ULTRA BRIGHT UB-500GE Series Manual

SOLAR POST CAP
UB-500GE-X
See www.ultrabrighttech.com
Solar Post Cap:
Ultra Bright's Solar Post Cap Light is the most
advanced, powerful, robust, solar fence post light
available. Add safety, elegance and ambience to your
deck without the hassle of electrical wiring! Patented
magnet technology allows users to easily adjust
between 7-brightness levels to meet seasonal
performance, brightness, & run preference.
Each side of the light has white, amber, and blue ultra-
high intensity downward shining LEDs that
automatically turn on at dusk and turn off at
dawn. Hold a magnet for 5 seconds over the solar
panel and the solar post cap light will change between
the illuminating colors. Swipe the magnet quickly over
the solar panel to adjust between 7 brightness levels
or "OFF".
PATENTS PENDING
Pictured in white
for other color & size options
4-Season Rated
Copyright Protected Design
Ultra Bright Tech
100 Industrial Dr.
Avilla, IN 46710
LIGHT CHARACTERISTICS
Light Source
Lumens output
Available LED Colors
Light Mode
Visible Range
Horizontal Output (degrees)
Vertical Divergence (degrees)
LED Life Expectancy (hours)
ELECTRICAL CHARACTERISTICS
Circuit Protection
Nominal Voltage (v)
Power / Brightness Levels
Autonomy (hours)
Temperature Range
SOLAR CHARACTERISTICS
Solar Module Type
Power (watts)
Solar Module Efficiency (%)
POWER SUPPLY
Battery Type
Battery Size
Battery Capacity (mAh)
Nominal Voltage (v)
Battery Service Life
Battery Service Access
PHYSICAL CHARACTERISTICS
Body Material
Lens Material
External Lens Design
Internal Lens design
Water Proof Rating
Base Options: (Post Sizes)
Height
Width / Width
Weight
OTHER
Other Options & Sizes
1yr Limited Warranty
Phone: 260-239-0974 / 260-918-2758
E-mail sales@ultrabrighttech.com
Web: www.ultrabrighttech.com
36-Ultra High Intensity LEDs
12-White, 12-Blue, 12-Amber
5 -50 Lumens *Varies with Brightness
Levels
White, Blue & Amber
Constant * Variable Brightness/3 Color
Adjustable with magnet
100m-200m+ (Depending on settings)
360°
180°
> 100,000 hrs
Integrated / Overcharge / Over
Discharge / Constant Current
3.2v Battery, 4v Solar
7 Levels, User Adjustable with Magnet
10-140hrs *On full Charge
* Varies with brightness/color settings
14-158° Fahrenheit
Tempered Glass + Monocrystalline Cell
1.00 Watts
18 % Super High Efficiency Cells
LiFePo4 (Lithium Phosphate)
1pcs IFR 18650E
1,400 mA
3.2v
1-3 years *Varies with local
Environment
Yes: User Changeable / Replaceable
High Performance ASA
Bayer UV Stabilized Poly Carbonate
Smooth / Clear
NA
IP 68 – Sealed - Fully Waterproof
 5.00"x5.00" – (All Brands / Generic)
2-5/8" (67mm)
7" x 7" (178x178mm)
2.1 lbs
Please Contact
* Information subject to change without notice
