Mitt 125 RT SUPER User Manual

Hide thumbs

Advertisement

Table of Contents

USER'S MANUAL
MAINTENANCE BOOK
125 RT SUPER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 125 RT SUPER and is the answer not in the manual?

Questions and answers

Related Manuals for Mitt 125 RT SUPER

Summary of Contents for Mitt 125 RT SUPER

  • Page 1 USER’S MANUAL MAINTENANCE BOOK 125 RT SUPER...
  • Page 2 Dear Customer: Thank you for purchasing the TY125T-2D motorcycle. The TY125T-2D scooter is a product manufactured by using advanced equipment and made up of high-quality component parts. Equipped with electronic igniter, electric starting motor and protection -welded frame, the vehicle features high performance，good fuel economy，low noise level, quick acceleration and good mobility.
  • Page 3 I mp o r t a n t No t i c e : • Driver and passenger This vehicle is designed to carry only one driver . Do not exceed the rated load capacity specified on the specification label. Road condition ●...
  • Page 4 NOTE: This heading is used to precede instructions on effective operation . You should regard this manual as a permanent component part of your vehicle, perform periodic maintenance of your vehicle in a proper way . It is suggested to have your new vehicle inspected and maintained one month after purchase or after 300 km of drivin g usage and the best place to have this done is in nearby service center authorized by the manufacturer.
  • Page 5 1. A great many of motorcycle accidents were caused by the failure of the car driver to see the motorcycle driver. Therefore，the motorcycle driver should use every means to make himself clearly seen by the car driver. He can do this. for example : Wearing colorful and eye-catching clothes .

  • Page 6: Safety Rules

    Safety Rules 1. Before driving a motorcycle, be sure to check it carefully ( See the section “Inspection before Operation” of this manual). 2. Always put on a helmet and if possible wear boots, gloves, eye -protecting glasses and colorful clothes to ensure safety. 3.
  • Page 7 Loading WARNING: The trunk box is used to carry only lightweight objects, not for very heavy ones. When determining if the vehicle is overloaded (the rated load capacity being 252 kg), the weights of the objects being carried , the vehicle and the driver should be put together.
  • Page 8 L o c a t i o n o f Co mp o n e n t p a r t s Rear mirror Headlight Front turn signal light Muffler ① Rear turn signal light Taillight Seat...
  • Page 9 Meter Panel and Indicators All the controls for the indicators and warning lights are located on the meter panel. Their functions are described in detail in the following pages. 1. Power indicator 2. Left turn indicator 3. High beam indicator 4.
  • Page 10 Left turn indicator High beam indicator Engine warning lamp Right turn indicator Fuel indicator Power indicator Time Total mileage indicator Speed indicator Adjust the time、km or miles、 TRIP、ODO Fuel gauge The fuel gauge indicates the amount of fuel remaining in the fuel tank. When the indicator light remains in the F(full) position, the total capacity of the tank is 5.1 liters.
  • Page 11 G u i d e t o O p e r a t i o n Ignition Switch 1. ON( )—Turn the switch to position 1 and the power is on. At this time, the key cannot be pulled out. 2.
  • Page 12 NOTE: In hot weather, leaving the engine idling for a long time will cause it to overheated .You should shut it down to let it get cool. Headlight beam switch ① Push the “ ” button for high beam and the “ ”...
  • Page 13 Start button⑤ When this button is pushed,the starting motor works to start the engine. See the part “ Starting the Engine” for the starting procedure. Engine stop off Turning the switch to this “ ” position to power off and checking the switch on “ ”...
  • Page 14 L O A DI NG O F CA R G O NOTE : We have special requirements for the distributed weight of goods. Improper loading affects the function and stability of the motorcycle, even causes accidents and damages the vehicle. The rear box and travel box are used to carry lightweight articles.
  • Page 15 Fuel Level The fuel tank has a capacity of 6.2 liters. If the fuel gauge pointer comes near to the red mark position, you should refill the fuel tank and at the same time check it for leakage. The recommended fuel for use is 90# lead-free gasoline. CAUTION: Take extreme care when refilling the fuel tank not to get dust, water or other foreign matter s into the fuel tank , Do not mix the fuel with engine oil.
  • Page 16 C h e c ki n g t h e o i l l e v e l a n d r e f i l l in g 1.Turn down the center stand. Remove The oil dipstick and clean it. 2.Insert the dipstick directly (without turning it ) into the oil tank.

  • Page 17: Adjusting The Front Brake

    Brakes Adjusting the front brake Check the brake for normal performance and adjust its free play. The free play refers to the distance for which the front brake lever travels freely to achieve the braking effect. Required free play : 5 to 10mm Adjusting the rear brake Measure the traveling distance of the rear brake lever before the brake begins to create the braking effect，which should be within 10 to 20 mm from the top end of the brake lever.

  • Page 18: Checking The Tire Pressure

    Checking the tire pressure Check the tires for correct inflation pressure. Normal tire pressure Frontwheel 200kpa Rear wheel 220 kpa Check the tire surface for cuts, nails or other sharp objects and the wheel rim for impressions, dents or deformations. If damage of any degree is found with the tire, send your vehicle to the nearby service center for repair, replacement and adjustment of balance between the two wheels.
  • Page 19 Wear limit mark nail stone foreign matter Minimum tread depth Front Tire 1.5mm(0.06in) Rear Tire 2.0mm(0.08in) S t a r t i n g t h e e n g i n e Turn down the center stand to prop up the vehicle (or not to prop it up).insert the key into the igniter keyhole and hold the braking on.
  • Page 20 CAUTION: Always start the engine with the rear brake lever holding . The engine should not be allowed to run too fast when it is being warm up. Quick opening and closing of the throttle must be avoided. Ma i n t e n a n c e S c h e d u l e The maintenance schedule is according to the distance driven by the vehicle when to carry out the periodic maintenance and lubrication of which parts.
  • Page 21 maintenance, always replace the damaged parts with new one provided by the original manufacturer or ones of similar quality. Using other similar parts of poor quality will degrade the durability of your vehicle. WARNING: To ensure personal safety , be sure to shut down the engine first and place the vehicle on a flat surface and prop it up securely with the center stand before performing maintenance at whatever levels.
  • Page 22 Maintenance table To keep the perfonnance good, the motorcycle should be checked and maintained at certain interval. The meanings of capital in following table are: I: Inspection, including check, clean, lubricate, refuel, repair or replacing if necessary. A: Adjusting C: Cleaning R; Replacing T: Tightening Maintenance Odometer (km) period...
  • Page 23 When the mileage is over the highest on the table, please perform according to the period set on the table Driving on dust place, it is recommended to clean it frequently. C l e a n i n g t h e a i r c l e a n e r A dusty air cleaner leads to an increased fuel consumption and should therefore be cleaned.
  • Page 24 (Procedure) 1. Remove the filter sponge from the air cleaner. 2. Clean the sponge in cleaning oil and dry in the air ( Do no t use fuel for this purpose). 3. Clean the sponge again in engine oil and wring it dry before putting i t back into the air cleaner.
  • Page 25 E n g i n e O i l WARNING: Be sure to refill the oil tank with engine oil (SF10W/40). Im mediately when the warning indicator goes on. Insufficient amount of oil will cause damage to the engine. Check the level of the oil in the oil tank regularly . Viscosity: The viscosity level of the engine oil to be used should suit the atmospheric temperature of the local area.
  • Page 26 Replacing the gear box oil (Frequency of replacement) Replace the gearbox oil for every 3,000km of travel. The type of GL-4 gear oil should be used. Gear oil capacity Full capacity: 0.11 liters...
  • Page 27 C h e c ki n g t h e s p a r k p l u g A dirty spark plug with dirty electrodes or excessive gap between electrodes will not be able to generate full sparks. (Cleaning) The best result can be achieved if you clean the spark plug with a spark plug cleaner;...
  • Page 28 R e p l a c i n g t h e f u s e Turn off the master switch and check the fuse to see if it is blown . Replace the blown fuse with one of the specified capacity. ·Always find out the cause before replacing a blown fuse.
  • Page 29 CAUTION: • When removing the fuse, do not expand the fuse clamp too wide. • After the fuse is installed，check the fuse clamp to see if it runs loose . The fuse will generate heat if the fuse clamp is loose，which is often the major cause of trouble. WARNING: Never use a fuse having an amperage capacity different from the rated value as this will cause damage to the electric system and give rise to fire hazards or m ake it impossible to use the...
  • Page 30 C h e c ki n g t h e a ir c l e a n e r The air cleaner is fitted with a paper element which should be checked and cleaned once even 2000 km of travel. Clean the filter element in a detergent solution and dry in the air. Apply a small amount of oil to the filter element before use.

  • Page 31: Storing The Vehicle

    G u i d e t o p r o p e r s t o r a g e o f v e h i c l e Storing the vehicle To store the vehicle for a long period of time such as in winter, several procedures should be used to prevent malfunction or damage of the vehicle parts during this long break.
  • Page 32 NOTE: Before turning the engine, be sure to set the ignition switch to the OFF position, put the spark plug into the cable cap and ground it to prevent damaging the ignition system. 4. Remove the battery and keep it in a place free of freezing or exposed to direct sunlight. Charge the battery once every month.
  • Page 33 W h a t t o d o w h e n p u t t i n g t h e v e h i c l e b a c k t o u s e 1 .Remove the dust cover and clean the vehicle.Replace the engine oil if the vehicle has been stored for more than 4 months.

  • Page 34: Specifications

    Specifications 1900×685×1138 Battery capacity 12V/7AH Dimension(mm)(L X W X H) Axle base(mm) 1345 Ignition mode Curb Mass (kg) Spark plug CR7HSA Max. speed(km/h) Lubrication Separate lubrication Loaded Vehicle Mass(kg) Transmision Type 3.5-10/3.5-10 Tire size Gearshift Stage-less gearshift Wheel rim(front/rear) Al alloy/Al alloy Fuse capacity Brake(front/rear) disc/disc...
  • Page 35 @mittmotorcycles mittmotorcycles @MittMotorcycles MITT Motorcycles w ww.mit t m ot or s .c o m...

This manual is also suitable for:

Ty125t-2d
