- Page 1 CYCLONE SENSOR Wind Speed Rain Readings Solar Panel Now with dual tipper for improved accuracy Assisted Power Wind Direction Easy-to-Install TX145WSDR Mounting Bracket...
-
Page 2: Initial Setup
Initial Setup Installing the Wind Cups (if needed) 2. Align the flat edges and place the Wind 1. Remove the Cyclone Sensor, Wind Cups, Cups on top of the Cyclone Sensor. and Mini Screwdriver from the package. Take note of the flat edges located on the head of the Cyclone Sensor and underside of the Wind Cups. -
Page 3: Sensor Placement & Mounting
Sensor according to polarity. Sensor Placement & Mounting For Accurate Cyclone Sensor Measurements • Use the built-in Bubble Level to ensure the Cyclone Sensor (especially the rain gauge) is mounted level. • Ensure the Solar Panel is facing to the South. This helps optimize battery life and transmit correct wind direction data. - Page 4 Cyclone Sensor Mounting Basic Installation Fence posts, poles, decks, and mailboxes are common mounting options due to their convenience. Many users prefer these types of locations as the data they provides is accurate from their ground level. However, because the wind in these spots is often affected by obstructions, the readings may differ when compared to local reporting stations.
- Page 5 Cyclone Sensor Mounting Flexible Installation Hand Screw Install the Hand Screw to the bracket, then This configuration allows you to attach the Secure the Sensor to the Mast by tightening sensor to angled locations and easily make the screws on the side.
-
Page 6: Cleaning The Rain Sensor
4. You should feel the funnel lock into place placing it back into the sensor and twisting when one of the arrows lines up with the center of the Lock/Unlock Line. clockwise until secure. Tip: Remove the Cyclone Sensor’s batteries before cleaning to avoid accidental rain readings. -
Page 7: Specifications
(0 to 9999 mm) • Transmission Range: 330 feet 433MHz (100 meters) open air • Power Requirements: 3 “AA” Batteries (not included) • Update Interval: Every 31 Seconds Follow La Crosse Technology on Facebook, Instagram, YouTube, and Twitter. -
Page 8: We're Here To Help
Representatives are available Monday-Friday, 8am-6pm CST Online: bit.ly/contact_techsupport Phone: 1.608-782-1610 Warranty La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product, relating to manufacturing defects in materials and workmanship. For full warranty details, visit: www.lacrossetechnology.com/pages/warranty La Crosse Technology, Ltd. -
Page 9: Battery Replacement
Battery Replacement Battery Replacement Instructions When batteries of different brand or type are used together, or new and old batteries are used together, some batteries may be over-discharged due to a difference of voltage or capacity. This can result in venting, leakage, and rupture and may cause personal injury.
