- Page 1 Installation and Restoring Manual Crash Cushion for work zones Taurus TL-3 Installation and Repair Manual...
-
Page 2: Table Of Contents
Taurus TL-3 – Installation and Repair Manual INDEX GENERAL ..........................2 Foreword ..........................2 Crash Test .......................... 2 Taurus MASH: Components ....................2 1.1. Customer service........................ 4 INSTALLATION PROCEDURE ....................6 CONNECTION PROCEDURE ....................8 LOWER SIDE PANEL SCREWING ..................12 INSPECTION-REPAIR ...................... -
Page 3: General
Taurus TL-3 – Installation and Repair Manual 1. GENERAL Foreword This document is the SMA (Safety Modular Absorber) Installation and Repair Manual for the Taurus MASH TL-3, Redirective Non-Gating Crash Cushion, designed by Industry A.M.S. srl, of Marcianise (CE), ITALY. - Page 4 Taurus TL-3 – Installation and Repair Manual Fig. 1: Taurus-TL3 crash cushion SMA Road Safety s.r.l.
-
Page 5: Customer Service
+ 150 chamfer) 1.1. Customer service. SMA Road Safety s.r.l. commits to supply the customer service at the highest level. The Company welcomes the comments concerning the quality and the manufacturing of its products, the installation procedure and the supporting documentation. - Page 6 Taurus TL-3 – Installation and Repair Manual Email: engineering@safebarriers.com SMA Road Safety s.r.l.
-
Page 7: Installation Procedure
• HILTI M16x175 threaded bars for the fastening of the connection piece to the barrier • Screws M16x50 for the fastening of the connection piece to the SMA device. Anchoring to the ground The following kit is mandatory for the anchoring to the of the system. - Page 8 Taurus TL-3 – Installation and Repair Manual Fig.2: Drill bit type HILTI TE-CX SDS Plus M20 x 450mm Fig.3: Threaded screw type HILTI KH-EZ M20 x 230mm Fig.4: Reflective Sticker attached to the trolley SMA Road Safety s.r.l.
-
Page 9: Connection Procedure
Taurus TL-3 – Installation and Repair Manual 3. CONNECTION PROCEDURE The connection piece will be supplied according to the barrier specifications. The customer has to advise the following information: Beam profile of the barrier system; Height from the ground; Dynamic deflection;... - Page 10 Taurus TL-3 – Installation and Repair Manual Crash Cushion Connection TRAFFIC Fig. 5a: Top view of the Crash Cushion connected to the guardrail. Type 1 Crash Cushion Connection TRAFFIC Fig. 5b: Top view of the Crash Cushion connected to the guardrail. Type 2 Fig.
- Page 11 Taurus TL-3 – Installation and Repair Manual Fig. 6b: Example of standard connection piece to concrete barrier.Type 2 Fig. 7a : Exploding view of connection piece. Type 1 SMA Road Safety s.r.l.
- Page 12 Taurus TL-3 – Installation and Repair Manual Fig. 7b : Exploding view of connection piece. Type 2 SMA Road Safety s.r.l.
-
Page 13: Lower Side Panel Screwing
Taurus TL-3 – Installation and Repair Manual 4. LOWER SIDE PANEL SCREWING Taurus TL-3 is supplied with an attachable/detachable lower side panel (see #5 Fig.1) which can be easily screwed to the other side of the device. The lower side panel must be faced towards the carriageway. - Page 14 Taurus TL-3 – Installation and Repair Manual 2. Insert the back part of the module type 3 in the C-shape support screwed to the backstop. 3. Put the plate on the back face of the box element welded to the foot, finally place the front part of the side panel in correspondence of the holes on the box element and screw the module with 2 M12 screws.
- Page 15 Taurus TL-3 – Installation and Repair Manual Fig. 9: Details of the backstop SMA Road Safety s.r.l.
-
Page 16: Inspection-Repair
5. INSPECTION-REPAIR Foreword Taurus TL-3 WZ doesn’t need maintenance under standard condition of use. If the vehicle impacts according to MASH-16 it can be restored by simply replacing the damaged components with the opportunity to totally recover the remaining part of the structure.. -
Page 17: Component Replacement
Taurus TL-3 – Installation and Repair Manual 5.2 Component replacement Each component has a Rif. code with the related drawing number (See CHAPTER 6). Fig. 9 shows the repair procedure in different steps. Trolley (Rif. H) Remove the reflective sticker (if present) and unscrew the 4 no. - Page 18 Taurus TL-3 – Installation and Repair Manual Lower Side panels (Rif. Lo) See CHAPTER 4 Module type 1 Module type 2 Module type 3 SMA Road Safety s.r.l.
- Page 19 Taurus TL-3 – Installation and Repair Manual Fig. 10: Repair procedure in different steps SMA Road Safety s.r.l.
-
Page 20: Spare Parts List
Taurus TL-3 – Installation and Repair Manual SPARE PARTS LIST Below you can find the table with the spare parts list TAURUS TL-3 D68120000 PART NUMBER DESCRIPTION LENGT WIDTH HEIGHT Rif. (mm) (mm) (mm) Qty. D68120300 Frontal Trolley Collapsible beam -... - Page 21 8 Trugood Drive, Eastamaki, Auckland, New Zealand Ph: +64 9 272-4665 Email: sales@steelgal.co.nz www.steelgal.co.nz SMA Road Safety s.r.l. Via Dante Giacosa snc Zona ASI Sud 81025 Marcianise (CE), Italy Phone: +39 0823 15 90 030 info@smaroadsafety.com Copyright 2020, SMA Road Safety srl...
