- Page 1 ALBA CORNER SET...
- Page 2 SAFETY AND CARE ADVICE Please read these instructions fully before starting assembly. • Check you have all the components and tools listed in this booklet before assembly. • Remove all fittings from their plastic bags and separate them into their groups. •...
- Page 3 COMPONENTS - FITTINGS COMPONENTS - PANELS 16 x M6*25mm 1 x Sofa bolts 2 x Front legs 16 x Flat washers Tools Included 2 x Rear legs 1 x Spanner Cushions Included 2 x Middle legs 1 x Seat cushion 1 x Seat cushion 1 x Seat cushion 3 x Back cushions...
- Page 4 ASSEMBLY INSTRUCTIONS - 3 SEATER SOFA Step 1 Turn the sofa (A) upside down on a sofa clean surface ready for assembly. Attach front legs (B) to seat panel with bolts (E) and flat washers (F). Using spanner (G). Step 2 Attach rear legs (C) to seat panel (A) with bolts (E) and flat washers (F).
- Page 5 Step 3 Turn the sofa over and place in desired position. Put all seat cushions (H, I and J), back cushions (K) and side cushion (L) in the right place. ASSEMBLY COMPLETE...
- Page 6 COMPONENTS - FITTINGS COMPONENTS - PANELS 1 x Sofa 12 x M6*25mm bolts 1 x rear legs 12 x Flat washers 3 x legs Tools Included 1 x Spanner Cushions Included 1 x Seat cushion 1 x Seat cushion 2 x Back cushions...
- Page 7 ASSEMBLY INSTRUCTIONS - 2 SEATER CORNER Step 1 Turn the sofa (A) upside down on a sofa clean surface ready for assembly. Attach rear leg (B) to seat panel with bolts (D) and flat washers (E). Using spanner (F). Step 2 Attach legs (C) to sofa (A) with bolts (D) and flat washers (E).
- Page 8 Step 3 Turn the sofa over and place in desired position. Put all seat cushions (G, H) and back cushions (I) in the right place. ASSEMBLY COMPLETE...
- Page 9 COMPONENTS - FITTINGS COMPONENTS - PANELS 12 x M6*25mm 1 x Table top bolts 12 x Flat washers 4 x Legs Tools Included 1 x Spanner...
- Page 10 ASSEMBLY INSTRUCTIONS - TABLE Step 1 Turn the table top (A) upside down on a sofa clean surface ready for assembly. Loosely attach legs (B) to table top (A) with bolts (C) and flat washers (D). Tighten all bolts completely using spanner (E). Step 2 Turn the table over and place in desired position.
- Page 11 COMPONENTS - FITTINGS COMPONENTS - PANELS 2 x Brackets 1 x 3 Seater corner sofa 1 x 2 Seater corner sofa...
- Page 12 ASSEMBLY INSTRUCTIONS - CONNECTOR Step 1 Position sofa (A) and sofa (B) for assembly. With brackets (C), position over the section that joins the sofa parts. Turn the sofa over and place in desired place. ASSEMBLY COMPLETE...
