Summary of Contents for EPOS EXPAND Vision 5
- Page 1 EXPAND Vision 5 — Microsoft Teams Room Installation Guide 1 Microsoft Teams Room Installation Guide EXPAND Vision 5...
- Page 2 Network Ports • EXPAND Vision 5 • Two network ports in the same subnet are required to pair the EXPAND Control with the EXPAND Vision 5. • EXPAND Control (Network cable included) • One of these ports must support Power over Ethernet (PoE) to power the EXPAND Control when connected with a network cable.
-
Page 3: Setup And Installation
If you do not limit the “Number of Devices Allowed” The Connect all the necessary cables to the EXPAND Vision 5. Remember to always attach the QR code can be reused for multiple power cord last. Once all cables are properly connected, allow the device to boot up. - Page 4 Enrollment without QR code Choose Continue with this device only. Use the created QR code to enroll the devices into EPOS Manager. The system will automatically deploy the settings contained in the QR code and upgrade the video device and controller to the latest FW.
- Page 5 EXPAND Vision 5 — Microsoft Teams Room Installation Guide 9 I do not use EPOS Manager > choose select. Pick your Country / Time zone and hour. Search for your Time zone. Choose Teams as UC provider for your product.
- Page 6 EXPAND Vision 5 — Microsoft Teams Room Installation Guide 11 EXPAND Vision 5 Display EXPAND Vision 5 MS teams login Login into MS teams using the code displayed on the monitor of your EXPAND device (use the same MTR account for your EXPAND Vision 5 and EXPAND Control).
- Page 7 EXPAND Vision 5 — Microsoft Teams Room Installation Guide 13 EXPAND Control Optional settings for static IP address configuration At first-time setup note the coq wheel in the right-hand corner. Tapping into this entry gives you the ability to set the device account to a static IP address required together with DNS, NTP and Proxy settings.
-
Page 8: Language & Time Settings
EXPAND Vision 5 — Microsoft Teams Room Installation Guide 15 Language & Time Settings Verify the settings of the setup Choose the static option and ok From the Device Settings the settings below can changed. Date/Time zone Date & Time >... -
Page 9: Device Name
Best practice is to change the default admin password which is 0000. To assign a unique name, delete the default and insert device name according to your naming policy. The name will automatically be synced into EPOS Manager, if enrolled. Insert relevant information and choose SAVE. -
Page 10: Network Settings
EXPAND Vision 5 — Microsoft Teams Room Installation Guide 19 Verify device details Choose static and then OK Choose relevant unit. It is recommended to start with the EXPAND Vision 5 video device as you will lose paring between EXPAND Control and EXPAND Vision 5 once IP address is changed. -
Page 11: Proxy Settings
EXPAND Vision 5 — Microsoft Teams Room Installation Guide 21 Factory Reset EXPAND Vision 5 Proxy Settings Device Settings => Debug Tools => default password is 0000. Always start with the video device as pairing will be lost between controller and video device. - Page 12 EXPAND Vision 5 — Microsoft Teams Room Installation Guide 23 Factory Reset EXPAND Control EPOS Manager Provisioning If you didn’t enroll the device into EPOS Manager to begin with, you can create your QR code and insert the QR Code in the system. Scan you QR code, choose on-prem and Enterprise Cloud.
-
Page 13: Camera Settings
This feature allows the camera to adjust the video feed based on the number of people and their positions in the video room. Learn more about how to install and use the EXPAND Vision 5 here: Access the learning videos:... - Page 14 THE POWER OF AUDIO EPOS Group A/S Industriparken 27 2750 Ballerup, Denmark eposaudio.com...
