPTION, 0603
DIODE, OPTION, SMB
DIODE, OPTION, SOD323
IND., OPTION
XSTR, OPTION, N-CHANNEL MOSFET
RES., 0Ω, 1/10W, 0603
RES., OPTION, 0603
RES., OPTION, 1206
RES., OPTION, 0805
RES., OPTION, 2010
RES., 0Ω, 2010
RES., SENSE, OPT, 2010
TURRET
CONN., HEADER, 1×3, 2mm
CONN., HEADER, 2×3, 2mm
SHUNT, 2mm
JACK, BANANA
PAD
STANDOFF , SNAP ON
MANUFACTURER/PART NUMBER
INFINEON, BSC072N08NS5
VISHAY, CRCW06039K76FKEA
VISHAY, CRCW06037K5FKEA
VISHAY, CRCW0603332KFKEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW060337K4FKEA
VISHAY, CRCW06033K60FKEA
VISHAY, CRCW060321K0FKEA
VISHAY, CRCW0603100RJNEA
VISHAY, CRCW06032R20JNEA
VISHAY, CRCW060390K9FKEA
VISHAY, WSL20108L000FEA18
VISHAY, WSL20106L000FEA18
LINEAR TECH. LTC7813EUH#PBF
OPTION
OPTION
OPTION
OPTION
OPTION
OPTION
OPTION
OPTION
VISHAY, CRCW06030000Z0EA
OPTION
OPTION
OPTION
OPTION
VISHAY, CRCW20100000Z0EF
OPTION
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 620-003-111-21
WURTH ELEKTRONIK, 620-006-211-21
WURTH ELEKTRONIK, 608-002-134-21
KEYSTONE, 575-4
NONE
KEYSTONE, 8832
dc2435af
9
