21.3-inch (54 cm) Color LCD Monitor
CL-S300
Operation Manual
Model: CL-S300Bx0EA
CL-S300Bx0UA
Important
Please read this "Operation Manual" carefully before use.
Please make sure to read the "Safety precautions" first and keep this "Operation
Manual" in a safe and easily accessible place for future reference.
B5A-2234-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL-S300 and is the answer not in the manual?

Questions and answers

Related Manuals for JVC CL-S300

Summary of Contents for JVC CL-S300

  • Page 1 21.3-inch (54 cm) Color LCD Monitor CL-S300 Operation Manual Model: CL-S300Bx0EA CL-S300Bx0UA Important Please read this “Operation Manual” carefully before use. Please make sure to read the “Safety precautions” first and keep this “Operation Manual” in a safe and easily accessible place for future reference.
  • Page 2 Attention! The monitor screen can be rotated horizontally or vertically at 90 degrees. The monitor screen is rotated horizontally by default, rotate it according to your usage. Copyright (C) 1991-2, RSA Data Security, Inc. Created 1991. All rights reserved. License to copy and use this software is granted provided that it is identified as the "RSA Data Security, Inc.

  • Page 3: Table Of Contents

    Contents Before use ............................4 Safety precautions ........................15 Features ............................20 Names and functions of parts .....................21 Reference ............................23 Operating principle ........................23 Cleaning the monitor .......................24 Connector pin assignment ....................25 Technical specification ......................26 After-sales service ........................28 Disposal of electrical and electronic equipment ............29 - 3 -...

  • Page 4: Before Use

    Before use Thank you for purchasing our color LCD CL-S300. Please read this manual carefully for proper use. For your safety This manual contains important information on how to use the product. Please make sure to read the safety precautions first and keep this manual in a safe and easily accessible place for future reference.
  • Page 5 ● Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ● Consult your dealer or an experienced radio/TV technician for help. Responsible party located within the United States JVCKENWOOD USA Corporation 500 Valley Road, Suite 203 Wayne, New Jersey 07470 TEL: 973-317-5000 FCC Warning...
  • Page 6 ● This apparatus shall not to be used in the vicinity of the patient, which is the space with surfaces likely to be contacted by the patient or an attendant who can touch the patient. This encloses a space within the room 1.83 m (6 feet) beyond the perimeter of the bed in its intended location, and extending vertically 2.29 m (7-1/ 2 feet) above the floor.
  • Page 7 Guidance and manufacturer’s declaration – electromagnetic emissions The model CL-S300 is intended for use in the electromagnetic environment specified below. The customer or the user of the model CL-S300 should assure that it is used in such an environment. Electromagnetic environment...
  • Page 8 The model CL-S300 is intended for use in the electromagnetic immunity environment (Professional healthcare facility environment defined in IEC 60601-1-2) specified below. The customer or the user of the model CL-S300 should assure that it is used in such an environment.
  • Page 9 The model CL-S300 is intended for use in the electromagnetic immunity environment (Professional healthcare facility environment defined in IEC 60601-1-2) specified below. The customer or the user of the model CL-S300 should assure that it is used in such an environment.
  • Page 10 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the model CL-S300 is used exceeds the applicable RF compliance level above, the model CL-S300 should be observed to verify normal operation.
  • Page 11 RF communications equipment and the model CL-S300 The model CL-S300 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the model CL-S300 can help prevent...
  • Page 12 The model CL-S300 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the model CL-S300 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the model CL-S300 as recommended below, according to the maximum output power of the communications equipment.
  • Page 13 Label Please read the label containing warnings and cautions carefully before use. Important - 13 -...
  • Page 14 Explanation of symbols These following symbols and labels indicate meanings as below. Caution Mark Indicates the monitor is approved according to the UL & c-UL regulations Indicates compliance to the essential requirements of the European Medical Device Regulation (EU) 2017/745 (“MDR”) Indicates this device complies with the requirements of The Medical Devices Regulations 2002 (SI 2002 No 618, as amended) (UK MDR 2002)

  • Page 15: Safety Precautions

    Safety precautions This manual contains important warnings and information to prevent potential personal injury and property damage. The symbols and signs used in this manual and their meanings are as follows. Symbols Indicates a hazard which, if not avoided, could result in death or serious injury.
  • Page 16 Warning Do not disassemble, repair, or alter the monitor. It could cause fire, electric shock, or injury. Servicing of such a monitor may be refused. Or a fee may be charged even within the warranty period. Ask your dealer for repairs. Do not continue using the monitor when failure or abnormality is found.
  • Page 17 The monitor must be grounded. Failure to do so could cause electric shock. When using a 2P plug, ground the monitor before plugging into a wall outlet. To remove the grounding cable, unplug the monitor first. Follow the instructions below in handling the power plug. •...
  • Page 18 Do not place the monitor on its back or use in a place with little ventilation. Heat could build up and damage the cabinet and/or the inner parts. It could result in shortening of life, overheat, and/or fire. Rest your eyes for 10 to 15 minutes per hour. Failure to do so could cause eyestrain.
  • Page 19 Do not set maximum luminance or closer to it when using the monitor in a dim room below 100 lx. It could cause eyestrain. We recommend the factory default. Setting it too low could makes it hard to see the image. Do not press the LCD luminance sensor or subject it to impact.

  • Page 20: Features

    Realized the power saving by the LED backlight. ● Luminance Uniformity correction feature CL-S300 has Uniformity correction function to provide uniformity of color/luminance. Corrects luminance unevenness or color unevenness, which arising from the LCD panel. This function enables monitors to be used in pairs without peculiarity among any monitors.

  • Page 21: Names And Functions Of Parts

    Names and functions of parts ① Human sensor When leaving your seat, the status of the monitor automatically switches into “Stand-by” due to “Human Sensor”. ② Operation button Displaying Menu on OSD or configuration can be available by these four buttons. ③...
  • Page 22 ⑪ DOWN: USB downstream ports (x2). A USB device with a maximum current consumption of 500 mA per port can be connected to each port. Multiple CL-S300 monitors, connected in a daisy chain, can be calibrated in succession by connecting the supplied USB cable between here and the next monitor’s UP.

  • Page 23: Reference

    Reference Power save function The monitor enters into power save mode after idling for a certain period of time to reduce power consumption. Refer to the workstation instruction manual on how to set it. Digital input This monitor supports digital signal. It is normal for noise to occur during startup, shutdown, and/or at switching resolutions.

  • Page 24: Cleaning The Monitor

    Cleaning the monitor How to care for the cabinet and screen ● When cleaning the monitor, remove the Power cord from the monitor and the wall outlet for your safety. ● Wipe off dust on the cabinet with a soft cloth, and use a cloth lightly moistened with a mild detergent, ethanol or isopropyl alcohol to remove grease.

  • Page 25: Connector Pin Assignment

    Connector pin assignment DVI 24-pin (female) connector for DVI signals Pin # Signal Pin # Signal TMDS Data 2- TMDS Data 3+ TMDS Data 2+ +5V Power TMDS Data 2/4 Shield DVI-D TMDS Data 4- Hot Plug Detect TMDS Data 4+ TMDS Data 0- DDC Clock TMDS Data 0+...

  • Page 26: Technical Specification

    The monitor installed on desk in observation room or diagnostic reading room. Use CL-S300/AR in the room that its ambient light is less than 120.3 lx. Use CL-S300/F in the room that its ambient light is less than 25.1 lx.
  • Page 27 ANSI/AAMI ES60601-1 (2005)+A1 (2012), Conformities CAN/CSA-C22.2 No.60601-1 (2014), FCC-B, ICES-003-B, FDA510(k), CE, UKCA, RCM, VCCI-B, RoHS Specifications are subject to change without notice. External dimensions Portrait (vertical orientation) 166.5 80.5 34.5 361.5 +20° -5° 326.5 196.5 Landscape (horizontal orientation) 434.5 Unit: mm - 27 -...

  • Page 28: After-Sales Service

    After-sales service Warranty Consult your dealer about the warranty. Requesting repair • Read “Troubleshooting” of the installation manual carefully and check if the problem solves. • If the problem remains, stop using the monitor, unplug it, and consult your dealer. Do not try to repair yourself.

  • Page 29: Disposal Of Electrical And Electronic Equipment

    Disposal of electrical and electronic equipment Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable for countries that have adopted separate waste collection systems) Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste. Old electrical and electronic equipment and batteries should be recycled at a facility capable of handling these items and their waste byproducts.
  • Page 30 This page is intentionally left blank. - 30 -...
  • Page 31 CL-S300 Operation Manual November 2023 Edition PZZ11-2505D Notes for the Operation Manual • No part of this manual, whether partly or wholly, may be reproduced or copied without authorization. • The content of this manual is subject to change without notice.
  • Page 32 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa 221-0022, JAPAN Printed in Japan © 2017 JVCKENWOOD Corporation B5A-2234-04 231109...
