USE AND MAINTENANCE INSTRUCTIONS
PELLET BOILER
Mini S
ead instructions carefully before installation, use and maintenance
The instruction manual is an integral part of the product
Laminox S.r.l. reserves the right to change the characteristics and data reported in the following
document at any time and without warning in order to improve their products. This manual, therefore,
cannot be considered as a contract with third parties.
The updated manuals and drawings are available on the website www.laminox.com.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LAMINOX IDRO Termoboiler Mini S
Summary of Contents for LAMINOX IDRO Termoboiler Mini S
- Page 1 The instruction manual is an integral part of the product Laminox S.r.l. reserves the right to change the characteristics and data reported in the following document at any time and without warning in order to improve their products. This manual, therefore, cannot be considered as a contract with third parties.
- Page 2 CAUTION, READ CAREFULLY MANDATORY COMPONENTS* • Fume-exhaust duct suitable for solid fuel condensation and resistant against condensation– vacuum pressure operation (N1) but airtight at a pressure up to 0.2 mbar. Refer to standard UNI 10683 :2022 • 1” anti-condensation valve with opening between 45 and 55°C •...
- Page 3 Dear Customer, thank you for choosing one of our products, which is a result of technological expertise and our continuous quest for superior products in terms of safety, reliability and performance. This manual contains all the information and helpful tips for using your product with maximum safety and efficiency. IMPORTANT INFORMATION This manual has been prepared by the manufacturer and is an integral and essential part of the product.
-
Page 4: Table Of Contents
INSTALLATION ......................5 General notes........................5 Smoke discharge system ....................5 Smoke duct ........................5 Chimney of flue ....................... 6 Using an external fume duct .................... 7 Chimney pot ........................8 External air intake vent ....................9 Installation room ......................10 Minimum safety distances ..................... -
Page 5: Installation
INSTALLATION General notes The heating system or appliance must be installed in order not to damage the building and other systems. The installer must strictly comply with standard UNI 10683:2022 and all other applicable local regulations. Smoke discharge system Every device must be connected to a fume discharge system, which ensures dispersion of combustion products into the atmosphere. -
Page 6: Chimney Of Flue
• They must not pass through rooms at risk of fire or rooms that cannot be inspected • They must be installed in such a way as to allow for normal thermal expansion • Along their entire length, they must have a diameter no less than that of the attachment of the appliance's evacuation duct •... -
Page 7: Using An External Fume Duct
Tube diameter depends on the type of system. The boiler has been designed for Ø 80 mm and Ø 100 mm tubes (check the technical data sheet of the selected model). As can be seen in the table below, a double-wall Ø... -
Page 8: Chimney Pot
Fig. 5 Chimney pot The top of the chimney flue must be equipped with a device, called a chimney pot, which facilitates dispersion into the atmosphere of combustion products. The chimney pot must meet the following requirements: • Its internal section and shape must be equivalent to that of the chimney flue. •... -
Page 9: External Air Intake Vent
Fig.8 External air intake vent The boiler must have the air necessary to ensure smooth combustion operation and good environmental well-being. make sure that the room where the boiler is installed offers sufficient ventilation and install an air supply duct from the outside with the recommended minimum section of 6 cm². per kW This value must be increased by 50% if the boiler is installed in an underground room up to -5 m and by 100% if it is installed in an underground room above -5 m Ventilation openings are not required In the case of an airtight installation... -
Page 10: Installation Room
Installation room • This product must be installed in a technical room • Installing the device inside rooms at risk of fire is prohibited. • Outdoor installation in locations exported to weathering or humid areas is prohibited. • Boiler installation must be carried out in a location which allows safe and easy use and simple maintenance. -
Page 11: Minimum Safety Distances
1.9 Minimum safety distances The following figures show the minimum safety distances which must always be guaranteed. Corner installation (mm) Wall installation (mm) Fig.9 Fig.10 Safety distances from flammable material Minimum distance in air from the flammable rear wall P= 500 mm Minimum distance in air from the flammable side wall L= 500 mm Frontal distance from flammable material... -
Page 12: Flooring Protection
1.10 Flooring protection In the event of valuable flooring or flooring that is sensitive to heat, moisture or is flammable, a floor protection must be used (i.e. sheet steel, marble or tile slabs). Whichever type of protection selected, it must protrude at least 300 mm from the front, at least 150 mm from the sides of the boiler, must withstand the weight of the boiler and have a thickness of at least 2 mm (Fig. -
Page 13: Specifications And Technical Data
SPECIFICATIONS AND TECHNICAL DATA Specifications Pellet boilers are devices built to work with good quality wood pellets only (see par. 3 fuel). Technical data Termoboiler Termoboiler Termoboiler Model Mini 12S Mini 12S Mini 18S Power to the brazier 14,0 kW 15,8 kW 19,5 kW Hourly pellet consumption... -
Page 14: Electrical Diagrams
Electrical diagrams... -
Page 15: Fuel
3 FUEL General notes The pellet boiler is designed to burn wood pellets only. Wood pellets are a fuel obtained from the pressing of sawdust timber, extracted from the processing and transformation residues of dried wood material. The compactness of the product over time is guaranteed by a natural origin substance contained in the wood: lignin. -
Page 16: Assembly
Outlet connection in the rear of the boiler is illustrated in Fig. 15. Absorbed power is indicated in the product technical sheet, which can be downloaded from the website www.laminox.com. By law, the system must be properly grounded and with a differential circuit-breaker. Make sure that the electrical power cable does not come into contact with hot parts when set in its final position. -
Page 17: Water Connection
Water connection Connection of the boiler to the hydraulic system must be exclusively performed by qualified personnel, who is able to perfectly perform the installation, complying with the regulations in force in the Country of installation. If the installation of the boiler requires interaction with another pre-existing system equipped with another heating device (gas boiler, methane boiler, gasoline boiler, etc.), contacting qualified personnel able to respond to the conformity of the system, according to the requirements of the law in force regarding the subject, is more recommended. -
Page 18: Heating Boiler Diagram
4.4.2 Indications for water treatment To prevent the heating system from having to be regularly cleaned it is best to install a magnetic sludge remover, this filter aids routine maintenance, increases boiler life span, aid removal of impurities and increased global efficiency of the system. The magnetic sludge remover filters the heating system removing sludge, ferrous or sandy residues which circulate in the pipes, if not removed they create surfaces which do not permit heat transmission, consequent pellet consumption and possible boiler malfunction... -
Page 19: External Thermostat Installation
4.5.1 Indicative hydraulic diagram External thermostat installation Boiler operation must be adjusted by an external room thermostat connected to the electronic board (see wiring diagram). The thermostat connection is performed with a 2x0.5 mm²cable. The contact to be used is NO (Normally open). This operation should be performed by qualified personnel. -
Page 20: Use
5 USE The Termoboiler line boilers are designed to operate 24/7 365 days a year. The boiler has been designed to maintain the water it contains above 70°C. This way, water will always be available for the domestic environment heat request or for the production of DHW. This does not involve continuous pellet consumption, as the boilers are adjusted automatically according to the heat requests of the connected utility. -
Page 21: Console Description
• CAUTION: if during cleaning, you find traces of spongy or hard (though not ash) pellets, replace the pellets being used as this residue may come from scraps of low-quality sawdust not usable in this type of boiler. Forcing ignition can cause a fire or strong production of fumes in the chimney. -
Page 22: First Ignition
5.1.1 Console button functions Functions: BUTTON 4 • Manual On/Off of the boiler ON/OFF • Exit from a sub-menu • Exit forma a shutdown or alarm (and passage to Off status) Functions: BUTTON 5 • Reduction in set power value POWER •... -
Page 23: Ignition And Normal Operation
When the tank is loaded for the first time, the feed screw must fill up for a given period. During this time, pellets will not be distributed within the combustion chamber. To overcome this difficulty, use the command "initial load" in menu 7 of the control panel (see further details below). Ignition and normal operation Before igniting the boiler: •... - Page 24 5.3.2 No start-up As said, if the onset of combustion is not detected, the no start-up alarm will be set off. The display will show the message "AL 5 NO START" and an acoustic signal will be heard at regular intervals (if the buzzer function is active in Menu 6).
- Page 25 5.3.4 Modulation based on boiler water temperature The boiler is equipped with boiler water temperature sensor that allows it to modulate its power according to the desired temperature. To set water temperature, press button "1". Press button "1" once and the bottom of the display will show the message "...
-
Page 26: Additional Functions
CAUTION: Never disconnect the power supply at this stage, as this may create problems for the boiler and compromise the subsequent phases of ignition. 5.3.9 Interruption of power supply In the event of a brief interruption in the power supply (under 10 seconds), the boiler will automatically re-start without any alarms. -
Page 27: Menu
6 MENU Press button "3" (MENU) to access the menu. The menu is divided into different items and levels that allow you to access board settings and programming. Menu items that allow you to access technical programming are protected by an access key. -
Page 28: Menu 04 "Choose Language
decide which day of the week to activate the corresponding pair controls. With the first parameter, M-3-3-01 “WEEKLY CHRONO”, you can enable or disable all weekly programmable settings After having set the first parameter (M-3-2-01) “WEEKLY CHRONO” to "on", you can set 4 start-ups and 4 shutdowns. -
Page 29: Menu 10 "Pellet Type
6.9 Menu 10 “PELLET TYPE” This menu allows you to simultaneously increase or decrease all pellet lowering parameters (quantity of pellets and brazier loading). The set default value is 00. Press keys (1) and (2) to modify said value from -9 to +9. For each unit, pellet load times are increased or decreased by 2.5 %. 6.10 Menu 11 “FIREPLACE TYPE”... -
Page 30: Safety And Alarms
SAFETY AND ALARMS Safety devices CAUTION: During operation, some parts of the boiler (door, handle, ceramic parts) can reach very high temperatures. Remember to keep at the previously mentioned safe distance. Be careful, use caution and always follow the instructions. If during operations any part of the boiler or the exhaust pipe leak smoke, immediately turn off the boiler without removing the power supply and ventilate the room. -
Page 31: Alarms
to modulation, the fume temperature continues to increase and exceeds the second pre-set safety limit, the boiler will pass into alarm mode. Pellet flow is interrupted and fume exhaust speed is set to maximum. The display will show the message “AL 3 – SMOKE TEMP”. The boiler constantly controls smoke sensor functioning, If the sensor is momentarily and/or accidentally removed from its housing, or the connector is not correctly positioned on the circuit board or the sensor fails for any reason. - Page 32 To exit from an alarm condition, always press button "4" until the message "FINAL CLEANING" appears. You will also need to take additional steps, depending on the type of alarm generated If you do not exit from the alarm condition within a given time (a few hours), the alarm will be sent into boiler memory and the display will show the message "ALARM MEMORY".
- Page 33 • In the case of repeated feed screw blocks, call a support center AL 7 – Thermal safety This alarm is activated by intervention of the safety thermostat installed inside the boiler What to do Put the boiler in stand-by by pressing the off button for a few seconds. •...
-
Page 34: Warning And Maintenance
8 WARNING AND MAINTENANCE All maintenance operations (cleaning, replacements, etc.) should be carried out when the fire is out and the boiler is cold. In addition, do not use any abrasive substances. CAUTION: FAILURE TO CLEAN AFFECTS SAFETY Opening the door The door must remain closed during operation. -
Page 35: Cleaning Glass
Cleaning glass Door glass must be clean cold with ammonia-based and non-corrosive degreasers as a diluent. Prevent corrosive substances from coming into contact with the paint on the boiler as these can cause damage. If glass is hot, before proceeding with cleaning, keep the door open as long as necessary until it cools down. - Page 36 Laminox S.r.l. Zona Industriale Callarella, 261/263 – 62028 SARNANO (MC) Italy Tel. +39 0733.657.622 – Fax +39 0733.657.494 www.laminox.com e-mail: export@laminox.com TB Mini-rev03/2024 EN...
