- Page 1 TECHNICAL REFERENCE GUIDE ACE MUSTANG SERIES MODEL: W640 ACE128...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DISCLOSURES ..........................3 INTRODUCTION ..........................4 ENEGY STAR AND POWER MANAGEMENT ..................5 ILLUSTRATED SYSTEM DISASSEMBLY/REASSEMBLY INSTRUCTIONS ..........7 UPGRADES, SERVICE, AND REPAIR ....................16 PRODUCT TAKE BACK, END OF LIFE PROCESSING, and E-WASTE PROGRAM ......18 REVISION HISTORY ........................ -
Page 3: Disclosures
Ace Computer's total liability for all claims will not exceed the price paid for the hardware product. The products sold by Ace Computers are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage. -
Page 4: Introduction
If you have any questions regarding this manual or computer system, please contact our support team through Ace Computers Support page at support.acecomputers.com This manual may be periodically updated without notice. Please check the Ace Computers website for possible updates to the manual revision level. ACE128... -
Page 5: Enegy Star And Power Management
ENEGY STAR AND POWER MANAGEMENT What is Energy Star? Created by the Environmental Protection Agency (EPA) and the United States Department of Energy (DOE), the Energy Star program is a strict set of specifications that residential appliances and construction elements (washers, dryers, refrigerators, freezers, dishwashers, televisions, tablets, computers, monitors, water heaters, HVAC units, dehumidifiers, air cleaners and purifiers, lighting, insulation and more) must meet through evaluation and testing to achieve certification. - Page 6 Wake Management Capable of both remote (via network) and scheduled (via real time clock) wake events from Sleep Mode. Provide clients with the ability to centrally manage (via vendor tools) any wake management settings that are configured through hardware settings if the manufacturer has control over such features.
-
Page 7: Illustrated System Disassembly/Reassembly Instructions
If you are uncertain about replacement or upgrade of your computers, the Ace Computers technical support team does offer “depot” services for on-site system repair and upgrade. Please contact the Ace Computers Technical Support team for additional information and pricing. - Page 8 Representative Desktop Component Layout Please note the illustration below is a representative sample of the W640, your PC may include additional components or variations of this family configuration. ACE128...
- Page 9 System Map: Left View of W640 Model System Map: Right & Rear Views of W640 Model ACE128...
- Page 10 System Map: Bottom View of W640 Model W640 Disposal/Selective Treatment The following section outlines the components of the W640 that required Selective Treatment/Special Handling Per Annex VII, Directive 2012/19/EU: Lithium Ion Optical Drive Battery Motherboard Processor Heatsink Fan HDD, SSD Memory The HDD, SSD, Memory, Motherboard, and Optical Drive each contain one printed circuit board of greater than 10 sq.
- Page 11 The processor must be disposed of, or recovered, in compliance with the requirements of Directive 2008/98/EC. A lithium-ion battery resides on the bottom rear of the laptop. The battery must be removed separately from the laptop and shall be disposed or recovered in compliance with Directive 2008/98/EC.
- Page 12 Battery Handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.
- Page 13 from the laptop and shall be disposed or recovered in compliance with Directive 2008/98/EC. External Power Cable Location: The inlet to the power cable is located on the I/O panel on the left view of the laptop. Type and number of fastenings: None, direct pressure connection method. Tools required: None.
- Page 14 Chassis Bottom Cover Removal Location: In order to access the internal components of your system, you will need to remove the bottom cover of the chassis. Type and number of fastenings: Four Phillips head screws Tools required: Phillips head screwdriver Procedure: Step 1: Ensure the desktop is off, unplugged, Four Phillips...
- Page 15 Contact Ace Computers Support Desk for help Ace Computers staffs a technical support desk and is always ready to help. You can contact the team at support@acecomputers.com - or- call 877-223-2667 -or- visit the acecomputers.com and click “Support” to start a new support ticket online.
-
Page 16: Upgrades, Service, And Repair
UPGRADES, SERVICE, AND REPAIR Replacement and Repair Services are available for a minimum of three years after date of purchase, and often times if a direct replacement is not available and upgrade replacement can be found for several years beyond the initial 3-year mark, ensuring the longest possible utilization of your PC. - Page 17 Ordering Parts, Requesting Repair, or Talking to Technical Support The Ace Computers technical support team is ready and available to help in providing replacement parts, helping to identify compatible upgrades, or to answer software questions. Please have your serial number available for reference when contacting Ace Computers.
-
Page 18: Product Take Back, End Of Life Processing, And E-Waste Program
Nation Wide Take Back Services If your PC has reached its end of life or is no longer useable, Ace Computers is excited to offer a Nation-Wide take back service. We will work with you to get the product back and will ensure it is proper disposed of with a certified R2 electronics recycling facility. -
Page 19: Revision History
REVISION HISTORY Release Date Changes 9.26.2022 Initial Release ACE128...
