- Page 1 LAB GRADE REFRIGERATOR PRODUCT MANUAL FLR105, FLR120, FLR125, FLR245 Upright and Undercounter...
- Page 2 FARRAR products is expressly prohibited. Copyright and Trademark Copyright © 2024 Trane is a registered trademark of Trane in the United States of America. All other trademarks and registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
FARRAR® Lab Grade Refrigerator Series Product Manual Contents 1. About this Manual Intended Audience Model Reference Intended Use Safety Precautions and Symbols Avoiding Injury General Recommendations 2. Installation Location Placement and Leveling Stacked Undercounter Units AC Power Cord Temperature Probes 3. -
Page 4: About This Manual
FARRAR® Lab Grade Refrigerator Series Product Manual 1. ABOUT THIS MANUAL 1.1 Intended Audience This manual provides information on how to use FARRAR Lab Grade Refrigerators. It is intended for use by end users of the refrigerators and authorized service technicians. 1.2 Model Reference Models are indicated by a distinguishing model number that corresponds to the series, type, and capacity of the refrigerator. -
Page 5: Avoiding Injury
FARRAR® Lab Grade Refrigerator Series Product Manual 1.5 Avoiding Injury Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Review safety instructions before installing, using, or maintaining the equipment. Before moving unit, ensure door is closed and casters are unlocked and free of debris. -
Page 6: Installation
FARRAR® Lab Grade Refrigerator Series Product Manual 2. INSTALLATION 2.1 Location Keep all ventilation openings in the enclosure or, in the structure of building-in, clear of obstruction. Has a grounded outlet meeting the electrical requirements listed on the product specification label. Is clear of direct sunlight, high temperature sources, and heating and air conditioning vents. -
Page 7: Ac Power Cord
FARRAR® Lab Grade Refrigerator Series Product Manual 2.4 AC Power Cord Use manufacturer supplied power cord only. Install power cord If packaged with modular cord, insert plug securely into the refrigerator power receptacle prior to connecting to grounded outlet. 2.5 Temperature Probes A temperature probe and buffered solid ballast have been provided with this unit. -
Page 8: Farrar Lab Grade Refrigerator Operation
FARRAR® Lab Grade Refrigerator Series Product Manual 3. FARRAR LAB GRADE REFRIGERATOR OPERATION 3.1 Initial Power Up Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. Switch the AC ON/OFF switch ON. Install 9 V back-up battery provided (undercounter battery located in literature box;... -
Page 9: Change Temperature Setpoint
FARRAR® Lab Grade Refrigerator Series Product Manual View maximum temperature recording Press and hold the Up Arrow button for 1 second and listen for a single beep. The display will alternate between HI and a valid temperature value five (5) times followed by a single beep to indicate exit back to the temperature display. -
Page 10: Set Parameter Values
FARRAR® Lab Grade Refrigerator Series Product Manual 3.4 Set Parameter Values Press and hold the Up and Down Arrows simultaneously for 3 seconds to enter program mode. The LED Display will show °C or °F to indicate Celsius or Fahrenheit. Press and release MODE button to scroll through the parameters. -
Page 11: Temperature Calibration Offsets
FARRAR® Lab Grade Refrigerator Series Product Manual 3.7 Temperature Calibration Offsets Temperature calibration offsets indicate an acceptable margin of error between the actual temperature value and the desired temperature value. Monitor Offset Value is factory-set to match a calibrated reference thermometer. Refer to the service manual for instructions regarding changing the Monitor Offset. -
Page 12: Product Specifications
FARRAR® Lab Grade Refrigerator Series Product Manual 4. PRODUCT SPECIFICATIONS 4.1 Operating Standards These units are designed to operate under the following environmental conditions: Indoor use only Altitude (maximum): 2000m (120 and 125 models); 3000m (105 models) Ambient temperature range: 15°C to 32°C (59°F to 90°F) Relative humidity (maximum for ambient temperature): 80% for temperatures up to 31°C;... -
Page 13: Refrigerator Specifications
FARRAR® Lab Grade Refrigerator Series Product Manual 4.2 Refrigerator Specifications Refrigerator Dimensions Cu. Ft/ Net Wt. Dimensions W x H x D in. (mm) Model Voltage Code Amps Profile Door Liters lbs (kg) Exterior 115V 60 Hz 24.3 x 33.9 x 27.8 Undercounter Single hinged glass FLR105... -
Page 14: Compliance
FARRAR® Lab Grade Refrigerator Series Product Manual 5. COMPLIANCE 5.1 Safety Compliance This product is certified to applicable UL and CSA standards by a NRTL. This product is IECEE CB Scheme certified and complies with national differences for safety certification beyond IEC 61010-1:2010, IEC 61010-1:2010/AMD1:2016, IEC 61010-2-011:2016. - Page 15 800-B Beaty Street, Davidson, NC 28036 T: 800.242.7197 | www.farrarscientific.com LSSinfo@tranetechnologies.com © 2024 Trane Technologies Life Sciences LLC. All Rights Reserved. LSFU-PRG011A-EN 4-14-24...
