Personal Computer
Model No. FZ-40 Series
Operating Instructions - Reference Manual
We recommend that this Reference Manual be printed.
Disclaimer
Computer specifications and manuals are subject to change without notice. Panasonic Connect Co., Ltd. assumes no liability for damage incurred dir-
ectly or indirectly from errors, omissions or discrepancies between the computer and the manuals. Refer for the latest information about optional
products to the catalogs, etc.
Panasonic Connect Co., Ltd.
Web Site :
https://panasonic.net/cns/pc/
© Panasonic Connect Co., Ltd. 2022
HS0522-0
20210096ZAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZ-40 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic FZ-40 Series

Summary of Contents for Panasonic FZ-40 Series

  • Page 1 Disclaimer Computer specifications and manuals are subject to change without notice. Panasonic Connect Co., Ltd. assumes no liability for damage incurred dir- ectly or indirectly from errors, omissions or discrepancies between the computer and the manuals. Refer for the latest information about optional products to the catalogs, etc.
  • Page 2 Introduction Illustrations and Terminology in this manual This manual explains using the default setting. In principle, this manual explains based on the following conditions: When the keyboard and touchpad are used for operation Some illustrations are simplified to help your understanding and may look different from the actual unit. Some types of software are automatically updated, and differences may occur from descriptions in this manual.
  • Page 3 When Windows is updated, the screen display or operation procedures may be changed. For the latest information on Windows, see the following web page. https://pc-dl.panasonic.co.jp/itn/win11/ Sound and Video Sound (e.g. MP3, WMA) and video (e.g. MPG, WMV) recorded in microSD memory card may be interrupted during playback. If this happens, copy them to the flash memory drive and play back.
  • Page 4 Attaching/Detaching the keyboard You can change to other language specific keyboard. IMPORTANT Be sure to turn off the computer before attaching or detaching the keyboard. Attaching and detaching the keyboard 1. Turn off the computer and disconnect the AC adaptor. 2.
  • Page 5 IMPORTANT You cannot use the removed keyboard again. 6. Connect the stack type connector of other language specific keyboard. IMPORTANT Do not pull the flat cable (G) connecting the keyboard and stack type connector (F) forcibly. 7. Tighten the screws (H) firmly. Use the PH 1 (PH #1) screwdriver.
  • Page 6 10. Attach the keyboard plate (L) and tighten the screws (M) firmly. Use the PH 1 (PH #1) screwdriver. Use 3 screws. Recommended tightening torque 0.45 N•m ± 0.05 N•m (4.5 kgf•cm ± 0.5 kgf•cm) 11. Insert the battery pack and connect the AC adaptor.
  • Page 7 Rear Expansion Area You can select from the following options. FZ-VCN401 FZ-VCN402 FZ-VCN403 VGA Port / Serial Port / 2nd LAN Serial Port / USB 3.2 Gen 1 (Type-A) Port / USB 3.2 Gen 1 (Type-A) Port / USB 3.2 Gen 1 (Type-A) Port / Port HDMI Port HDMI Port...
  • Page 8 2. Insert an option until it securely fits the connector. 3. Tighten the screws (E) firmly. Use the PH 1 (PH #1) screwdriver. Use 2 screws. Recommended tightening torque 0.45 N•m ± 0.05 N•m (4.5 kgf•cm ± 0.5 kgf•cm) 6. Close the cover until it clicks. 7.
  • Page 9 Right Expansion Area You can select from the following options. FZ-VZSU1XU FZ-VSC401 Second Battery Pack Smart Card Reader Inserting an option to the right expansion area 1. Turn off the computer and disconnect the AC adaptor. IMPORTANT We recommend that you turn off the computer completely the following. 1.
  • Page 10 2. Pull the tab (E) to pull out an option. 3. Insert an option until it securely fits the connector. 4. <When using Smart Card Reader> Slide the latch (F) until the orange-colored sign disappears in the indicator (G). 7. Close the cover (H) until it clicks. 8.
  • Page 11 Left Expansion Area You can select from the following options. FZ-VBR401 FZ-VDM401 FZ-VDM402 FZ-VBD401 FZ-V2S400 FZ-V2S401 FZ-VSC402 Barcode DVD MULTI Drive DVD-ROM Drive Blu-ray Disc Drive SSD Pack (512 SSD Pack (1 Smart Card Reader Pack Pack Pack Reader Inserting an option to the left expansion area 1.
  • Page 12 <Only for model with DVD MULTI Drive Pack, DVD-ROM Drive Pack or Blu-ray Disc Drive Pack> Press the release handle (G) and pull the release handle (G) to pull out an option. 3. Insert an option until it securely fits the connector. 4.
  • Page 13 Recommended tightening torque 0.45 N•m ± 0.05 N•m (4.5 kgf•cm ± 0.5 kgf•cm) 5. Close the cover until it clicks. 6. Insert the battery pack.
  • Page 14 Palm Rest Expansion Area You can select from the following options. FZ-VNF401 FZ-VFP401 FZ-VFP402 Contactless Smart Card Reader Fingerprint Reader (Windows Hello) Fingerprint Reader (Windows Hello, Multi User authentication) Inserting an option to the palm rest expansion area 1. Turn off the computer and disconnect the AC adaptor. IMPORTANT We recommend that you turn off the computer completely the following.
  • Page 15 4. Tighten the screws (B) firmly. Use the PH 1 (PH #1) screwdriver. Use 4 screws. Recommended tightening torque 0.45 N•m ± 0.05 N•m (4.5 kgf•cm ± 0.5 kgf•cm) 4. Insert the battery pack.
  • Page 16 1. Connect the USB storage device to the USB port. 3. Click (Start) - [All apps] - (Panasonic PC Recovery Disc Creation Utility). If the “User Account Control” is displayed, click [Yes]. 4. Click [Next]. 5. Confirm on-screen information ([Select OS Image] and [Number of discs required]), and then click [Next].
  • Page 17 If you fail to create a recovery disc or an error message appears, try either of the following procedures. Insert the disc or USB storage device correctly. Check the disc or USB storage device condition. Restart the computer and try to create a recovery disc again. Contact Panasonic Technical Support.
  • Page 18 About the Partition Structure IMPORTANT Do not add or delete partitions in Windows 11, as the Windows area and recovery partition must be adjacent to each other in Windows 11.
  • Page 19 Flash Memory Backup/Restore Function Panasonic Connect Co., Ltd. will bear no responsibility for any damage suffered (including loss of data) as a result of the use of this function. Creating a Backup of the Flash Memory Data You can create a backup of the flash memory data, which can be used to recover from hardware failure.

  • Page 20: Description Of Parts

    Description of Parts Front side A. Camera <Only for model with camera> Camera) a. IR Camera b. IR camera light (RED) c. Camera Lens d. Camera Indicator e. Ambient Light Sensor The ambient light sensor is equipped with an automatic brightness adjustment function that adjusts the display screen. ( About the Ambient Light Sensor)
  • Page 21 To close the camera cover 1. Slide the camera cover to the arrow direction. B. LCD C. LED Indicator : Caps Lock Indicator : Num Lock (numeric lock) Indicator : Scroll Lock Indicator : Drive Indicator (Drive status) : microSD Memory Card Indicator (Blinking: During access or a password is requested) D.
  • Page 22 Fingerprint Reader) O. LED Indicator : Power Indicator Off: Power off/Hibernation Green: Power on Blinking Green: Modern standby (Sleep) : Battery 1 Indicator : Battery 2 Indicator *1: When using second battery pack P. Security Slot A Kensington cable can be connected. For further information, read the manual that comes with the cable. Q.
  • Page 23 GPS) F. Wireless LAN Antenna <Only for model with wireless LAN> Wireless LAN) Right side A. Right Expansion Area You can select an option to the right expansion area and install it later. You can select from the following options. FZ-VZSU1XU FZ-VSC401 Second Battery Pack...
  • Page 24 1. Slide the cover to the arrow direction. Left side A. Left Expansion Area You can select an option to the left expansion area and install it later. You can select from the following options. FZ-VBR401 FZ-VDM401 FZ-VDM402 FZ-VBD401 FZ-V2S400 FZ-V2S401 FZ-VSC402 Barcode...
  • Page 25 External Display) E. Ventilation Hole (Exhaust) F. Rear Expansion Area You can select an option to the rear expansion area and install it later. You can select from the following options. FZ-VCN401 FZ-VCN402 FZ-VCN403 VGA Port / Serial Port / 2nd Serial Port / USB 3.2 Gen 1 (Type-A) Port / USB 3.2 Gen 1 (Type-A) Port / USB 3.2 Gen 1 (Type-A) LAN Port...
  • Page 26 <Only for model with External Antenna Connector> Pass Through to External Antenna) F. RAM Module Slot G. Ventilation Hole (Intake) H. Dust Cover Handling and Maintenance)

  • Page 27: Turning On / Turning Off

    Turning On / Turning Off Turning On Press and hold the power switch until the power indicator lights. ( Description of Parts) NOTE Do not press the power switch repeatedly. The computer will forcibly be turned off if you press and hold the power switch for 10 seconds or longer.

  • Page 28: Ignition Mode

    To conserve power, the following power saving methods are set at the time of purchase. The screen automatically turns off after : 10 minutes (when AC adaptor is connected) of inactivity 4 minutes (when operating by battery power) of inactivity The computer automatically enters sleep after : 10 minutes (when AC adaptor is connected) of inactivity...
  • Page 29 Touchpad Use the touchpad to move the cursor on the screen and perform computer operations. A. Work Surface (touchpad) B. Left Button C. Right Button Function Operation Move cursor Move the tip of your finger over the work surface. Click (Tap) Tap a touchpad or press a left button.

  • Page 30: Key Combinations

    Keyboard Key Combinations NOTE Do not repeatedly press the keys in quick succession. Do not use the key combinations together with touchpad (external mouse), touchscreen, programmable buttons or other key operations. Do not use the key combinations before you sign in to Windows. Wait until the drive indicator and the microSD memory turn off.
  • Page 31 Function Pop-up display ≪ Fn≫ + ≪ F4≫ Speaker on/off A slide bar appears. You can check the status of speaker by seeing an icon on the taskbar corner. : Mute ≪ Fn≫ + ≪ F5≫ Volume A slide bar appears. ≪...

  • Page 32: Hotkey Settings

    Panasonic PC Backlit Keyboard Settings Utility) When switched to [Night Mode] of “Panasonic PC Day Night Mode Utility”, if you add a check mark to [Backlit Keyboard], ≪ Fn≫ + ≪ F12≫ is disabled. ( Panasonic PC Day Night Mode Utility) ≪...
  • Page 33 Changing the functions assigned to the “P” buttons and “A” keys) Panasonic PC Backlit Keyboard Settings Utility The Panasonic PC Backlit Keyboard Settings Utility can be used to make custom color of the backlit keyboard. Starting Panasonic PC Backlit Keyboard Settings Utility 1. Click (Start) - [All apps] - (Panasonic PC Backlit Keyboard Settings Utility).
  • Page 34 To change the color of the backlit keyboard, click C. Color Settings To customize the color of the backlit keyboard, click Defining Custom Colors) D. Restore Default Restore the settings to the default color. NOTE The colors of [Color1] and [Color2] cannot be changed. 2.
  • Page 35 4. Click [Add to Custom Colors]. 5. Click the color under “Custom colors:”. 6. Click [OK]. NOTE If you change the color of the backlit keyboard to black, the backlit keyboard does not light. You can also decrease the brightness automatically to conserve power with Setup Utility. (As factory default, [On Battery Power] [Plugged in]...
  • Page 36 Screen Input Operation The screen of your computer allows you to perform the same operations as a mouse by touching its surface. You can use the touchscreen function to perform the same operation as the touchpad and mouse. The computer supports, using your fingers and the pen (included).
  • Page 37 Touch with a quick sweeping motion. Change “Touchscreen Mode” You can select the suitable operation mode in “Touchscreen Mode”. 1. Click (Start) - [All apps] - (Panasonic PC Settings Utility) - (Settings) - (Touchscreen). 2. Select the operation mode under “Touchscreen Mode”. [Auto] mode The optimal settings will be selected based on the environment.

  • Page 38: Calibrating The Screen

    Use this mode when operating with a glove on. Depending on the type of glove, operation may be ignored. With finger operation, the screen may not respond properly. [Touch (Water)] mode Use this mode when the screen or finger is wet with water drops in operation. Depending on the water drop condition, operation may be ignored.
  • Page 39 Panasonic PC Day Night Mode Utility) When [Manual] of “Panasonic PC Day Night Mode Utility” is selected, ≪ Fn≫ + ≪ 3≫ is enabled. You can change the functions. ( Changing the functions assigned to the “P” buttons and “A”...
  • Page 40 Click [Browse...] to select the application. [Advanced Options]: Arguments and working directory can be specified. If you select [Camera], pressing the selected button/key will launch the Panasonic PC Camera Utility. Press it while the Panasonic PC Camera Utility is running to take a picture.

  • Page 41: Important Tips

    Important Tips Important Battery Tips IMPORTANT The battery pack is a consumable item. The rate of battery deterioration depends on the usage environment, but as a guide, it will reach the end of its life after 1-3 years of use or 300-500 times of charging. If the battery pack swells or battery usage time is dramatically short even after being fully charged, we highly recommend replacing the battery.
  • Page 42 Right-click on the taskbar corner, click [Power and sleep settings], and set the “Power mode” to [Best power efficiency]. This will reduce power consumption. We recommend against using applications or screen saver that place a significant load on the CPU Some screen savers place a large load on the CPU.

  • Page 43: Battery Power

    Battery Power Battery Indicator Battery indicator (situation in use): (A) and Battery indicator (situ- Battery status ation in use) The battery pack is not inserted or not being charged. Not lit Concealed mode is set to ON. Orange Charging is in progress. [Battery Charging Indicator] in the [Main] menu of the Setup Utility is set to [Flashing], the indicator will alternately become lighter and darker (Flashing).

  • Page 44: Checking The Remaining Battery Power

    Battery indicator (replacing status) Battery status Green The battery pack can be replaced without turning off the computer. Blinking red The battery packs can only be replaced with turning off the computer. The battery pack can be replaced. (During shutdown, hibernation) Not lit The battery pack is not inserted or not being charged or other than those above.
  • Page 45 (Example) NOTE The battery display may not correspond to the actual remaining battery power in the cases as below. To correct the display, perform the Battery Recalibration ( Correcting the Battery Display (Battery Recalibration)). The battery indicator remains red. The indicator lights orange and the display shows 99 % for a long time. Low battery warning appears soon after a short time of use.

  • Page 46: Battery Duration

    1. Click (Start) - [All apps] - (Panasonic PC Settings Utility) - (Support) - (Battery) - [Perform battery recal- ibration]. 2. Click [OK] on “Perform Battery Recalibration after shutting down Windows.” screen. 3. Click [OK] on “Windows will be shut down. OK?” screen.

  • Page 47: Replacing The Battery Pack

    Replacing the Battery Pack The battery pack is a consumable item so the replacement will be necessary. If the battery operation time becomes noticeably short and not recovered even after recalibrating the battery, replace with a new battery. IMPORTANT The battery pack is not charged when you first purchase it. Be sure to charge it before using for the first time. Charging starts automatically when the AC adaptor is connected to the computer.
  • Page 48 6. Insert the battery pack (E) until it securely fits the connector. <When using second battery pack> 7. Close the cover (F) until it clicks. 8. Slide the latch (G) to the arrow direction to lock the cover. <When using second battery pack> When replacing the battery pack without turning off the computer <When using multiple battery packs>...
  • Page 49 1. Slide the latch (H) to the arrow direction. 2. Slide the latch (H) down to unlock the cover. 3. Open the cover (I), and check the status of battery indicator (J). <When using second battery pack> If some one battery has enough remaining power or the AC adaptor is connected, you can replace the battery pack without turning off and dur- ing sleep of the computer.
  • Page 50 <When using second battery pack> 6. Close the cover (N) until it clicks. 7. Slide the latch (O) to the arrow direction to lock the cover. <When using second battery pack> IMPORTANT Make sure the latches are securely locked, otherwise the battery pack may fall when you carry the computer.

  • Page 51: Setting Sleep

    Sleep/Hibernation Functions Starting Up Your Computer Quickly The sleep or hibernation functions allow you to shut off the computer without closing programs and documents. You can quickly return to the programs and documents that you were working on before sleep or hibernation. The sleep mode of this computer supports the modern standby mode.
  • Page 52 The following problem will occur if you fail the password input (failing three times or leaving the computer unattended for one minute or more) while resuming from sleep or hibernation. If you fail the password input while resuming from hibernation: Cannot resume from hibernation by the Task Scheduler or the operation to open the display.
  • Page 53 1. Click (Start) - (Power). 2. Click [Sleep] or [Hibernate]. NOTE Hibernation from the Windows system menu is not available as the factory default. To enter hibernation from the Windows sys- tem menu, the following setting is necessary. 1. Click (Start) - [All apps] - [Windows Tools] - [Control Panel].
  • Page 54 Ignition Mode The power status can be switched by connecting or disconnecting the AC adaptor. 1. Click (Start) - [All apps] - (Panasonic PC Settings Utility) - (Settings) - (Power Management). 2. Make the settings under “Ignition Mode”. [Enable “Power on AC”]: The computer is turned on by connecting the AC adaptor.
  • Page 55 [Power Status]: Select the power status. [Wait Time]: Select the time to switch to the set power status. [Display countdown]: Displays a countdown until the computer switches to the set power status. 3. Restart the computer to enable the new settings. NOTE You can also set [Power On AC] with Setup Utility.
  • Page 56 Panasonic PC Settings Utility You can perform the following operations easily by using the Panasonic PC Settings Utility. When starting up this application for the first time, connect to the Internet for initial setup. If it is first started up without Internet connection, the initial setup may take time, and several minutes may be required for startup.
  • Page 57 Hotkey Settings) Network Wireless LAN: Wireless LAN) Utilities You can use Panasonic applications that display icons. To use these applications, click an icon. Support System PC Information: Display particular PC information. [Launch PC Information Viewer] Checking the Computer’s Usage Status)
  • Page 58 If the “User Account Control” is displayed, click [Yes]. The new settings will be activated after restarting this application. You can export or import the display items that can be used by XML files on this utility. About Panasonic PC Settings Utility: Display the version information.

  • Page 59: Connecting Lan

    Connecting LAN IMPORTANT Do not connect the telephone cable to the LAN port. 1. Slide the cover (A) to the arrow direction. The cover is unlocked. 2. Open the cover (A). 3. Connect the LAN cable. Connect the LAN port (B) and the network system (server, HUB, etc.) using a LAN cable. <Only for model with 2nd LAN>...
  • Page 60 Connect the LAN port (E) and the network system (server, HUB, etc.) using a LAN cable.

  • Page 61: Disabling/Enabling Wireless Communication

    Disabling/Enabling Wireless Communication <Only for model with wireless LAN/Bluetooth/wireless WAN/GPS on wireless WAN/dedicated GPS> There are several ways of disabling and enabling wireless communication. Switching the airplane mode using ≪ Fn≫ Using airplane mode Turning wireless communication on/off quickly Using Network & Internet settings Setting [Wireless Configuration] in the [Advanced] menu of the Setup Utility...
  • Page 62 Turning on/off the airplane mode 1. Click on the taskbar corner. 2. To turn on the airplane mode, click The icon changes to , and then the icon on the taskbar corner changes to To turn off the airplane mode, click .

  • Page 63: Using The Wireless Lan Function

    Wireless LAN <Only for model with wireless LAN> Using the wireless LAN allows for the use of network without cable connection. IMPORTANT Do not use wireless LAN on airplanes, in hospitals, or in other locations where wireless LAN signals may affect devices. Follow the instructions of airline companies and hospitals.
  • Page 64 For further information, ask the system administrator or the person in charge of the network. Switching the frequency band of the wireless LAN 1. Click (Start) - [All apps] - (Panasonic PC Settings Utility) - (Settings) - (Network). 2. Select the frequency band under “Wireless LAN”.

  • Page 65: Using The Bluetooth Function

    Bluetooth <Only for model with Bluetooth> You can access internet and other Bluetooth devices without connecting cables. NOTE Communication is established through the Bluetooth antenna (A). Do not block the antenna area with your hand or body. To use Bluetooth, set [Bluetooth] to [Enabled] (default) in the sub-menu of [Wireless Configuration] in the [Advanced] menu of the Setup Utility.

  • Page 66: Wireless Wan

    Wireless WAN <Only for model with wireless WAN> The model with wireless WAN allows for data communication using the incorporated communication module. The computer is equipped with a nanoSIM card slot and an eSIM. eSIM allows wireless communication without a nanoSIM card. This model is DSSS (Dual SIM Single Standby) and you can only make either nanoSIM Card or eSIM Active.
  • Page 67 Inserting a nanoSIM card 1. Turn off the computer and disconnect the AC adaptor. 2. Remove the battery pack. ( Replacing the Battery Pack) <When using second battery pack> Remove the second battery pack. ( Replacing the Battery Pack) 3. Slide the cover (A) to the arrow direction. 4.
  • Page 68 <When using second battery pack> Remove the second battery pack. ( Replacing the Battery Pack) 3. Slide the cover (E) to the arrow direction. 4. Open the cover (E). 5. Push the nanoSIM card. It will come out of the slot a little bit. 6.
  • Page 69 eSIM/nanoSIM Switching 1. Click (Start) - [Settings] - [Network & internet]. 2. Click [Cellular]. 3. Click [SIM 1] or [SIM 2] in “Use this SIM for cellular data”. [SIM 1]: nanoSIM [SIM 2]: eSIM Connect/Disconnect to a network Connecting to a network If the APN setting is completed automatically after inserting the nanoSIM card, Internet connection will be possible.
  • Page 70 To use the “Panasonic PC GPS Viewer”, proceed the following operation. 1. Click (Start) - [All apps] - (Panasonic PC GPS Viewer). You can start up “Panasonic PC GPS Viewer” from Panasonic PC Settings Utility. Launch Panasonic PC Settings Utility, and then click (Utilities) - (GPS Viewer). NOTE Communication is established through the GPS antenna (A).
  • Page 71 Due to the effect of a phenomenon that weekly information transmitted by GPS is reset (GPS Week Number Rollover), wrong date values are output from the GPS module on and after the date shown on the table below. Because of this, apps, etc. that use date information from GPS will be affected by GPS Week Number Rollover.
  • Page 72 Pass Through to External Antenna <Only for model with External Antenna Connector> This computer can utilize up to 4 external antenna signals such as wireless WAN that are passed through to the computer. When [Wireless Antenna Switching] is set to [Auto] and the computer is connected to the vehicle dock, the external antenna signal passed through to the computer will be used.

  • Page 73: Saving Power

    Saving Power You can extend battery life and save power also during AC adaptor usage. Reducing Power Consumption Use the methods below to reduce power consumption. Change the Power mode to [Best power efficiency]. 1. Right-click on the taskbar corner, and click [Power and sleep settings]. 2.
  • Page 74 3. Click [Change plan settings] of the power plan you want to change. 4. Change the settings. [Change advanced power settings]: You can make more detailed settings. 5. Click [Save changes]. Creating Your Own Power Setting 1. Click (Start) - [All apps] - [Windows Tools] - [Control Panel]. 2.

  • Page 75: Security Measures

    Do not forget your password. If you forget your Supervisor Password, you will not be able to use your computer. Contact Panasonic Technical Support. When running the Setup Utility, do not leave and go away from your computer even for a short time, since other people may set or change the password.
  • Page 76 The password will not be displayed on the screen. If the [Caution] screen appears when entering the password, check the status of Num Lock and Caps Lock. You can use up to 32 alphanumeric characters (including spaces). The case (upper/lower) is distinguished. Use only the upper horizontal row of numeric keys to input your password.
  • Page 77 The fingerprint recognition for Windows Hello is supported. To use Windows Hello, perform the following steps for setup. 1. Click (Start) - [Settings]. 2. Click [Accounts] - [Sign-in options]. 3. Click [Fingerprint recognition (Windows Hello)] - [Set up]. 4. Follow the on-screen instructions. NOTE Register at least two fingers.

  • Page 78: Device Encryption

    NOTE The [Password On Resume] of Setup Utility is effective when the computer was once shut down, and not effective when the computer resume from sleep. If the Supervisor Password or User Password has been set, the password input screen will be displayed on starting-up of the Setup Utility even though [Password On Boot] and/or [Password On Resume] is set to [Disabled].
  • Page 79 Other security measure About Secure Boot “Secure Boot” is a function that protects your computer by prohibiting Operating System other than those permitted under factory default con- ditions from being executed during startup. When performing [Clear Secure Boot Keys] to use Secure Boot. <When using the function of Microsoft_DeviceGuard/CredencialGuard>...

  • Page 80: Change The Settings

    Concealed Mode You can make your computer inconspicuously using the concealed mode. You can select on/off of LCD Backlight, LED, Sound, Wireless Radio, Backlit Keyboard (only for model with backlit keyboard) and Touchscreen. IMPORTANT [Concealed Mode] is set to [Enabled] as the factory default. The camera indicator cannot be turned off.
  • Page 81 Waves MaxxAudio Waves MaxxAudio is an application that adjusts the sound output of speakers or headset jack using an equalizer function or noise reduction function. NOTE Waves MaxxAudio is enabled as factory default, so it does not require the startup operation. Depending on the model, [HandsFree Conference] or [Standard] that places importance on conversation has been preset as default.
  • Page 82 [Movie & Music]: This setting places importance on the sound quality by raising the volume of low-tone range. NOTE The preset cannot be changed while headphones are used. Depending on the model, the preset that is selected as default may differ. E.
  • Page 83 The Panasonic PC Day Night Mode Utility starts up, and the following screen is displayed. A. Manual Switch between [Day Mode] and [Night Mode]. With the factory default, when [Manual] of “Panasonic PC Day Night Mode Utility” is selected, ≪ Fn≫ + ≪ 3≫ or button is enabled.
  • Page 84 1. Click (Start) - [Settings] - [System] - [Display]. 2. Set [Night light] to [Off]. 3. Click [Brightness], and remove the check mark from [Change brightness automatically when lighting changes].

  • Page 85: Starting The Setup Utility

    Setup Utility You can make the settings of the computer's operating environment (password settings, startup drive selection, etc.) Starting the Setup Utility 1. Click (Start) - [Settings] - [System] - [Recovery]. 2. Click [Restart now] in “Advanced startup”. 3. Click [Restart now] on the “We’ll restart your device so save your work” screen. 4.
  • Page 86 Docking Device Information Docking Device Computer information (cannot be changed.) Model No. Serial No. PD Controller Enter the sub-menu. Expansion Areas Sub-menu (Expansion Areas) Expansion Areas Rear Expansion Area Computer information (cannot be changed.) Model No. Serial No. Right Expansion Area Computer information (cannot be changed.) Model No.
  • Page 87 Accumulative Operating Time Computer information (cannot be changed.) Access Level Main Menu Underlined items are the factory presets. System Date [xxx xx/xx/xxxx] Day of the Week, Month/Day/Year. You can use ≪ Tab≫ to move the cursor. System Time [xx:xx:xx] 24-hr. style. You can use ≪...
  • Page 88 Sound Can be changed only when [Concealed Mode] is set to [Enabled]. Wireless Radio Can be changed only when [Concealed Mode] is set to [Enabled]. Backlit Keyboard Only for model with Backlit Keyboard. Can be changed only when [Concealed Mode] is set to [Enabled]. Touchscreen Can be changed only when [Concealed Mode] is set to [Enabled].

  • Page 89: Advanced Menu

    Toggle Color 4 Green Blue White Custom Custom 0 to 255 Green Blue Can be changed only when [Toggle Color 4] is set to [Custom]. Specify [Red], [Green], and [Blue] colors with numbers from [0] to [255], or use ≪ F5≫ /≪ F6≫ keys to set them. Backlight Timeout (seconds) On Battery Power None...
  • Page 90 Intel(R) VT-d Disabled Enabled Can be changed only when [Intel(R) Trusted Execution Technology] is set to [Disabled]. Intel(R) Trusted Execution Technology Disabled Enabled Can be changed only when [Intel(R) VT-d] is set to [Enabled]. Intel(R) Total Memory Encryption Disabled Enabled Peripheral Configuration Enter the sub-menu.
  • Page 91 Wireless Antenna Switching PC(built-in) Auto Channel 1 <Only for model with GPS on wireless WAN> WWAN-main Can be changed only when [Wireless Antenna Switching] is set to [Auto]. NONE <Only for model with dedicated GPS> WWAN-main NONE Channel 2 <Only for model with GPS on wireless WAN> WWAN-GPS Can be changed only when [Wireless Antenna Switching] is set to [Auto].
  • Page 92 Boot from a device or not can be selected at [UEFI Priorities], device by device. You can select the boot device during start-up of the computer, too. Press ≪ Esc≫ key soon after “Panasonic” boot screen is displayed. “Boot Menu” appears and you can select the device. To use this function, set [Boot Popup Menu] to [Enabled].
  • Page 93 Boot Prompt Configuration Boot Popup Menu Disabled Enabled Password On Boot Disabled Enabled The shutdown when the fast startup is enabled, this function is ineffective. Password On Reboot Disabled Same as Boot Password On Resume Disabled Enabled Can be changed only when [Password On Boot] is set to [Enabled]. This function is effective when the computer is restarted after a shutdown (when fast startup is enabled) and when the computer resumes from hiberna- tion, but not when it resumes from sleep.
  • Page 94 Enabled Absolute Persistence(R) Module Disabled Absolute(R), formerly Absolute Computrace(R), is a service designed to help Permanently Disabled track devices and provide recovery services in the event a device is lost or stolen. *1 : When [Permanently Disabled] is selected, this setting cannot be used again. Enter the sub-menu.

  • Page 95: Handling And Maintenance

    Handling and Maintenance Operation environment Place the computer on a flat stable surface not subject to shock, vibration, and danger of dropping. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged. Operating environment Temperature: Operation : -10 °C to 50 °C {14 °F to 122 °F} (IEC60068-2-1, 2)

  • Page 96: Handling The Screen

    Touching the screen with an object other than the pen (included) or your fingertip (a fingernail or metal object, or other hard or sharp objects that may leave a mark) may scar or stain the surface, causing the malfunction. Do not apply too much pressure when operating the screen. Only a light touch is required to operate the screen.

  • Page 97: Maintenance

    Before using wireless LAN/Bluetooth/wireless WAN, make the appropriate security settings such as data encryption. When the battery indicator does not light on The battery indicator may not light on even if the AC adaptor and the battery pack are correctly connected to the computer, due to the following reasons. The AC adaptor’s protection function may be working.
  • Page 98 Do not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc. Do not use commercially available household cleaners and cosmetics, as they may contain components harmful to the surface. Do not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause malfunction or damage.

  • Page 99: Optical Disc Drive

    Optical Disc Drive <Only for model with optical disc drive> NOTE Connect the AC adaptor if writing operation takes a long time. If the remaining battery power becomes low and the power is not supplied, writing operation may not be completed. You need to use writing software to write to discs (e.g.
  • Page 100 Do not use a cloth. Disc Information Data transfer speeds indicate values measured by Panasonic Connect Co., Ltd. The data transfer rate of DVD per 1X speed is 1,350 KB/s. The data transfer rate of CD per 1X speed is 150 KB/s.
  • Page 101 Reading Format Continuous Data Transfer speed CD-ROM 24 X (Max) CD-R (XA Compatible) 24 X (Max) CD-RW 24 X (Max) High-Speed CD-RW 24 X (Max) Ultra-Speed CD-RW 24 X (Max) DVD-ROM (Single Layer, Dual Layer) 8 X (Max) DVD-R (1.4 GB, 2.8 GB, 3.95 GB, 4.7 GB) 8 X (Max) DVD-R DL (8.5 GB) 8 X (Max)

  • Page 102: Inserting/Removing A Disc

    Format Continuous Data Transfer speed Recommended discs for writing Discs you can use for writing DVD-R DL 6 X (Max) MITSUBISHI CHEMICAL MEDIA DVD-R DL CO.,LTD. 2-8X-SPEED (8.5 GB) DVD-RW 6 X (Max) 1-2X-SPEED (4.7 GB/9.4 GB) 2-4X-SPEED (4.7 GB/9.4 GB) 2-6X-SPEED (4.7 GB/9.4 GB) DVD-RAM 5 X (Max)

  • Page 103: Power Saving Mode

    3. Press the eject button (C) and slowly pull out the tray. When inserting or removing a disc, be careful not to touch the lens and other parts of the laser pickup (D). Do not touch the disc surface (the side with no printing).

  • Page 104: Movie Disc Playback

    Movie Disc Playback Installing PowerDVD PowerDVD is a software application for DVD/BD playback. Install “PowerDVD” using “DVD Drive Utility Disc” or “BD Drive Utility Disc”. 1. Sign in to Windows as an administrator. 2. Set “DVD Drive Utility Disc” or “BD Drive Utility Disc” in the drive. 3.

  • Page 105: Region Codes

    When playing videos recorded on rewritable discs, approx. 40 to 50 seconds may be required to recognize the disc. Wait for the required time. Depending on the condition (record quality, cracks, dirt, modification, copy protection, type of drive/disc maker used when creating the disc, etc.) of a disc, it may not be possible to be read or play it correctly.

  • Page 106: Using Power2Go

    Writing to CD/DVD/BD Applicable media Refer to the Disc Information. Refer to the software’s online manual (below). About Copies When writing to discs, make sure that you are not infringing upon any copyrights. It is illegal to copy commercially available audio CDs for non-per- sonal use.
  • Page 107 1. Click (Start) - [All apps] - [CyberLink Power2Go x.x for Panasonic] - [CyberLink Power2Go x.x for Panasonic] *11 : x.x indicates the version number. IMPORTANT If you format a disc using Windows functions, you cannot write with Power2Go. Do not format a disc using Windows functions when you write to the disc using Power2Go. For rewritable discs (i.e. CD-RW, etc.), writing is possible using Power2Go if all the disc contents are deleted.
  • Page 108 1. Set the disc in the optical disc drive. 2. Close all applications that use the disc. 3. Right-click (Start) - [File Explorer]. 4. Click [This PC]. 5. Right-click the optical disc drive, and click [Format...]. 6. Select the settings and click [Start]. When the disc was recorded with Power2Go and you want to record using Explorer, remove the check mark from [Quick Format].

  • Page 109: Microsd Memory Card

    Note that Panasonic assumes absolutely no liability for any loss of data recorded by the user, or any other damages, direct or indirect.
  • Page 110 Removing the card Preparation Save the data and close all applications. Open the cover and confirm the microSD memory card indicator is off. 1. Disable the card function. 1. Click on the taskbar corner and click 2. Select the card. These steps are not necessary when: Removing the card after turning off the computer.
  • Page 111 6. Slide the cover (E) to the arrow direction. IMPORTANT After pressing the microSD memory card, do not release your finger suddenly. The microSD memory card may jump out.

  • Page 112: Smart Card

    Smart Card <Only for model with Smart Card slot/2nd Smart Card slot> You need software to use a Smart Card. IMPORTANT Do not: Hit, bend, or drop the card. Touch the contact part with fingers or metal object. Place the card in very hot location for a long time. Remove the card immediately after inserting it.
  • Page 113 6. Slide the latch (E) to the arrow direction to lock the cover. <Only for model with 2nd Smart Card slot> 1. While sliding the latch (F) to the arrow direction, open the cover (G). 2. Insert the Smart Card until it surely fits in the slot. Smart Card must be inserted with the chip portion (H) facing up.
  • Page 114 6. Close the cover (L) until it clicks. 7. Slide the latch (M) to the arrow direction to lock the cover. <Only for model with 2nd Smart Card slot> 1. While sliding the latch (N) to the arrow direction, open the cover (O). 2.

  • Page 115: Ram Module

    RAM Module Use RAM modules that comply with the specifications ( Specifications). Using any other module may cause malfunction or result in computer fail- ure. IMPORTANT Use recommended RAM module products. Do not use non-recommended RAM modules. Non-recommended RAM modules may not operate properly, and may cause damage to your computer.
  • Page 116 NOTE Confirm that the RAM module is fixed with the hooks (E) as shown below. 3. Remove the release paper (F) of the sheet supplied with the recommended RAM module. 4. Firmly attach the RAM module and the seal (G). 6.
  • Page 117 If the RAM module is recognized correctly, the total size of the main unit memory and RAM module memory is displayed on [Information Menu] of the Setup Utility. If the RAM module is not recognized, power off the computer and insert it again.

  • Page 118: External Display

    External Display HDMI Port You can switch the output destination to an external HDMI display. 1. Slide the cover (A) to the arrow direction. 2. Open the cover (A). 3. Connect the HDMI port (B) and the HDMI display using an HDMI cable. <Only for model with 2nd HDMI port>...
  • Page 119 3. Connect the VGA port (H) and the external display using a VGA cable. NOTE If you connect VGA display after connecting high resolution HDMI display, such as 4K display, images could not be displayed. In such cases, connect VGA display first, and then connect high resolution HDMI display. USB Type-C Port You can switch the output destination to an external display.

  • Page 120: Switching The Display Mode

    Switching the display mode Using key function 1. Press ≪ ≫ key + ≪ P≫ or ≪ Fn≫ + ≪ F3≫ . 2. Select the display mode. Using the [Display settings] 1. Click (Start) - [Settings] - [System] - [Display]. 2.
  • Page 121 While using an extended desktop or [Second screen only], you cannot operate the external display screen with touch oper- ation. Set the internal LCD to the primary display when using the touchscreen. The cursor will move on the primary display when you touch the internal LCD.

  • Page 122: Usb Devices

    USB Devices Features of the Supported Standards USB 3.2 (Type-A) port Support USB 3.2 (Gen 1 *1 : Rear side *2 : Right side USB Type-C Port The features of the supported standards are as follows. USB Power Delivery ( USB Power Delivery) Thunderbolt 4...
  • Page 123 3. Connect the USB device to the USB 3.2 (Type-A) port (E) on the computer. <Only for model with 2nd USB port/3rd USB port> 1. Slide the latch (F) to the arrow direction. 2. Open the cover (G). 3. Connect the USB device to the USB 3.2 (Type-A) ports (H) or (I) on the computer. Removing the USB device 1.

  • Page 124: Charging Usb Devices

    If the computer enters sleep while an external keyboard or external mouse is connected, touching the external keyboard keys or external mouse will resume the computer. Charging USB Devices The computer comes with a USB port to provide efficient charging to smart phones or portable devices that can use USB port charging. This computer’s USB Type-C port allow USB devices to be charged efficiently even if the computer is turned off or in the sleep/hibernation state.

  • Page 125: Serial Port

    Serial Port <Only for model with Serial Port> Connecting Serial device 1. Slide the latch (A) to the arrow direction. 2. Open the cover (B). 3. Connect the serial device to the serial port (C). 4. Connect the serial device to the connector of the serial cable. NOTE When connecting a cable, be sure to secure it with screws (D).

  • Page 126: Using The Camera

    When the computer has resumed from sleep and hibernation, an error may appear and the connection with the camera device may be lost. If this occurs, restart this utility. Panasonic PC Camera Utility only with the built-in camera. It does not support a camera connected to the computer. Starting up 1.
  • Page 127 A. Open the camera settings B. Preview screen C. Display the folder where recorded data is saved D. Shoot photos E. Start/Stop shooting videos F. Hide the mode menu G. Night Mode switching H. Zoom Shooting Photos and Videos Shoot photos 1.

  • Page 128: Changing The Settings

    Display the recorded image or video 1. Click files The recorded data will be saved in the displayed folder named the recording date. Zoom To enlarge or reduce the camera image. 1. Use the Zoom slider for adjustment. If the slider is not displayed, click Changing the Settings 1.
  • Page 129 Add geolocation and time stamps to still images. J. Adding a geotag Add geotagging to the Exif data of still images. K. Photo storage folder Specify the destination of recorded photo data to save. The default value is the “Pictures” folder. L.

  • Page 130: Barcode Reader

    (Start) - [All apps] - (Panasonic PC 2D Barcode Key Emulator). 2. Click on the taskbar corner, and then click (Panasonic PC 2D Barcode Key Emulator) - [Connection to Barcode (Always-On)]. Reading Barcodes IMPORTANT Do not look directly into the reading window.
  • Page 131 If the barcode is read successfully, the code appears where the cursor is placed. NOTE When the barcode read operation is finished, please wait about 3 seconds to start the next reading. You may press the button immediately, even if you set to release, it takes several seconds to light to light actually. If an error message appears and nothing is displayed, restart this utility.

  • Page 132: Cleaning The Reading Window

    Barcode Reader Light Barcode Reader Light Cleaning the Reading Window If the reading window is dirty, gently wipe the reading window with a cloth or a cotton swab moistened with water. Do not allow materials that can easily scratch the reading window to touch the window, such as sandpaper or metal object. For parts other than the reading window, please read “Handling and Maintenance”.

  • Page 133: Contactless Smart Card Reader

    Contactless Smart Card Reader <Only for model with Contactless Smart Card Reader> You can read the data from RFID (Radio Frequency Identification) tags / Contactless Smart Card. Precautions NOTE This reader is typically used with specialized applications. For further information, ask the system administrator. Contactless Smart Card Reader Location 1.

  • Page 134: Fingerprint Reader

    Fingerprint Reader <Only for model with Fingerprint Reader> Fingerprint Authentication Function Use fingerprint authentication to improve security and convenience by replacing the conventional password entry required to sign in to windows. Fingerprint Reader Location Fingerprint Authentication Function Features You can use the fingerprint authentication function by using the Windows Hello. Pre-boot authentication (PBA) Perform fingerprint authentication before the computer starts up.
  • Page 135 To erase all fingerprint data when transferring or disposing the computer: Select [Clear the fingerprint data] in [Fingerprint Security] in the [Security] menu of the Setup Utility, and select [Yes]. Fingerprint Reader Handling Avoid the following. Failure to do so may result in malfunction or damage to the fingerprint reader. Do not rub or scratch the reader with hard materials or poke it with small pointed objects that could cause scratches.
  • Page 136 SSD Pack Attaching/Detaching the SSD pack You can replace the SSD pack. IMPORTANT Back up all the important data before detaching the SSD pack. Carefully attach/detach the SSD pack since the SSD pack is extremely sensitive to shock. Note that static electricity may affect some internal components.
  • Page 137 4. Pull the tab (C) and pull out the SSD pack (D). <Only for model with 2nd SSD pack> 1. While sliding the latch (E) to the arrow direction, open the cover (F). 2. Remove the screw (G) and slide the latch (H) until the orange-colored sign appears in the indicator (I). Use the PH 1 (PH #1) screwdriver.
  • Page 138 4. Slide the latch (N) to the arrow direction. <Only for model with 2nd SSD pack> 1. Insert the SSD pack (O) until it securely fits the connector. 2. Slide the latch (P) until the orange-colored sign disappears in the indicator (Q) and tighten the screw (R) firmly. Use the PH 1 (PH #1) screwdriver.
  • Page 139 Erasing SSD Pack Data You can erase the data before changing the SSD pack. 1. Select [Start “Secure Wipe”] in the sub-menu of [Secure Wipe] in the [Security] menu of the Setup Utility.

  • Page 140: Port Replicator

    Port Replicator You can use an optional port replicator. This device frees you from being bothered by a lot of cable connections when you carry the computer. It also allows you to connect various peripherals. Connect the port replicator to the expansion bus connector (A) on the bottom of the computer. Read the instruction manual of the port replicator before using.

  • Page 141: Connecting/Disconnecting The Computer

    It is not compatible with the analog display. The display specifications of the maximum resolution, etc. that can be output differ according to the specifications of the device con- nected. For details, refer to the specifications of the device connected. G.
  • Page 142 Do not attempt to move the port replicator while the computer is being connected to the port replicator. If the computer malfunctions while the port replicator is attached, disconnect the port replicator and check to see if the com- puter operates normally. If the computer operates normally, the port replicator may be malfunctioning. Contact Panasonic Technical Support.
  • Page 143 If the computer malfunctions while the port replicator is attached, disconnect the port replicator and check to see if the computer operates normally. If the computer operates normally, the port replicator may be malfunctioning. Contact Panasonic Technical Support. 4. Lift up the computer to remove it from the port replicator.
  • Page 144 Incorrect...

  • Page 145: Attaching The Shoulder Strap

    Shoulder Strap Attaching the straps helps you stably hold the computer. Attaching the Shoulder Strap 1. Attach the D-rings (A) and tighten the screws (B). NOTE Attach the D-ring to the front side or rear side. Use the two D-rings and two screws supplied with the shoulder strap. Use the PH 2 (PH #2) screwdriver.
  • Page 146 Use the shoulder strap so that the shoulder pad (E) faces inward. IMPORTANT Do not use the shoulder strap for other purposes such as use as a neck strap.

  • Page 147: Battery Charger

    Battery Charger The battery charger is designed for charging the battery pack for the Panasonic computer series. To recharge a battery pack, you will need the AC adaptor and AC cord included with this product. Read both this Operating Instructions and the operating instructions of the battery charger before using.

  • Page 148: Charging The Battery Pack

    Charging the battery pack 1. Connect the AC adaptor. 2. Insert the battery pack(s). Insert the battery pack firmly with its battery connector (B) facing the indicator (A) of the charger. IMPORTANT Do not insert the battery pack at an angle. The terminal of the battery charger may be damaged. Incorrect If the battery pack got lodged in the slots, push the middle of the battery pack.
  • Page 149 The battery indicator lights when the battery pack is properly inserted with the AC adaptor connected. Four battery packs can be inserted simultaneously. Each of them can be inserted in any slot. When removing the battery pack, pull it out in the opposite direction of attaching the battery pack. Charging begins automatically.

  • Page 150: Troubleshooting

    Troubleshooting Refer to the following instructions when a problem occurs. If the remedies indicated in the chart do not solve the problem, contact Panasonic Technical Support. For a software problem, refer to the instruction manual of the software. Refer to Checking the Computer’s Usage...
  • Page 151 Other startup problems. Start in the Setup Utility ( Setup Utility) to return the Setup Utility settings (excluding the passwords) to the default values. Start the Setup Utility and make the settings again. Remove all peripheral devices. Check to see if there was a disk error. 1.
  • Page 152 Select [Enabled] in [Password On Resume] in the [Security] menu of the Setup Utility. [Enter Password] does not appear when resuming from sleep/hibernation. The Windows password can be used instead of the password set in the Setup Utility. To add a password, set up the following. 1.
  • Page 153 When using the Extended Desktop, use the same display colors for the external display as During Simultaneous display, one of the those used by the LCD. If you continue to experience problems, try changing the display. screens becomes disordered. If the external display does not support the power saving function, it may not work normally The external display does not work nor- when the computer enters the power saving mode.
  • Page 154 To stop microphone’s monitoring output. The feedback noise may occur. 1. Right-click (Speakers) on the taskbar corner, and click [Sound settings] - [More sound settings]. 2. Click [Recording] - [Microphone Array] - [Properties], and then remove a check mark for [Listen to this device] in [Listen]. Keyboard Only numbers can be input.
  • Page 155 Network Set the device ([LAN] [LAN (2nd)] [Wireless LAN] [Wireless WAN]) to [Enabled] in the Cannot connect to a network. [Advanced] menu of the Setup Utility. Follow the steps below. Cannot check the computer’s MAC address. 1. Click (Start) - [Settings]. 2.
  • Page 156 Install the driver. A peripheral device does not work. Contact the manufacturer of the device. When operation resumes from sleep or hibernation, devices such as an external mouse and cards may not function properly. In this case, restart the computer or reinitialize the device. When is displayed in the Device Manager, remove and insert the device.
  • Page 157 <Only for model with wireless LAN> You can check the Wireless LAN status. ( Wireless LAN) Wireless LAN does not work. Set airplane mode to OFF. Airplane mode Confirm that Wireless LAN (Wi-Fi) is [On]. If a USB 3.2 compatible device is used, Wireless LAN Antenna may not be correctly received. In this case, do any of the following.
  • Page 158 Handling. The fingerprint reader may be malfunctioning when it continues to perform poorly after the steps described above have been performed. Contact Panasonic Technical Support. If none of your enrolled fingers can be used, follow this procedure: User cannot use enrolled finger. (e.g.

  • Page 159: Checking The Computer's Usage Status

    “Not use” is not a malfunction. Connect the AC adaptor for a while. Checking the Computer’s Usage Status You can check the computer’s usage status in the PC Information Viewer. You may need this information when calling Panasonic Technical Support for advice.
  • Page 160 The screen image is saved in “Screenshots” folder under “Pictures” folder.

  • Page 161: Hardware Diagnostics

    If it appears that the hardware installed in this computer is not operating properly, you can use the PC-Diagnostic Utility to determine whether or not there is a problem. If the utility discovers a problem in the hardware, contact Panasonic Technical Support. Software cannot be checked using this utility.
  • Page 162 At the confirmation message, select [Yes] and press ≪ Enter≫ . The computer will restart. 5. Press ≪ F2≫ or ≪ Del≫ while “Panasonic” boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.
  • Page 163 If the display is red and the message “TEST FAILED” is displayed, you can assume that there is a problem with the computer's hardware. Con- firm which hardware component is displayed as red, and contact Panasonic Technical Support. If the display is green and the message “TEST PASSED” is displayed, the computer's hardware is operating normally. Continue using the com- puter as it is.
  • Page 164 8. After the diagnostic check is complete, click (close), or press ≪ Ctrl≫ + ≪ Alt≫ + ≪ Del≫ to restart the computer. When the Icon Becomes Invisible or Gray, and the Corresponding Device Cannot Be Checked The device is disabled in the Setup Utility: Set the device to [Enabled] in the Setup Utility.

  • Page 165: Reset Your Computer

    Reset your computer If operations on the unit become unstable, we recommend refreshing Windows. This involves reinstalling the operating system with personal files and settings retained (Personalization). Preparation Remove all peripherals and microSD memory card, etc. Connect the AC adaptor and do not remove it until installation is complete. 1.
  • Page 166 5. Click [Refresh] under “Actions” on the right of the “Trusted Platform Module (TPM) Management on Local Computer” screen. 6. When “The TPM is ready for use.” appears in “Status” item, close the “Trusted Platform Module (TPM) Management on Local Com- puter”...

  • Page 167: Installing Software

    At the confirmation message, select [Yes] and press ≪ Enter≫ . The computer will restart. 4. Press ≪ F2≫ or ≪ Del≫ while “Panasonic” boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.

  • Page 168: Using Recovery Disc

    Do not interrupt installation, for example by turning off the computer or performing other operation. Otherwise installation may become unavailable as Windows may not start up or the data may be corrupted. 10. When the Ending process screen is displayed, click [Shutdown.] to turn off the computer. 11.
  • Page 169 At the confirmation message, select [Yes] and press ≪ Enter≫ . The computer will restart. 5. Press ≪ F2≫ or ≪ Del≫ while “Panasonic” boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.

  • Page 170: Error Message

    Error Message Follow the instructions below when an error message appears. If the problem persists or if the error message is not shown here, contact Panasonic Technical Support. Error Message Solution Bad System CMOS An error has occurred in the memory of system settings. This occurs when the memory content is changed by an unexpected program operation, etc.

  • Page 171: Technical Information

    Technical Information Network Connections and Communications Software The sleep mode of this computer supports the modern standby mode. ( Modern Standby) When an application supports the modern standby mode, it can periodically connect to the network even during sleep. If the computer enters sleep or hibernation while you are using an application that does not support the modern standby mode, the network connection may be interrupted or the performance may be adversely affected.

  • Page 172: Hard Disk Data Erase Utility

    There are also specialized devices that may be able to read data that has been erased using this method. If you need to erase highly confidential data, contact a company that specializes in this process. Panasonic Connect Co., Ltd. will bear no responsibility for damages suffered as a result of the use of this utility.
  • Page 173 At the confirmation message, select [Yes] and press ≪ Enter≫ . The computer will restart. 5. Press ≪ F2≫ or ≪ Del≫ while “Panasonic” boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.
  • Page 174 Dispose of Computer Preparation Remove all peripherals and microSD memory card, etc. Erase the stored data. ( Erasing data when disposing or transferring the computer) When disposing of this product, accord with your national legislation.

  • Page 175: Main Specifications

    Specifications This page provides the specifications for the basic model. The model number is different according to the unit configuration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the flash memory drive (SSD) size: Run the Setup Utility ( Setup...
  • Page 176 30 % to 90 % RH (No condensation) Software Operating System Windows 11 Pro PC Information Viewer Pre-installed Software Panasonic PC Recovery Disc Creation Utility Microsoft Office Trial Emergency notification setting Panasonic PC Camera Utility Panasonic PC GPS Viewer Panasonic PC Manual Selector...

  • Page 177: Optional Devices

    Wireless LAN IEEE802.11a : 54 Mbps Data Transfer Rates IEEE802.11b : 11 Mbps IEEE802.11g : 54 Mbps IEEE802.11n : HT20 : 144.4 Mbps HT40 : 300 Mbps IEEE802.11ac : VHT20 : 173.3 Mbps VHT40 : 400 Mbps VHT80 : 866.7 Mbps VHT160 : 1.73 Gbps IEEE802.11ax : HE20 : 287 Mbps...
  • Page 178 2nd LAN IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE 802.3ab 1000BASE-T Right Expansion Area Smart Card Slot × 1 Battery Pack (Second Battery) Li-ion 10.8 V, 6300 mAh Approx. 36 hours (with Main Battery + Second Battery) Operating Time Charging Time Power Off: Approx.

  • Page 179: For Europe

    *24: Depending on the models, this application software is not installed. *25: Only for model with dedicated GPS. *26: Panasonic PC Settings Utility includes the following functions: Touchscreen Mode / Programmable Buttons/Keys / etc. *27: Only for model with Barcode Reader.
  • Page 180 Declaration of Conformity (DoC) “Hereby, Panasonic declares that this computer is in compliance with the essential requirements and other relevant provisions of the Directive 2014/53/EU.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: https://www.ptc.panasonic.eu/...

  • Page 181: Software License

    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. Please refer to the detailed terms and conditions below. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL V2.1 or the other licenses with the obligation to do so, as well as the respective copyright notice thereof.
  • Page 182 1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty;...
  • Page 183 8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that dis- tribution is permitted only in or among countries not thus excluded.
  • Page 184 Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. [This is the first released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2, hence the version number 2.1.] Preamble The licenses for most software are designed to take away your freedom to share and change it.
  • Page 185 "Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library.
  • Page 186 You must give prominent notice with each copy of the work that the Library is used in it and that the Library and its use are covered by this License. You must supply a copy of this License. If the work during execution displays copyright notices, you must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this License.

  • Page 187: Openssl License

    Each version is given a distinguishing version number. If the Library specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation.
  • Page 188 * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright *     notice, this list of conditions and the following disclaimer. * 2.
  • Page 189 * This product includes cryptographic software written by Eric Young * (eay@cryptsoft.com). This product includes software written by Tim * Hudson (tjh@cryptsoft.com). Original SSLeay License ----------------------- /* Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) * All rights reserved. * This package is an SSL implementation written * by Eric Young (eay@cryptsoft.com).
  • Page 190 * THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND * ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE * ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE * FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL * DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS * OR SERVICES;...
  • Page 191 Simon-Pierre Cadieux Eric S. Raymond Gilles Vollant and with the following additions to the disclaimer: There is no warranty against interference with your enjoyment of the library or against infringement. There is no warranty that our efforts or the lib- rary will fulfill any of your particular purposes or needs.
  • Page 192 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Con- nect Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.

  • Page 193: Warranty

    This warranty does not cover failures or defects that are caused by fire, intentional acts, loss, theft, improper maintenance, modification or service by anyone other than a Panasonic Authorized Service Provider, or damage that is attributable to acts of God. Cosmetic damage that does not affect func- tionality is not covered.
  • Page 194 All modems must be approved by the wireless carrier prior to use. Any use or attempted use of a wireless modem not approved and activated by the car- rier for use on their network is strictly prohibited and is not sanctioned or warranted by Panasonic and may result in legal action. In addition, all modems must be approved by Panasonic as compatible with the device hardware before installation or use.

  • Page 195: For Canada

    Panasonic will not be responsible for any liability resulting, and in any way for any damages or loss resulting from the use of this product arising out of the foregoing uses.
  • Page 196 Panasonic will not be responsible for any liability resulting, and in any way for any damages or loss resulting from the use of this product arising out of the foregoing uses.

  • Page 197: Pour Le Canada

    GARANTIE LIMITÉE – ORDINATEURS ET PÉRIPHÉRIQUES PANASONIC Couverture - Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que ce produit informatique (à l’exclusion des supports des logiciels) est, au moment de sa vente par PCI ou d’un revendeur agréé par PCI, exempt de défauts de pièces et de fabrication dans les conditions normales d’utilisation, et ce, pendant la période de couverture de la garantie, sous réserve des modalités décrites ci-dessous.
  • Page 198 GARANTIE LIMITÉE – SUPPORTS DES LOGICIELS Couverture – Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que la ou les disquettes ou tout autre support sur lequel le ou les pro- grammes sont fournis sont exempts de défauts de pièces et de fabrication dans des conditions normales d’utilisation au Canada, et ce, pour une péri- ode de soixante (60) jours suivant la date de réception indiquée sur la preuve d’achat.
  • Page 199 Panasonic can not be held responsible in any way for any damage or loss resulting from the use of this unit in these types of equipment, devices or sys- tems, etc.
  • Page 200 Purchaser, its quality, performance, merchantability, or fitness for a particular purpose. Panasonic does not warrant that the functions contained in the software will be uninterrupted or error free. Panasonic assumes no risk of and shall not in any case be liable for any damages, including, without lim-...
