TECHNICAL
REFERENCE GUIDE
ACE MUSTANG SERIES
MODEL: T730
ACE159
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T730 and is the answer not in the manual?

Questions and answers

Related Manuals for ACE COMPUTERS T730

Summary of Contents for ACE COMPUTERS T730

  • Page 1 TECHNICAL REFERENCE GUIDE ACE MUSTANG SERIES MODEL: T730 ACE159...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DISCLOSURES ..........................3 INTRODUCTION ...........................4 ENEGY STAR AND POWER MANAGEMENT ..................5 ILLUSTRATED SYSTEM DISASSEMBLY/REASSEMBLY INSTRUCTIONS ..........7 TROUBLESHOOTING YOUR PC ....................16 MAINTENANCE ........................18 SOFTWARE UPDATES ......................19 REMOVAL OF PERSONAL DATA ....................21 UPGRADES, SERVICE, AND REPAIR .....................24 PRODUCT TAKE BACK, END OF LIFE PROCESSING, and E-WASTE PROGRAM ......26 REVISION HISTORY ........................27 ACE159...

  • Page 3: Disclosures

    Ace Computer's total liability for all claims will not exceed the price paid for the hardware product. The products sold by Ace Computers are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

  • Page 4: Introduction

    If you have any questions regarding this manual or computer system, please contact our support team through Ace Computers Support page at support.acecomputers.com This manual may be periodically updated without notice. Please check the Ace Computers website for possible updates to the manual revision level. ACE159...

  • Page 5: Enegy Star And Power Management

    ENEGY STAR AND POWER MANAGEMENT What is Energy Star? Created by the Environmental Protection Agency (EPA) and the United States Department of Energy (DOE), the Energy Star program is a strict set of specifications that residential appliances and construction elements (washers, dryers, refrigerators, freezers, dishwashers, televisions, tablets, computers, monitors, water heaters, HVAC units, dehumidifiers, air cleaners and purifiers, lighting, insulation and more) must meet through evaluation and testing to achieve certification.
  • Page 6 Wake Management Capable of both remote (via network) and scheduled (via real time clock) wake events from Sleep Mode. Provide clients with the ability to centrally manage (via vendor tools) any wake management settings that are configured through hardware settings if the manufacturer has control over such features.

  • Page 7: Illustrated System Disassembly/Reassembly Instructions

    If you are uncertain about replacement or upgrade of your computers, the Ace Computers technical support team does offer “depot” services for on-site system repair and upgrade. Please contact the Ace Computers Technical Support team for additional information and pricing.
  • Page 8 Representative Desktop Component Layout Please note the illustration below is a representative sample of the T730, your PC may include additional components or variations of this family configuration. 1) Camera LED 2) Camera 3) Microphone 4) Touchpad ACE159...
  • Page 9 System Map: Bottom View of T730 Model System Map: Right View of T730 Model 5) Kensington Lock 6) Headphone Combo 7) RJ45 8) USB 3.0 9) Type-c Data only 10) Micro SD 11) Power Button 12) Camera On or Off...
  • Page 10 System Map: Left View of T730 Model 13) Type-c Charging 14) USB 3.0 15) HDMI 16) Type-c 17) Charger Led 18) Smart Card ACE159...
  • Page 11 T730 Disposal/Selective Treatment The following section outlines the components of the T730 that required Selective Treatment/Special Handling Per Annex VII, Directive 2012/19/EU: I/O Connections Heatsink Fan Motherboard Memory Processor HDD/SSD Lithium Ion Battery The HDD, SSD, Memory, Motherboard, Optical Drive, and External Power Supply each contain one printed circuit board of greater than 10 sq.
  • Page 12 Battery Handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.
  • Page 13 on the motherboard within the laptop. Both batteries must be removed separately from the laptop and shall be disposed or recovered in compliance with Directive 2008/98/EC. External Power Cable Location: The inlet to the USB-C power cable is located on the I/O panel on the left view of the laptop.
  • Page 14 Chassis Bottom Cover Removal Location: In order to access the internal components of your system, you will need to remove the bottom cover of the chassis. Type and number of fastenings: 8 Phillips head screws Tools required: Phillips head screwdriver Procedure: Step 1: Ensure the desktop is off, unplugged, and any potential energy is...
  • Page 15 I/O Connections Location: There are two locations on the T730 that have I/O connections. (1) The left-side panel of the laptop (2) The right-side panel of the laptop Procedure: Note: I/O connections are integral parts of higher-level assemblies and thus to replace them the entire assembly would need to be replaced.

  • Page 16: Troubleshooting Your Pc

    TROUBLESHOOTING YOUR PC If your computer will not power on, try the following steps: 1. Make sure the power cord is fully connected to the computer and to the wall outlet. 2. If using a surge protector, try connecting the power cord directly to a wall outlet. 3.
  • Page 17 If your computer freezes or crashes during boot, try the following steps: 1. If Windows seems to boot fine but hangs halfway or blue screens and restarts, it may be a software or hardware problem. Try the following steps: 2. Attempt to boot into safe mode. If the computer is stable in safe mode, try uninstalling any recently installed hardware drivers, perform a system restore, and scan for malware.

  • Page 18: Maintenance

    MAINTENANCE Removing Dust Build Up Dust buildup may lead to overheating and could potentially cause serious damage to your PC components. If fans get clogged with dust, they may begin to turn at a slower RPM reducing the effectiveness of the fan and leading to overheating of the PC. The issue of dust build up is applicable to all fans within the system (e.g.

  • Page 19: Software Updates

    SOFTWARE UPDATES Utilization of the most up to date OS software version and patches will provide the best possible defenses against viruses and malware. Periodic Check for Software Updates Windows will periodically look for and apply critical patches and security updates. Allows your system, during the initial setup of the system, to automatically update, this will provide the most secure user environment.
  • Page 20 Contact Ace Computers Support Desk for help Ace Computers staffs a technical support desk and is always ready to help. You can contact the team at support@acecomputers.com - or- call 877-223-2667 -or- visit the acecomputers.com and click “Support” to start a new support ticket online.

  • Page 21: Removal Of Personal Data

    REMOVAL OF PERSONAL DATA Be sure to back up all information that you desire to keep on alternative drives before deleting data as this process cannot be reversed. Digitally Erasing Information Resetting your PC may be done for various reasons, but one reason may be to remove all your personal information and return the PC to the original settings.
  • Page 22 Option What it Does Removes apps you installed. ▪ Removes changes you made to ▪ settings. Removes any apps your PC ▪ manufacturer installed. Remove everything > Change settings gives you two options. Data erasure On removes files and cleans the drive. If you're planning to donate, recycle, or sell your PC, use this option.
  • Page 23 Additionally, using a drill press, or drill of sorts to drill through the HDD will also destroy the HDD beyond repair. SSD: The process for destroying an SSD is much simpler, it can simply be destroyed beyond use, there is no protective outer cover. Use of a hammer, stomping on the component, breaking in half, etc.

  • Page 24: Upgrades, Service, And Repair

    UPGRADES, SERVICE, AND REPAIR The following table is a list of all included hardware features, and a few hardware features that could be added as an upgrade option. Note: all add on hardware features do not fall within the original scope of this product and void all certifications/regulatory compliance attestations.
  • Page 25 Ordering Parts, Requesting Repair, or Talking to Technical Support The Ace Computers technical support team is ready and available to help in providing replacement parts, helping to identify compatible upgrades, or to answer software questions. Please have your serial number available for reference when contacting Ace Computers.

  • Page 26: Product Take Back, End Of Life Processing, And E-Waste Program

    Nation Wide Take Back Services If your PC has reached its end of life or is no longer useable, Ace Computers is excited to offer a Nation-Wide take back service. We will work with you to get the product back and will ensure it is proper disposed of with a certified R2 electronics recycling facility.

  • Page 27: Revision History

    REVISION HISTORY Release Date Changes 4.01.2024 Initial Release ACE159...
