- Page 1 3M OVERHANGING PARASOL INSTRUCTION MANUAL IMPORTANT: Please read these instructions before using the product and retain for future use. HHGL Limited, MK9 1BA HHGL (ROI) Limited, D02 X576...
-
Page 2: Care Advice
CARE ADVICE • Always close/put down the parasol when not in use. Do not use or assemble the parasol in wind, rain, thunderstorms or if it’s snowing. In these weather conditions, we recommend to fold down or disassemble the parasol. Disassemble by following the setup steps in this manual. •... - Page 3 COMPONENTS Please check you have all components listed below. If you have any missing or damaged components, please contact your local store. 1 x Cross Base A 1 x Cross Base B 1 x Support Pole 4 x Bolts φM8*20mm 4 x Washers 1 x Wrench 1 x Frame with Canopy...
- Page 4 ASSEMBLY INSTRUCTIONS Step 1 Place Cross Base (A) on a soft surface, line up notches and place Cross Base (B) over Cross Base (A). Step 2 Attach Support Pole (C) to Cross Base by using Bolts (D) and Washers (E), hand tighten only. Adjust the Support Pole (C) to be sure it is positioned correctly on the Cross Base and finally tighten all Bolts with Wrench (F).
-
Page 5: Lock In Place
Step 4 Unlock the clip to raise the canopy arm. Step 5 Ensure the clip is locked into place to secure the canopy arm in position. ② ① LOCK IN PLACE ③ Step 6 Turn the crank handle in a clockwise direction to open the parasol canopy. Step 7 Turn the crank handle counter clockwise to close the parasol. - Page 6 Step 8 DO NOT JUST FOLD DOWN SUDDENLY, OR THE PLASTIC PART (L) WILL BE EASILY BROKEN. Step 9 Step 10 LOCK...
