- Page 1 Technical Manual Wind Screen 85, 105 & 125 Solar...
-
Page 3: Table Of Contents
Index 1. General recommendations regarding safety, use and restrictions ............ 4 2. Installation instructions ............................5 2.1 On-site installation ....................................5 2.2 Installation on pergola ..................................8 2.3 Solar panel installation ................................... 11 3. Wind resistance (EN 1359) ...........................11 4. Maintenance ................................12 4.1 Cleaning and care .................................... -
Page 4: General Recommendations Regarding Safety, Use And Restrictions
1. General recommendations regarding safety. Use and restrictions In order to ensure the safe assembly, use and maintenance of Before assembly, it is very IMPORTANT for your safety and that this product, a number of precautionary measures must be taken. of the product to follow all the recommendations listed below. -
Page 5: Installation Instructions
TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR 2. Installation instructions 2.1 On-site installation Verify the dimensions of the installation place. Check the dimensions of the product before installation. Verify that they are correct. X = Width total (mm) Y = Height total (mm) X = Width total (mm) Y = Height total (mm) - Page 6 Position the product in the place where it is going to be installed. Check that the product is correctly levelled and square in all positions. The solar panel can then be installed on the façade or on the box. 90º 90º...
- Page 7 TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR Fasten the systems through the guides. Take into account the type of wall when choosing the anchoring system. Insert the rack profile through the PVC 26x13.50 mm guide and position it on the rear guiding profile. To finish the installation, join the two parts of the aluminium guide using screws DIN 912 A2 M4x25 mm.
-
Page 8: Installation On Pergola
2.2 Installation on pergola Verify the dimensions of the pergola side where it is going to be Check the dimensions of the product before installation. Verify installed. that they are correct. X = Total width ( (mm) X = Total width ( (mm) Y = Total height (mm) Y = Total height (mm) Assemble the box with the rear guides. - Page 9 TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR Check that the product is correctly levelled and square in all positions. The solar panel can then be installed on the pergola or on the box. 90º 90º 90º Fasten the systems through the guides. For an installation on a pergola it is recommended to use self-tapping screws.
- Page 10 Insert the rack profile through the PVC 26x13.50 mm guide and position it on the rear guiding profile. To finish the installation, join the two parts of the aluminium guide using screws DIN 912 A2 M4x25 mm. The rear guide with the front guide.
-
Page 11: Solar Panel Installation
TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR 2.3 Solar panel installation The solar panel can be installed either in the box or where the sunlight is most direct. The fastening can be done either with the included adhesive stickers or with two screws. The connection of the solar panel to the motor can be done in two ways: 1. -
Page 12: Maintenance
4. Maintenance 4.1 Cleaning and care To clean the canvas, we recommend removing the dust that has For best use and extended durability of the screen, it is recom- accumulated without using water, to enable you to remove all the mended to carry out regular maintenance and checks at least surface particles by vacuuming, air blowing, beating or brushing. -
Page 13: Motor Programming
TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR 6. Motor programming 6.1 Motor configuration The motor has the limit switches adjusted and the transmitter assigned. To begin with, remove the protective plastic from the battery and then you can use the product. 1. - Page 14 4. Setting the limit switches Upper limit switch setting. 1. Move the Wind Screen to the desired upper limit switch posi- tion. 2. Once in place, press once on the back of the transmitter. 3. Then press the up button on the transmitter and the motor will confirm with a double up and down movement.
- Page 15 TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR 5. Datos técnicos Rolling Code Rolling Code Radio coding 433.92MHz 433.92MHz Radio Frequency IP44 IP44 Protection Index 5 Nm 10 Nm Rated Torque 28 RPM 14 RPM Speed Nominal Consumption 11, 1 V 11, 1 V Nominal Voltage 3,5A...
-
Page 16: Anexo I Disassembly And Disposal Of The Packaging And Components Of The Product At The End Of Its Useful Life
Anexo I Disassembly and disposal of the packaging and components of the product at the end of its useful life Disposal of packaging Important The packaging must be recycled by the authorised profes- sional who installed the product. We advise you to recycle the product packaging responsibly: Paper and cardboard: In waste management, the recycling of paper and cardboard •... - Page 17 TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR Warning Always act with care. Use appropriate tools which are in perfect condition. • Step 12 • Step 1 Remove the mat from the box profile. Raise the Wind Screen to its upper limit switch position. •...
- Page 18 Our products are mainly made of recyclable materials. It is Important advisable to be informed about the recycling or disposal systems provided for in the current regulations in your country for this product category. Always act with care. Please only use suitable tools that are in perfect condition.
- Page 19 TECHNICAL MANUAL WIND SCREEN 85, 105 & 125 SOLAR The materials that our products are made of offer a great variety of environmental advantages Galvanised steel Galvanised steel is a type of steel which undergoes a certain treatment, at the end of which it is coated with several layers of zinc which protect it, avoiding oxidation.
- Page 20 Plastic Plastic recycling provides a sustainable source of raw material for the industry. Its reuse also significantly reduces environmental problems, as it is a non-biodegradable material. HDPE Recycling reduces energy consumption and CO2 emissions, thus mitigating pollution and climate change. There are several types of plastic, so to achieve optimal recycling it is essential to deposit them in clean points where the separation of the different types and their identification will take place.
- Page 21 Giménez Ganga, S.L.U. Polígono Industrial El Castillo C/ Roma, 4 • 03630 Sax (Alicante) • España saxun.com...
