- Page 1 BUSDAQ / BUSLOG Version 3 R 6 - 2018-10-17 Getting started © 2018 imc Test & Measurement GmbH imc Test & Measurement GmbH • Voltastraße 5 • 13355 Berlin • Germany...
- Page 2 Copyright © 2018 imc Test & Measurement GmbH, Germany This documentation is the intellectual property of imc Test & Measurement GmbH. imc Test & Measurement GmbH reserves all rights to this documentation. The applicable provisions are stipulated in the "imc Software License Agreement".
-
Page 3: Table Of Contents
4.1.6 ARINC-Bus (DSUB-15) .......................... 29 4.2 DSUB-9 pin configuration ....................30 4.2.1 Display ..............................30 4.2.2 Modem (external) ..........................30 © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... - Page 4 4.4 DI/DO pin configuration (DSUB-15) .................. 32 4.4.1 Metal connector ..........................33 5 Last Changes ....................34 6 Symbols and legend ..................35 Index ......................... 36 © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17...
-
Page 5: General
Products not satisfying these requirements may only be used with special approval of the regulating body in the country where operated. All signal lines connected to imc BUSDAQ / BUSLOG must be shielded and the shielding must be grounded. © 2018 imc Test & Measurement GmbH... - Page 6 FCC Rules and Regulations. Industrial Safety We certify that imc BUSDAQ / BUSLOG in all product configuration options corresponding to this documentation conforms to the directives in the accident prevention regulations in "Electric Installations and Industrial Equipment" (DGUV Regulation 3) This certification has the sole purpose of releasing imc from the obligation to have the electrical equipment tested prior to first use (§...
-
Page 7: Imc Customer Support / Hotline
The measurement system has been carefully designed, assembled and routinely tested in accordance with the safety regulations specified in the included certificate of conformity and has left imc in perfect operating condition. To maintain this condition and to ensure continued danger-free operation, the user should pay particular attention to the remarks and warnings made in this chapter. -
Page 8: Instruction Manual
1.5 Guarantee Each device is subjected to a 24-hour "burn-in" before leaving imc. This procedure is capable of recognizing almost all cases of early failure. This does not, however, guarantee that a component will not fail after longer operation. Therefore, all imc devices are guaranteed to function properly for two years. -
Page 9: Notes On Maintenance And Servicing
This will help expedite the process of problem elimination. For questions by telephone please be prepared to provide your device's serial number and have your imc installation software, as well as this manual at hand, thanks! The serial number, necessary power supply, interface type and software version included can be determined from the plaque on the side of the device. -
Page 10: Operating Personnel
Improper handling may lead to serious damage to personnel and property. When in doubt, consult qualified personnel. · Work which may only be performed by trained imc personnel may not be performed by the user. Any exceptions are subject to prior consultation with the manufacturer and are conditional on having obtained corresponding training. -
Page 11: After Unpacking
To clean the slits use a small soft dry brush. · Do not allow liquids to enter the housing interior. · Be certain that the ventilation slits remain unobstructed. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 12: Start Of Operation With The Hardware
1. Observe the data in the chapter "Technical Specs", to prevent damage to the unit through inappropriate signal connection. 2. If you are using a internal device drive, observe the notes in the imc software manual. Particular care should be taken to comply with the storage device’s max. ambient temperature limitation. -
Page 13: Dc Power Supply At Can-Nodes 1 And 2
2.2.2 DC power supply of connected CANSAS units Not only the imc BUSDAQ device can be supplied with power externally, as described above, but also, it is possible to power connected imc CANSAS modules from the imc BUSDAQ’s power supply unit. Here, too, a cable of sufficient cross-section is needed. -
Page 14: Ups And Power Fail Function
Thus, brief interruptions of the power supply will not cause a measurement to be aborted. The buffer time constant is ten seconds for imc BUSLOG and imc BUSDAQ-2 ten, and fifteen seconds for imc BUSDAQ-X. Immediately after the running measurement is completed, that takes another 10 seconds. -
Page 15: Remote On/Off
The remote operation with imc BUSDAQ-X devices is only possible with a switch at the control socket not with a push-button. In case of a closed switch on the control socket the device will be activated permanently and it will turn off when the switch has been opened. -
Page 16: Potential Difference With Synchronized Devices
No fuses are included in the device. For BUSDAQ-X (MP0,5-4 4V Pb) the manufacturer specifies 5-7 years @ T<20°C and less than 1 year @ 50°C, if the discharge is very little (Trickle-life). Charging these internal backup batteries is accomplished automatically when the activated device receives a supply voltage. -
Page 17: Leds And Beeper
LEDs and Beeper 2.6 LEDs and Beeper 6 Status LEDs and a beeper are provided at imc BUSDAQ-X devices as additional visual and acoustic "output channels". They can be used just as standard output channels in imc Online FAMOS by assigning them the binary values "0"... -
Page 18: Start Of Operation Software / Firmware
Use of software requires a license, subject to the purchase order and configuration (see e.g. imc STUDIO manual product configuration / license). In order to be able to install or uninstall imc STUDIO products, you must be registered with a user account possessing administrator rights to the PC. This applies to the overwhelming majority of all installations of Windows. - Page 19 IP-address using the Command Prompt/Command line. Note, however, that automatically obtained IP-addresses might change the next time the operating system is started! © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17...
- Page 20 Modern PCs and network switches are able to switch electronically. Hence you can use both cable types. Step 3: IP-configuration Start imc STUDIO. Open the dialog for configuring the device IP address by clicking on the button Device interfaces ( Ribbon...
- Page 21 Note: Connection via modem If the connection to the device is established via a modem, start the program imc DEVICES Interface Configuration by clicking on the button: Advanced Configuration. An exact description is found in the chapter: Setup - Connect the device > Special options for connecting to the device.
-
Page 22: Firmware Update
The firmware update for the device module is only performed if it does not. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... - Page 23 Start of the firmware update (example of a single device) The state of the components of the firmware is diaplayed in the list. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17...
- Page 24 Conclusion of the firmware update (example of a single device) · Choose Close. The device can now be used with the product software. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17...
- Page 25 Other scenarios are feasible, e.g. if switches are activated, which can also respond to missing data traffic. If an error message is posted during the firmware update, leave the device on and contact the imc Hotline. It may be possible to continue the firmware-update under the guidance of the Hotline using a service program.
-
Page 26: Pin Configuration
Rear view imc BUSLOG | imc BUSDAQ-2 | imc BUSDAQ-X Front view imc BUSLOG | imc BUSDAQ-2 | imc BUSDAQ-X © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 27: Pin Configuration Of The Field Busses
TX/RX + J1587 bus line connected TX/RX - J1587 Ground connected reserved unused reserved unused © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 28: Flexray-Bus (Dsub-9)
BP channel A (positive bus line channel A) BP channel B (positive bus line channel B) 4.1.5 XCPoE (RJ45) Standard Ethernet 1x RJ45. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 29: Arinc-Bus (Dsub-15)
Tx4B sending channel 4B Rx8A receiving channel 8A Rx8A receiving channel 8A Rx8B receiving channel 8B Rx8B receiving channel 8B © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 30: Dsub-9 Pin Configuration
2x Black PPS (1 Hz clock) Yellow Yellow Pin configuration at measurement device. At the GPS-mouse Rx and Tx are interchanged. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 31: Ctrl-Plug Pin Configuration
+Sleep / Resume High sleep mode: 0 V to 1 V; Resume Mode: 4 V to 55 V imc BUSDAQ-X devices can be powered on or off with a switch (or with the standard Power-On) and not with push button. -
Page 32: Di/Do Pin Configuration (Dsub-15)
CHASSIS IMPORTANT NOTE The pin configuration does not match with any imc-DSUB15 plug! From hardware version Multi IO7 on, the imc DSUB connector ACC/DSUB-DI2-4 and ACC/DSUB-DO4 can be used. LEVEL open = 24V; LEVEL 1/2 and -IN 1/2 or (LEVEL 3/4 and -IN 3/4 ) jumpered=TTL The different MultiIO varieties can be distinguished by the button for exchanging the CF card. -
Page 33: Metal Connector
3. Insert the bend protection 4. The pressure nut must be screwed back on 5. The lid screws can be tightened © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 34: Last Changes
Amendments and bug-fix in Version 3 R 4 Chapter Amendments General smaller changes and improvements imc BUSDAQ-X devices can be powered on or off with a switch (or with the standard Power-On) and not with push button. Amendments and bug-fix in Version 3 R 3 Chapter Amendments... -
Page 35: Symbols And Legend
... points out, concerning WEEE guideline, that the product may not be thrown in the domestic refuse. The product was brought into the market after 2005 August 13th. © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... -
Page 36: Index
ISO-9001 DSUB-15 digital inputs ISOSYNC DSUB-15 digital outputs DSUB-9 GPS-receiver J1587-Bus DSUB-9 (optional) pin configuration DSUB-9 modem pin configuration © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17... - Page 37 Power via CAN Product improvement Quality Management remote control RoHS Service: Hotline shielding shielding: signal leads signal: interference Software installation special voltage © 2018 imc Test & Measurement GmbH imc BUSDAQ / BUSLOG - Getting started, Version 3 R 6 - 2018-10-17...
