Yardline Sky Climber Manual

Hide thumbs

page of 60

/ 60
Bookmarks

Quick Links

Download this manual

16683PLAY

STOP!

Call Us First!

DO NOT RETURN TO STORE.

For immediate help with assembly or product information

call our toll-free number:

1-800-844-9273

or email:

customerservice@backyardproductsllc.com

Our staff is ready to provide assistance.

April through October M - F 8:00 AM to 7:00 PM EST

Saturday 8:30 AM to 4:30 PM EST

November through March M - F 8:00 AM to 5:00 PM EST

Need help?

Do you have a question about the Sky Climber and is the answer not in the manual?

Questions and answers

Summary of Contents for Yardline Sky Climber

Page 1 16683PLAY STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll-free number: 1-800-844-9273 or email: customerservice@backyardproductsllc.com Our staff is ready to provide assistance. April through October M - F 8:00 AM to 7:00 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST...
Page 3 Model: 4276 4369 6007 Customer Service 1-800-844-9273 6192 1000 Ternes Drive Monroe, MI 48162 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Page 4 Never add extra length to chail or rope. The chains or rope provided are the maximum length designed for the swinging elements.
Page 6 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
Page 7 DIMENSIONS 6’ -0’’ 14’ -0’’ 14’ -8’’ 28’ -0’’ 6’ -0’’ 6’ -0’’ 11’ -0’’ 14’ -0’’ 6’ -0’’ 26’ -8’’ 9’ -6’’ 83’’ TO SWING HANGER PIVOT 8’’ MINIMUM...
Page 8 TOOLS REQUIRED INCLUDED HARDWARE...
Page 9 HARDWARE...
Page 10 SA6066 BOX 1 of 2 BOARD LIST (2) [PF 6325] 3’’ x 3’’ x 94-1/4’’ (1) [PF 6309] 5/8’’ x 3-3/8’’ x 35’’ (2) [PF 6324] 3’’ x 3’’ x 94-1/4’’ (1) [PF 6331] 5/8’’ x 3-3/8’’ x 31-1/2’’ (1) [PF 6323] 3’’ x 3’’ x 31-1/2’’ TOWER BEAM SUPPORT (1) [PF 6338] 3/4’’...
Page 11 SA6065 BOX 2 of 2 BOARD LIST (2) [PF 6297] 1-3/8’’ x 3-3/8’’ x 83’’ A-FRAME (20) [PF 6330] 1/2” x 3-5/16” x 36-3/4” SHINGLE (1) [PF 6296] 1-3/8’’ x 3-3/8’’ x 58’’ A-FRAME SUPPORT (2) [PF 6354] 5/8’’ x 3-3/8’’ x 37-3/8’’ (2) [PF 6352] 1-3/8’’...
Page 12 COMPONENTS 1-1/4"...
Page 13 COMPONENTS Model: 4276 4369 A Backyard Products Company 6007 Customer Service 1-800-844-9273 1000 Ternes Drive 6192 Monroe, MI 48162 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Page 14 STEP 1 PANEL A Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions. PANEL B NOTE HOLES PANEL C...
Page 15 STEP 2 PANEL A NOTE: HOLE ORIENTATION FRAME A Note:...
Page 16 STEP 3 FRAME A FLIP FRAME OVER...
Page 17 STEP 4 NOTE: HOLE ORIENTATION NOTE HOLES FRAME B WINDOW PANE INSTALL Note:...
Page 18 STEP 5 FRAME B FLIP FRAME OVER...
Page 19 STEP 6 3’’ From Outside of Post PANEL C 3’’ From outside of post To end of horizontal support. PANEL A Flush to outside edge of 3”x 3” 94-1/4’’ PF 6337 Flush to outside edge of 3”x 3” 20-1/4’’ FRAME A NOTE HOLE LOCATION...
Page 20 STEP 7 3’’ From Outside of Post to End of Horizontal Support. FRAME A FRAME B...
Page 21 STEP 8 NOTE: HOLE LOCATION...
Page 22 STEP 9 46-5/8’’...
Page 23 STEP 10 NOTE: 55-1/4’’ PRE-DRILL HOLES GOING INTO DECK SUPPORTS 11’’ 11’’...
Page 24 STEP 11 PANEL B PANEL B INSTALL...
Page 25 STEP 12 NOTE HOLE LOCATION INSIDE VIEW NOTE: Secure Barrier Board from inside barrier as shown.
Page 26 STEP 13 NOTE: MAKE SCREW HEADS FLUSH...
Page 27 STEP 14 COUNTERBORE 31-1/2’’ FRAME C FLIP FRAME OVER LIFT FRAME UP Note:...
Page 28 STEP 15 Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions. 2-5/8’’ 2-5/8’’ FRAME C FRAME C...
Page 29 STEP 16 NOTE: PRE-DRILL HOLES GOING INTO DECK SUPPORTS 12-3/4’’ 12-3/4’’...
Page 30 STEP 17 NOTE HOLE LOCATION...
Page 31 STEP 18 2-1/4’’ 3/4’’...
Page 32 STEP 19...
Page 33 STEP 20 Swing Beam Flat Washer Swing Hanger Bolt Swing Hanger Flat Washer IMPORTANT! WS 4456 Final position of each Spring Clip is perpendicular to swing beam. Swing Hanger You may need to tap with hammer to get though holes. Spring Clip Swing Hanger Bolt must protrude at least TWO Threads beyond Lock Nut.
Page 34 STEP 21...
Page 35 STEP 22...
Page 36 STEP 23 NOTE:...
Page 37 STEP 24 NOTE:...
Page 38 STEP 25 NOTE:...
Page 39 STEP 26...
Page 40 STEP 27 Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions.
Page 41 STEP 28 NOTE: CENTERED NOTE: Overlap Shingles as shown.
Page 42 STEP 29 NOTE: NOTE: OUTSIDE CENTER OUTSIDE OUTSIDE OUTSIDE OUTSIDE OUTSIDE OUTSIDE 1-1/2’’ 1-1/2’’ FLUSH AT BOTTOM...
Page 43 STEP 30...
Page 44 STEP 31 ALIGN SCREWS WITH PRE DRILLS...
Page 45 STEP 32...
Page 46 STEP 33...
Page 47 STEP 34 NOTE HOLE NOTE HOLES...
Page 48 STEP 35 BOTH SIDES BOTH SIDES...
Page 49 STEP 36...
Page 50 STEP 37...
Page 51 STEP 38 CENTERED NOTE:...
Page 52 STEP 39...
Page 53 STEP 40...
Page 54 STEP 41 STAND-UP SWING SWING SWING 8” Minimum when occupied. Adjust chains at Top. MINIMUM Swing Seat and Stand-Up Swing Assembly Installation...
Page 55 STEP 42 Roof parts removed for clarity. Steering Wheel Assembly 1. Choose a desired location for the Steering Wheel. 2. Mount Steering Wheel as indicated. 3. Snap Steering Wheel Cap into place.
Page 56 STEP 43 Telescope Assembly STEP 45 Flag Assembly...
Page 57 STEP 44 Note: Keep as little play as possible using any of the holes in the strap that work best. TIP:...
Page 58 WARRANTY WARRANTY REGISTRATION: Please complete your warranty registration to properly validate your product warranty registration. Register your product online at: www.OnlineWarranty.net Backyard Play Systems warrants the following: 1. All wood and plastic (polymer) coated wood components have a Limited Lifetime Warranty. solely to damage caused by fungal decay or termites.
Page 59 WARRANTY Please feel free to call our Consumer Help Line Toll Free 1-800-844-9273 Monday - Friday 8:00 AM to 6:00 PM EST Saturday 8:30 AM to 5:00 PM EST No warranty is offered on the following: (1) equipment subject to abuse, negligence, improper installation, vandalism, acts of God, unauthorized alteration or attachment to equipment other than our own: or (2) equipment subjected to improper use, service or repair by customer or any third party.
Page 60 A Backyard Products Company 1-800-844-9273 Available Monday - Friday, 7am - 5pm (CST) Technical support from experienced customer service representatives who have actually built a swing set themselves.
