DEMO MANUAL DC2435A-A/
DC2435A-B/DC2435A-C
parts list
ITEM QTY REFERENCE
1 2 CIN1, COUT1
2 1 COUT2
3 6 CIN2, CIN3, CIN4, COUT6, COUT8, C80 CAP , 4.7µF, X7R, 100V, 10%,1210
4 2 COUT4, C5
5 2 COUT5, COUT11
6 5 C4, C17, C21, C47, C52
7 3 C15, C56, C62
8 1 C43
9 1 C44
10 1 C49
11 1 C53
12 1 C54
13 1 C61
14 2 C64, C81
15 1 L1
16 1 L2
17 1 Q1
18 1 Q2
19 1 Q21
20 1 Q22
21 1 R33
22 1 R35
23 2 R43, R78
24 2 R46, R48
25 1 R72
26 1 R75
27 1 R79
28 1 R81
29 1 R86
30 1 R92
31 1 RS1
32 1 RS2
33 1 U1
Additional Demo Board Circuit Components
1 0 C1, C2, C3, CIN5, C6, C59, C68
2 0 C36
3 0 C7, C39, C40, C51, C66, C67, C73, C74,
C78, C79
4 0 C55, C57, C60, C63, C65, C77
10
PART DESCRIPTION
DC2435A-C
CAP , 33µF, 63V, 20%, ELEC
CAP , 100µF, 63V, 20%, ELEC
CAP , 2.2µF, X7R, 100V,10%,1206
CAP , 68µF, 35V, 20%, D8
CAP , 0.1µF, X7R, 25V ,10%, 0603
CAP , 1nF, X7R, 50V,10%,0603
CAP , 68pF, NPO, 50V, 10%,0603
CAP , 4.7nF, X7R, 50V,10%,0603
CAP , 47pF X7R, 50V, 5%, 0603
CAP , 820pF X7R, 50V, 5%, 0603
CAP , 27nF, X7R, 50V,10%, 0603
CAP , 1µF, X5R, 25V, 20%, 0603
CAP , 4.7µF X5R,10V, 20%, 0603
IND, 10µH
IND, 15µH
XSTR, N-CHANNEL MOSFET
XSTR, N-CHANNEL MOSFET
XSTR, N-CHANNEL MOSFET
XSTR, N-CHANNEL MOSFET
RES., 63.4kΩ,1/10W, 1%, 0603
RES., 4.99kΩ,1/10W, 1%, 0603
RES., 332kΩ,1/10W, 1%, 0603
RES., 100kΩ,1/10W, 5%, 0603
RES., 37.4kΩ,1/10W, 1%, 0603
RES., 3.6kΩ,1/10W, 1%, 0603
RES., 17.4kΩ,1/10W, 1%, 0603
RES., 100Ω,1/10W, 5%, 0603
RES., 2.2Ω,1/10W, 5%, 0603
RES., 90.9kΩ,1/10W, 1%, 0603
RES., SENSE,0.008Ω,1/2W, 1%, 2010
RES., SENSE, 0.010Ω,1/2W, 1%, 2010
IC, LOW I , 60V BOOST + BUCK SYNCHRONOUS
Q
CONTROLLER
CAP , OPTION, 1210
CAP , OPTION, 1206
CAP , OPTION, 0805
CAP , OPTION, 0603
MANUFACTURER/PART NUMBER
SUN ELEC. 63HVH33M
UNITED CHEMI CON,
EMZA630ADA101MJA0G
MURATA, GRM32ER72A475KE14L
MURATA, GRM31CR72A225KA73L
PANASONIC, EEHZA1V680XP
TDK, C1608X7R1E104K
AVX, 06035C102KAT2A
AVX, 06035A680KAT2A
AVX, 06035C472KAT2A
AVX, 06035A470JAT2A
AVX, 06035A821JAT2A
AVX, 06035C273KAT2A
TDK, C1608X5R1E105M
AVX, 0603ZD475MAT2A
COILCRAFT, SER1390-103ML
COILCRAFT, XAL1510-153MED
INFINEON, BSC123N08NS3G
INFINEON, BSC042NE7NS3G
INFINEON, BSC026N08NS5
INFINEON, BSC072N08NS5
VISHAY, CRCW060363K4FKEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW0603332KFKEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW060337K4FKEA
VISHAY, CRCW06033K60FKEA
VISHAY, CRCW060317K4FKEA
VISHAY, CRCW0603100RJNEA
VISHAY, CRCW06032R20JNEA
VISHAY, CRCW060390K9FKEA
VISHAY, WSL20108L000FEA18
VISHAY, WSL201010L000FEA18
LINEAR TECH. LTC7813EUH#PBF
OPTION
OPTION
OPTION
OPTION
