Help Guide
Home Theatre System
BRAVIA Theatre Quad
Model: YY2080C
Install the application on your smartphone and follow the directions on the application to set
up the speaker system
To use the speaker system with all the available functions and improved performance, update the software of the speaker
system and the "Sony | BRAVIA Connect" app to the latest versions.
HT-A9M2
How to Use/Parts and Controls
About the App Required to Use the Speaker System
Devices That Are Connected to the Speaker System
Parts and Controls
Control Box
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRAVIA Theatre Quad YY2080C and is the answer not in the manual?

Questions and answers

Related Manuals for Sony BRAVIA Theatre Quad YY2080C

Summary of Contents for Sony BRAVIA Theatre Quad YY2080C

  • Page 1 To use the speaker system with all the available functions and improved performance, update the software of the speaker system and the “Sony | BRAVIA Connect” app to the latest versions. HT-A9M2 How to Use/Parts and Controls...
  • Page 2 If Your TV Has the S-CENTER SPEAKER IN Jack Connecting an AV Device Connecting to an AC Outlet (Mains) Performing Initial Setup with the “Sony | BRAVIA Connect” App If the Speakers Are Not Connected Correctly Listening to Music/Sound Listening to TV Sound...
  • Page 3 [Network Settings] [Easy Initial Setup] [Software update] Saving Power in Standby Mode Troubleshooting Troubleshooting Resetting the Speaker System Additional Information Specifications Supported Audio Formats Supported HDMI Video Formats Trademarks Licenses Notes on Use Customer Support Website 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 4 BRAVIA Theatre Quad About the App Required to Use the Speaker System Use a smartphone with the “Sony | BRAVIA Connect” app installed to operate and configure the settings on the speaker system. Install the “Sony | BRAVIA Connect” app on your smartphone.
  • Page 5 Connect wirelessly to the control box to play the speaker system sound. Optional subwoofer By using the app, optional subwoofers can be connected with the speaker system and configured. For the supported optional subwoofers, see the Sony website. Mobile device...
  • Page 6 The speaker system can also be used to stream music by connecting a mobile device to the same network as the speaker system. Listening to Music by Pairing the BLUETOOTH Device that is Connected for the First Time TP1001053981 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 7: Control Box

    Help Guide Home Theatre System BRAVIA Theatre Quad Control Box Front Status LED Indicates the speaker system status. Flashing in blue: Registering the speaker system. Flashing slowly in white: Initial setup is not complete or the speaker system is not connected to a network. Turned off: Initial setup is complete and the speaker system is connected to a network.
  • Page 8 HDMI IN jack DC IN terminal Related Topic Connecting to a TV If Your TV Has the S-CENTER SPEAKER IN Jack Connecting an AV Device Connecting to an AC Outlet (Mains) Resetting the Speaker System TP1001053980 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 9 The speaker is turned off. AC inlet Cable holder LINK When the speaker is turned on: Press: Press this button when the control box and speakers do not connect properly with the “Sony | BRAVIA Connect” app. Follow the instructions on the app.
  • Page 10 Remove the hole cover to use the hole. Keep the hole cover and the screw behind the cover for use when you do not mount the speaker on a wall or stand. Sony shall not be held responsible for accidents or damage caused by improper installation, lack of installation strength, misuse, or natural disaster.
  • Page 11 Help Guide Home Theatre System BRAVIA Theatre Quad Supplied Remote Control INPUT (Input) Used to select the input for playback on the speaker system. The input is switched each time you press this button. (Power) Switches between power on and standby on the speaker system. SOUND FIELD (Sound field) Turns on/off the surround sound effect on the speaker system.
  • Page 12 Remove any obstructions between the remote control and the control box. Replace both batteries in the remote control with new ones if they are older batteries. Check that the correct button on the remote control is being pressed. Related Topic Adjusting Sound Quality TP1001053979 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 13 BRAVIA Theatre Quad Remote Control Screen on the App The following functions can be controlled on the remote control screen on the “Sony | BRAVIA Connect” app. Playback information/input switching area The currently selected input, etc. appears on the upper part of the screen. The following information and operations are displayed by tapping this area.
  • Page 14 Related Topic Adjusting Sound Quality TP1001053978 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 15 Help Guide Home Theatre System BRAVIA Theatre Quad Installing the Control Box and Speakers Choose an installation method for the control box and speakers. They can be installed on a TV stand or shelves, etc. or mounted on the wall. Example of speakers installed on a TV stand and shelves: Example of speakers mounted on the wall: Note...
  • Page 16 Using with an optional subwoofer If you have not yet started setting up the speaker system, use the “Sony | BRAVIA Connect” app to start the setup. During the setup process, the app will guide you in connecting an optional subwoofer. No sound is output from the subwoofer if the setup is not completed on the app.
  • Page 17 If the sound from the optional subwoofer skips, this may be improved by changing the subwoofer installation position or settings. Note A software update may be required when using an optional subwoofer. TP1001174824 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 18 Help Guide Home Theatre System BRAVIA Theatre Quad Installing the Speakers on a TV Stand and Shelves Note Do not install the speakers in a cabinet or directly under the ceiling. Doing so may obstruct the sound output from the top of the speaker.
  • Page 19 Table stand Table stand screw Check the intended installation positions of the speakers and install the speakers. Check the label on the bottom of the speaker to make sure it matches the speaker’s installation position. : Front left speaker : Front right speaker : Rear left speaker : Rear right speaker Connect the AC power cord (mains lead) for the speaker that is connected to the speaker to an AC outlet...
  • Page 20 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 21: Mounting The Speakers On A Wall

    Hang the wall mounting brackets flat against the reinforced wall. Ask a Sony dealer or licensed contractor to install the speakers securely with full consideration of safety. Sony shall not be held responsible for accidents or damage caused by improper installation, lack of installation strength, misuse, or natural disaster.
  • Page 22 Attach the wall hook (supplied) to the speaker. Use the screw that was removed in step 2. Screw Wall hook Connect the AC power cord (mains lead) for the speaker (supplied) to the speaker. Fix the AC power cord (mains lead) that is connected to the speaker to the cable holder on the bottom of the speaker.
  • Page 23 To avoid dropping the wall bracket, hold down the wall mounting bracket while installing. Screws (not supplied) Confirm the speaker types. Check the label on the bottom of the speaker to make sure it matches the speaker’s installation position. : Front left speaker : Front right speaker : Rear left speaker : Rear right speaker...
  • Page 24 (mains). Note Keep the cover that is removed in step 2 for covering the screw hole when you do not mount the speaker on a wall. Related Topic Connecting to an AC Outlet (Mains) TP1001053976 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 25 Help Guide Home Theatre System BRAVIA Theatre Quad Connecting to a TV Connect an HDMI IN jack compatible with ARC/eARC on the TV and the HDMI OUT (TV ARC/eARC) jack on the speaker system using the HDMI cable (supplied). HDMI cable (supplied) Change the TV settings so that TV sound can be output from the speaker system.
  • Page 26 By enabling the eARC function on the TV, some features on the TV may become limited. For instance, system sounds and voice response may not be output. For details, refer to the operating instructions of your TV. TP1001174826 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 27 Help Guide Home Theatre System BRAVIA Theatre Quad If Your TV Has the S-CENTER SPEAKER IN Jack The TV can output the center part of the speaker system sound if the speaker system is connected to the TV using the following method.
  • Page 28 Displayed on the remote control screen on the app. Displayed by tapping [Settings] - [Sound Settings] - [Sound Field Setting] on the remote control screen on the app. Related Topic Connecting to a TV Adjusting Sound Quality [Sound Settings] TP1001174827 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 29: Connecting An Av Device

    Help Guide Home Theatre System BRAVIA Theatre Quad Connecting an AV Device 8K video and high-quality audio such as Dolby Atmos, Dolby TrueHD, DTS:X, etc. can be played by connecting an AV device (Blu-ray Disc player, set-top box, cable box, satellite box, gaming console, etc.) in the following way. Connect the HDMI OUT jack on the AV device and HDMI IN jack on the TV using an HDMI cable (not supplied).
  • Page 30 To play 360 Reality Audio content on an AV device, connect the AV device directly to the speaker system. By connecting an AV device directly to the speaker system, higher quality audio formats such as Dolby Atmos that are played on the AV device can also be output from the speaker system, even if the TV is not compatible with eARC.
  • Page 31 [Settings] - [HDMI Settings] - [HDMI Signal Format] on the remote control screen on the app. For the supported audio formats, refer to “Related Topic.” Related Topic Connecting to a TV Playing 360 Reality Audio Content from the Connected AV Device Supported Audio Formats Supported HDMI Video Formats TP1001174828 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 32 Help Guide Home Theatre System BRAVIA Theatre Quad Connecting to an AC Outlet (Mains) Connect the AC adaptor (supplied) and AC power cord (mains lead) (supplied)(*) to the DC IN terminal on the control box, then connect them to an AC outlet (mains). Except for North American models For North American models For other models...
  • Page 33 AC power cord (mains lead) for the speaker (supplied) When the AC power cord (mains lead) for the speaker is connected to an AC outlet (mains), the speaker turns on and the power indicator on the speaker flashes in green. TP1001053974 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 34 Performing Initial Setup with the “Sony | BRAVIA Connect” App To set up the speaker system, use the “Sony | BRAVIA Connect” app. Check that the control box and TV are connected and that the control box and speakers are connected to a power source.
  • Page 35 Power indicator Hint Check the speaker connection status in [Settings] - [Wireless Speaker Settings] on the remote control screen on the app. Related Topic Performing Initial Setup with the “Sony | BRAVIA Connect” App [Easy Initial Setup] [Wireless Speaker Settings] TP1001174829...

  • Page 36: Listening To Tv Sound

    Depending on whether you turn on the TV or the speaker system first, the speaker system may be muted and cause [MUTING] to appear in the front panel display on the control box. In this case, turn on the TV before turning on the speaker system. TP1001054252 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 37: Adjust The Volume

    If the picture and sound of the device that is connected to the speaker system are not output from the TV while the speaker system is turned off, access [Settings] - [HDMI Settings] - [Standby Through] and set this to [Auto] or [On] on the remote control screen on the app. Related Topic [HDMI Settings] TP1001174830 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 38: Adjusting Sound Quality

    Help Guide Home Theatre System BRAVIA Theatre Quad Adjusting Sound Quality The following sound quality adjustments can be performed on the remote control screen on the app or on the supplied remote control. Operating using the remote control screen on the app [Sound field] Outputs sound with the surround sound effect.
  • Page 39 On/off setting of the sound field and the setting displayed after you tap [Settings] - [Sound Settings] - [Sound Field Setting] on the remote control screen on the app. Displayed when you tap [Settings] - [Sound Settings] - [Sound Field Optimization] on the remote control screen on the app. Related Topic [Sound Settings] TP1001054316 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 40 Help Guide Home Theatre System BRAVIA Theatre Quad Listening to Music by Pairing the BLUETOOTH Device that is Connected for the First Time To use the BLUETOOTH function, the speaker system and BLUETOOTH device need to be paired in advance. Pairing is the process of registering devices with each other in advance.
  • Page 41 [Bluetooth]. Perform pairing for a second or subsequent BLUETOOTH device. Related Topic Setting the Wireless Function to On or Off Resetting the Speaker System TP1001054655 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 42 Help Guide Home Theatre System BRAVIA Theatre Quad Listening to Music from the Paired BLUETOOTH Device Turn on the BLUETOOTH function on the BLUETOOTH device. Switch the input to [Bluetooth] on the remote control screen on the app. The speaker system automatically reconnects to the BLUETOOTH device that was most recently connected to the speaker system.
  • Page 43 Related Topic Setting the Wireless Function to On or Off TP1001054654 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 44 The following operations cannot be performed when the wireless function is set to off: Pairing and/or connecting with a BLUETOOTH device. Using “Sony | BRAVIA Connect.” Playing music on the network via wireless LAN. If the wireless function is set to off, [Network/Bluetooth Standby] is automatically set to off. (European models only)
  • Page 45 The speaker system is compatible with 360 Reality Audio. 360 Reality Audio is a new music experience that uses Sony’s object-based spatial acoustic technology to create a highly realistic sound field that makes you feel as if you have entered the space where an artist is performing live.
  • Page 46 Play 360 Reality Audio compatible content by operating the connected AV device. Hint For details about AV devices that are compatible with 360 Reality Audio, refer to the following URL. https://www.sony.net/360RA/#speakers Related Topic Connecting an AV Device TP1001273837 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 47: Using Spotify

    Press INPUT (Input) to display [SPOTIFY] in the front panel display on the control box. If you were playing music on Spotify with the speaker system, the music that was being played on Spotify is resumed. Note The Spotify app may not be available in some countries/regions. TP1001174832 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 48: Using Airplay

    If you add the speaker system to the Home app on the iOS device, you can stream music to the speaker system by talking to Siri. Note Because the speaker system does not have a microphone, you cannot talk to the speaker system to operate it. Not all Siri features are available on the speaker system. TP1001174833 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 49 For how to enable the Control for HDMI function on a TV or Blu-ray Disc player, refer to its operating instructions. If the Control for HDMI (“BRAVIA Sync”) function is enabled on a TV manufactured by Sony, the Control for HDMI function on the speaker system is also automatically enabled.

  • Page 50: Volume Adjustment

    TV is turned on next. If this occurs, perform the following operation. Select the speaker system as the sound output device in the TV menu. If a Sony TV is being used, turn on the speaker system while the TV is turned on. Volume adjustment The sound of the TV that you are watching is output from the speaker system automatically.
  • Page 51 Sync” Function “BRAVIA Sync” is an extended function that is developed by Sony based on the Control for HDMI function. By using an HDMI cable to connect “BRAVIA Sync”-compatible devices such as a TV or a Blu-ray Disc player, the devices can be interlocked with each other and controlled.
  • Page 52 Normally set to [Auto] (the best channel for wireless communication is automatically selected). If sound dropping occurs, this may be improved by fixing the channel. [Wireless Playback Quality] Used to set the wireless playback quality for the 4 supplied speakers and optional subwoofer. TP1001054644 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 53 Help Guide Home Theatre System BRAVIA Theatre Quad [Sound Settings] These are the settings for audio output. The following setting items appear by tapping [Settings] - [Sound Settings] on the remote control screen on the app. [Sound Field Optimization] Optimizes the sound field effect. Follow the instructions on the screen. [Sound Field Setting] Used to select the type of surround sound effect.
  • Page 54 Reduces volume changes caused by the input signal. This function is effective when the volume of a TV commercial is louder than that of the TV program. Related Topic Supplied Remote Control Remote Control Screen on the App If Your TV Has the S-CENTER SPEAKER IN Jack [HDMI Settings] TP1001054648 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 55 Help Guide Home Theatre System BRAVIA Theatre Quad [HDMI Settings] These are the settings for HDMI. The following setting items appear by tapping [Settings] - [HDMI Settings] on the remote control screen on the app. [Control for HDMI] When the Control for HDMI function is enabled, devices that are connected using an HDMI cable are operated with each other and receive ARC audio from the TV.
  • Page 56 TP1001054647 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 57 The following setting item appears by tapping [Settings] - [Bluetooth Settings] on the remote control screen on the app. [Bluetooth Connection Quality] Used to set the BLUETOOTH connection quality when playing audio from a mobile device on the speaker system. Related Topic Setting the Wireless Function to On or Off TP1001054646 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 58 Used to change the name of the speaker system that is displayed when a function such as the BLUETOOTH function is being used. [System Information] Displays speaker system information such as the software version. [Software License Information] Displays the software license information. TP1001054645 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 59 Hint Once you have given your approval, you can stop the collection of information by withdrawing your consent or resetting the speaker system to its original settings. Related Topic Resetting the Speaker System TP1001174834 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 60 [Easy Initial Setup] The basic settings, speaker settings, and surround sound optimization for the speaker system can be easily performed. Tap [Settings] - [Easy Initial Setup] on the remote control screen on the app. TP1001054649 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 61 Home Theatre System BRAVIA Theatre Quad [Software update] Used to update the software of the control box, 4 supplied speakers, or optional subwoofer. Tap [Settings] - [Software update] on the remote control screen on the app. TP1001174835 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 62: Saving Power In Standby Mode

    Access [Settings] - [System Settings] - [Network/Bluetooth Standby] and set this to [Off] on the remote control screen on the app. Note When [Network/Bluetooth Standby] is set to [Off], it may take longer for audio to be output from the speakers. TP1001174836 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 63: Troubleshooting

    North American models only 4. Access the Sony support site from the menu of the “Sony | BRAVIA Connect” app to look up the cause and solution of the issue, or check the support website below.

  • Page 64: Resetting The Control Box

    Procedure: Press and hold down NIGHT (Night mode) on the supplied remote control for 5 seconds, then press (Volume) (Volume) –, and (Muting) in this order. Related Topic Performing Initial Setup with the “Sony | BRAVIA Connect” App [Wireless Speaker Settings] TP1001054642 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 65: Specifications

    Help Guide Home Theatre System BRAVIA Theatre Quad Specifications Speakers (YY2080C2/YY2080C3/YY2080C4/YY2080C5) The following descriptions are the specifications per speaker. Front speaker section Woofer 85 mm × 85 mm (3 3/8 in × 3 3/8 in) Cone type Midrange speaker 60 mm (2 3/8 in) Cone type Tweeter 19 mm (3/4 in) Soft dome type Speaker system...

  • Page 66: Lan Section

    BLUETOOTH standard profiles indicate the purpose of BLUETOOTH communication between devices. 3） Codec: Audio signal compression and conversion format 4） LDAC is an audio coding technology developed by Sony that enables the transmission of High-Resolution (Hi-Res) Audio content, even over a BLUETOOTH connection. General Input...

  • Page 67: Modulation Method

    Frequency band 5 GHz Modulation method OFDM Note Design and specifications are subject to change without notice. Refer to the Reference Guide included with your product, which may contain specification information not listed above. TP1001054641 5-049-832-11(1) Copyright 2024 Sony Corporation...

  • Page 68: Supported Audio Formats

    DTS-HD High Resolution Audio – DTS-HD Master Audio – DTS:X – 360 Reality Audio – – Note HDMI IN does not support audio formats that contain copy protections, such as Super Audio CD or DVD-Audio. TP1001054639 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 69 Help Guide Home Theatre System BRAVIA Theatre Quad Supported HDMI Video Formats The speaker system supports the following video formats. 8K 24/25/30/50/60 Hz 4K 24/25/30/50/60/100/120 Hz 1440p 120 Hz 1080p 24/30/50/60/100/120 Hz 1080i 50/60 Hz 720p 24/30/50/60 Hz 576p 50 Hz 480p 60 Hz About the [HDMI Signal Format] setting When [Settings] - [HDMI Settings] - [HDMI Signal Format] is set to [Enhanced format (4K120, 8K)] on the remote control...
  • Page 70 TV. HDCP2.3 is a copy protection technology that protects content such as 4K and 8K video content. BT.2020 is a wide color gamut standard that is established for Super Hi-Vision TVs. TP1001174837 5-049-832-11(1) Copyright 2024 Sony Corporation...
  • Page 71 Apple, AirPlay, iPad, iPhone, iPod touch and Siri are trademarks of Apple Inc., registered in the U.S. and other countries and regions. “BRAVIA” and “BRAVIA Sync” are a registered trademark or a trademark of Sony Group Corporation or its affiliates. Wi-Fi®, Wi-Fi Protected Access® and Wi-Fi Alliance® are registered trademarks of Wi-Fi Alliance. Wi-Fi CERTIFIED™, WPA™, WPA2™, and WPA3™...
  • Page 72 Apple performance standards. This product contains software that Sony uses under a licensing agreement with the owner of its copyright. We are obligated to announce the contents of the agreement to customers under requirement by the owner of copyright for the software.

  • Page 73: Notes On Use

    Help Guide Home Theatre System BRAVIA Theatre Quad Notes on Use Precautions Before using the speaker system, check that the operating voltage matches your local supply voltage. The operating voltage is indicated on the nameplate attached to the bottom of the speaker system. The supplied AC adaptor is designed exclusively for this speaker system.
