- Page 1 XBIRD 2022 . USER MANUAL Xuwing com Finwinghobby com...
- Page 2 Please read through the manual before installation and flying This manual as introductions to user on how to build ing this RC plane. Please visit the finwinghobby com official website for more introductions. Warning : 1 This model airplane is not a toy not recommended for children under 14 years old 2.
- Page 3 55MM 55MM Is 55MM from the leading edge You can move it forward to 52MM if noted tail heavy But Maiden please use 55MM Xuwing com Finwinghobby com...
- Page 4 What Parts in the bag M3 30 Secure tail Motor Screws to For Tail Motor secure Servo horn Servo Horn Fuselage inside Spare playwood Xuwing com Finwinghobby com...
- Page 5 Reinforce Elevator control surface Carbon rod reinforce fuselage As below is step by step on how to glue parts Install reinforcement cabon rib First do this please skip if some has been pre glued Xuwing com Finwinghobby com...
- Page 6 Answer is you are no long available to get the plane if came out as a whole part becau e of expensive shipping cost and packing size restrictions Glue to the red colored surface Some parts can also be installed now Xuwing com Finwinghobby com...
- Page 7 Airframe building install cabon rib to reinforce vertical wing install cabon rib to reinforce Elevator surface Xuwing com Finwinghobby com...
- Page 8 Airframe building Main wings 40MM install cabon rib to reinforce Aileron surface Xuwing com Finwinghobby com...
- Page 9 Airframe building Glue to join horizontal wing and vertical wing Stay drying at least 4 hours after glued two parts Xuwing com Finwinghobby com...
- Page 10 Right Screw was fixed don t screw off Front 2 Rear 2 Elevator Neutralize Servo first then install servo arm If Stock PNP Electronic combo will include 1PCS Customized 450MM Wire servo 450MM for Elevator Xuwing com Finwinghobby com...
- Page 11 Airframe building Elevator Travel 10 4 1 Elevato r Pull rod recommend to use this hole Reminder : Pull rod direction Xuwing com Finwinghobby com...
- Page 12 Airframe building - 2 Aileron Cut off the side connection of the control surface until feeling the control surface is rotatable freely Ailerons all do the same Xuwing com Finwinghobby com...
- Page 13 Airframe building Right Wing Elevator Travel 10 Reminder : Pull rod recommend Pull rod direction to use this hole Xuwing com Finwinghobby com...
- Page 14 Airframe building Left Wing Elevator Travel 10 Reminder : Pull rod recommend Pull rod direction to use this hole Xuwing com Finwinghobby com...
- Page 15 Glue to join left and right fuselage Tail motor base Belly protector Put a little glue to install the belly protector Reminder don t put too much glue in order to replace it easily in future Xuwing com Finwinghobby com...
- Page 16 Airframe building Twin motor version Glue to joinl the twin motor mount Room temperature dry at least 12 hours before installation of Motors Xuwing com Finwinghobby com...
- Page 17 Airframe building Glue to install vertical wing Xuwing com Finwinghobby com...
- Page 18 Airframe building Recommend stay drying at least hours Horizontal wing Xuwing com Finwinghobby com...
- Page 19 Motor ESC Single tail pusher As below show is the stock motor and ESC In put Connect to Battery 4PCS Screws FG motor plate M3 6MM M3 30MM 2PCS Xuwing com Finwinghobby com...
- Page 20 Motor ESC Motor CW Propeller CCW Motor CCW Propeller CW Xuwing com Finwinghobby com...
- Page 21 Twin Motor & Twin motor tractor 4PCS Screws 3 15MM 2PCS Propeller rotation direction Xuwing com Finwinghobby com...
- Page 22 Tail fuselage cover locker Lock Find out a screw M4 16 Unlock Xuwing com Finwinghobby com...
- Page 23 FPV ears Reserved bay for GPS You can also put GPS on top of the fuselage Reserved T un n el F or a n t en n a Xuwing com Finwinghobby com...
- Page 24 机架安装 Reserved bay FPV camera Xuwing com Finwinghobby com...
- Page 25 相关设备安装和 建 议 Xuwing com Finwinghobby com...
