Assembly Instruction
• Slide on the top handrail until it clips into place (fig. 1)
• There are holes at the top and bottom of the side
handrails, place the handrail over the outside of the
main frame top ensuring all the holes are aligned
(fig. 2)
• Insert a bolt through the hole in the handrail and
tighten with a screwdriver through the ladder main
frame. Add a washer and nut (fig. 3)
• Tighten using the 10mm spanner and screwdriver
(fig. 4), ensuring there is no movement
• Repeat the above ensuring that both handrails are
secured at the top and the bottom.
Fig. 3
Issue 1 March 2024
Please note: protective rubber caps are attached to protect the
product in transit, these must be removed before assembly.
Fig. 4
