INSTALLATION MANUAL
AIR CONDITIONER (SPLIT TYPE)
Indoor unit
RAS-B10, 13, 18S4KVDG-E
Outdoor unit
RAS-10, 13, 18S4AVPG-E
Scan QR CODE to access installation and owner's manual on website.
https://www.toshiba-carrier.co.th/manuals/default.aspx
Manual are available in EN/FR/DE/IT/ES/PL/PT/NL/GR/CZ/CR/HU/
RO/BG/EE/LV/SK/SI/SV/NO/FI/DA/LT/RU.
R32
INVERTER
ENGLISH
1134050106A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toshiba RAS-B10S4KVDG-E
Summary of Contents for Toshiba RAS-B10S4KVDG-E
- Page 1 INVERTER INSTALLATION MANUAL ENGLISH AIR CONDITIONER (SPLIT TYPE) Scan QR CODE to access installation and owner’s manual on website. https://www.toshiba-carrier.co.th/manuals/default.aspx Manual are available in EN/FR/DE/IT/ES/PL/PT/NL/GR/CZ/CR/HU/ RO/BG/EE/LV/SK/SI/SV/NO/FI/DA/LT/RU. Indoor unit RAS-B10, 13, 18S4KVDG-E Outdoor unit RAS-10, 13, 18S4AVPG-E 1134050106A...
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS FOR SAFETY ............................1 ACCESSORY AND INSTALLATION PARTS ........................5 INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS...................6 Optional Installation Parts ...............................6 INDOOR UNIT ..................................7 Installation Place ................................7 Cutting a Hole and Mounting Installation Plate .......................7 Piping and Drain Hose Installation ..........................8 Indoor Unit Fixing .................................10 Drainage ..................................11 OUTDOOR UNIT ................................11... -
Page 3: Precautions For Safety
PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is fi lled with R32. operating the unit. Warning indications on the air conditioner unit CAUTION CAUTION BURST HAZARD BURST HAZARD Open the service valves Open the service valves before the operation, before the operation, otherwise there might be the burst. - Page 4 DANGER FOR USE BY QUALIFIED PERSONS ONLY. TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK. CONNECT THE CONNECTING CABLE CORRECTLY. IF THE CONNECTING CABLE IS CONNECTED WRONGLY, ELECTRIC PARTS MAY BE DAMAGED.
- Page 5 Do not use any refrigerant different from the one specifi ed for complement or replacement. Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may result in a failure or explosion of the product or an injury to your body.
- Page 6 CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock. Do not store it in a wet basement or expose to rain or water. • After unpacking the unit, examine it carefully for possible damage. •...
-
Page 7: Accessory And Installation Parts
ACCESSORY AND INSTALLATION PARTS ACCESSORY AND INSTALLATION PARTS Indoor Unit Part name Part name Installation plate × 1 Wireless remote controller × 1 Battery × 2 Remote controller holder × 1 Ultra pure lter × 2 Mounting screw × 8 Flat head wood screw ×... -
Page 8: Installation Diagram Of Indoor And Outdoor Units
INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS For the rear left and bottom left piping Wall Hook Mounting screw Hook Installation plate Cut out a piece of SPACER from indoor unit packaging box, roll it and insert between the indoor unit and wall to tilt the indoor unit for better operation. -
Page 9: Indoor Unit
INDOOR UNIT INDOOR UNIT Directly mounting indoor unit to the wall Installation Place preparation • A place which provides the spaces around the indoor unit as shown in the • In the case of block, brick, concrete or similar type wall, determining the diagram. -
Page 10: Piping And Drain Hose Installation
1. Cut Front panel slit When the installation plate is directly mounted • Cut out the slit on the bottom left or bottom right side of the Front panel on the wall for the bottom left or bottom right connection with a coping saw. 2. - Page 11 How to remove the drain hose How to x the drain cap • Removed xing screw of LED set then pull out it from the main body. • Insert hexagonal wrench (dia. 4 mm) in a center head. • Removed 2 screws to x drain pan then secure remove the drain pan from the main body.
-
Page 12: Indoor Unit Fixing
How to remove the air inlet grille CAUTION 1. Be careful open the air inlet grille until arm touch the stopper of the front panel. • Bind the auxiliary pipes (two), power supply and connecting cable with 2. Insert a screwdriver deeply into the space between arm of the air inlet facing tape tightly. -
Page 13: Drainage
2. Put water in the drain pan and make sure that the water is drained out of Drainage doors. 3. When connecting extension drain hose, insulate the connecting part of extension drain hose with shield pipe. 1. Run the drain hose sloped downwards. Shield pipe NOTE •... -
Page 14: Draining The Water
Draining the Water Refrigerant Piping Connection • Holes are provided on the base plate of the outdoor unit to ensure that the Flaring defrost water produced during heating operations is drained o e ciently. If a centralized drain is required when installing the unit on a balcony or 1. -
Page 15: Evacuating
Packed valve handling precautions Evacuating • Open the valve stem all the way out, but do not try to open it beyond the stopper. After the piping has been connected to the indoor unit, you can perform the air purge together at once. Pipe size of Packed Valve Size of Hexagon wrench AIR PURGE... -
Page 16: Electrical Works
ELECTRICAL WORKS ELECTRICAL WORKS Model RAS-B10S4KVDG-E RAS-B13S4KVDG-E RAS-B18S4KVDG-E Power source 50 Hz, 220 – 240 V Single phase Maximum running current 8.50 A 9.95 A 12.00 A Circuit breaker rating 15 A 15 A 20 A Power supply cable H07RN-F or 60245 IEC66... -
Page 17: In Case Of Indoor Unit Connect With 1:1 Outdoor Unit
In Case of Indoor Unit Connect With 1:1 Outdoor Unit The power supply can be selected to connect to indoor unit or outdoor unit. Choose proper way and connect the power supply and connecting cable by follow the instruction as following. Power Supply Input at Indoor Unit Terminal Block (Recommend) Indoor Unit Outdoor Unit... -
Page 18: Power Supply Input Wiring Diagram For 1:1 Outdoor Unit
Power supply input Wiring Diagram for 1:1 Outdoor Unit Power supply input at Indoor Terminal Block (Recommend) Indoor Terminal Block Power supply input Outdoor Terminal Block Power supply input at Outdoor Terminal Block (Optional) Indoor Terminal Block Outdoor Terminal Block Power supply input CAUTION 1. -
Page 19: In Case Of Indoor Unit Connect With Inverter Multi System (Ims)
In Case of Indoor Unit Connect With Inverter Multi System (IMS) Power Supply Input at Outdoor Unit Terminal Block Indoor Unit Outdoor Unit Stripping length of the Connecting cable Connecting cable connecting cable connect to Earth line Terminal block (L N 1 2 3) 50 mm 10 mm Earth line... -
Page 20: Others
OTHERS OTHERS Gas Leak Test Decorative wood • The air inlet grille (wooden grille) of this product is made from real wood, grain patterns, color tone will vary, making each piece of wood have its own unique which it is natural characteristics of wood. Check places for the indoor unit. -
Page 21: Test Operation
Test Operation CAUTION • Wood may expand and shrink with di erences in temperature and To switch the TEST RUN (COOL) mode, press [RESET] button for humidity. 10 seconds. (The beeper will make a short beep.) • Keep products at least 2 meter away from a direct heat source (heaters, radiators, replaces etc.). -
Page 23: Installation Check List
INSTALLATION CHECK LIST Model name After finishing installation work, please check items below and hand this sheet to user to keep it in a safe place together with Owner and Installation Manuals Check date Checked by Note : Please put a mark " "...
