  • Page 1 CLASSIC USER MANUAL Tap. Zoom. Rotate with official interactive instructions on the BILT app.

  • Page 2: Table Of Contents

    WARNINGS AND SAFETY INFORMATION PROPER USAGE FCC INFORMATION ASSEMBLY MOVING THE STEPR CONSOLE ONBOARDING PROCESS GROUNDING METHODS EXPLODED DRAWING PARTS LIST...

  • Page 3: Warnings And Safety Information

    Do not use the STEPR if it has a damaged cord or plug, if it isn't functioning correctly, if it has been dropped or damaged, or if it has fallen into water. In such cases, send an email to support@getstepr.com...
  • Page 4 Children under the age of 13 should be kept away from the STEPR. Do not carry the STEPR by its power cord or use the cord as a handle. SAVE THESE INSTRUCTIONS The specifications of this product may vary slightly from the illustrations and are subject to change without notice.
  • Page 5 Do not use this product if it has a damaged cord or plug, if it isn't functioning properly, if it has been damaged, or if it has been submerged in water. In case of an emergency, immediately press the 'emergency stop button' to stop the STEPR’s operation. Caution: Carefully read...
  • Page 6 Before beginning any exercise program, consult with your physician or healthcare professional. Ensure that all bolts are securely fastened. Never place the STEPR in a damp or wet area, as this could lead to malfunctions. We are not responsible for any issues or injuries resulting from the aforementioned causes.
  • Page 7 ATTENTION The STEPR is suitable for use by children aged 14 years and older, as well as individuals with reduced physical, sensory, or mental capabilities, or those lacking experience and knowledge, provided they are under supervision or have been instructed on how to use the STEPR safely and understand the associated risks.
  • Page 8 At no time should more than one person be on the STEPR while it is in operation Do not use the STEPR under a blanket or pillow. Excessive heat can build up and lead to the risk of fire, electric shock, or injury.

  • Page 9: Proper Usage

    PROPER USAGE As shown in the figure below, the user enters the step area of the STEPR from the direction of the arrow, walks up the steps, and clicks the start button to begin using the STEPR. As shown in the figure...
  • Page 10 T-type wrench to tighten rear gear screw clockwise, demonstrated in Figure 1. As shown in Figure 2, once the gap between the chain and the tube is adjusted to 35mm, you can resume using the STEPR. FIGURE 1 FIGURE 2...
  • Page 11 Pressing any of the EMERGENCY STOP BUTTONS will bring the step surfaces to a complete stop Stand directly in front of the STEPR. Grasp the handlebars and step onto the STEPR until you are within comfortable reach of the console, emergency stop button and in-reach handlebar controls.

  • Page 12: Fcc Information

    Reorient or relocate the receiving antenna Increase the separation between the STEPR and receiver. Connect the STEPR into an outlet on a circuit different from that to which the receiver is connected. Consult the retailer or STEPR customer service...
  • Page 13 assembly & installation Easy to follow with voice, text & interactive 3D images DRAG TO ROTATE • Faster than paper or video Audio, text & • image prompts TAP FOR DETAILS Rotate & zoom • 3D images 360° • Replay steps instantly PINCH TO ZOOM •...

  • Page 14: Assembly

    The floor area of this STEPR is 45.66in×28.3in (116×72cm) Product Net Weigth: 282.19lbs (128 kgs) Note: At least 2 persons are required to assemble the STEPR STEP 1 Open the package, remove the following part — the main frame (1) — from the box, and place it...
  • Page 15 STEP 2 Pass the Switch upper wire 2 (123) through the right Decorative cover (49R) to connect with the Switch lower wire 2 (124); Cover the Decorative cover (49L / R) to the Upright tube (2L / R), then lock the Upright tube (2L/R) to the Main frame (1) with six M10*20 Hex socket screws (74) and six φ10*1.2 Lock washers (102).
  • Page 16 STEP 3 Connect the Console lower extension wire (119) of the console with the Console lower wire (120) of the console. Attach the Lower console mast (5) to Main frame (1) with four M10*30 Hex socket screws (73) and four φ10 Flat washers (105).
  • Page 17 STEP 4 Lock the Console (132) to Upper Console mast (4) with four Cross screw M5*15 (81) Insert the Key board extension wire (128), Console upper extension wire (118), Emergency switch lower wire 1 (122), into the corresponding port of Socket board (12) (As shown in figure A,B).
  • Page 18 STEP 5 Hold the Console (132) and Upper Mast set carefully, connect the Console upper extension wire (118) to the Console lower extension wire (119) . Attach the Console mast (4) to the Lower Console mast (5) with four M10*20 Hex socket screws (74) and four Lock washer Φ10*1.2 (102).
  • Page 19 STEP 6 Pass the Key Board Lower Wire (129a) on left Handrail (3L) through the open D and out of hole C on right Handrail (3R), then insert the left Handrail (3L) into the right Handrail (3R). WARNING: (Please be careful not to clip the wires when putting the tube together).
  • Page 20 Align the hole of G and Upright tube left/right(2L/R) position, then press the G of the Handrails left/ right (3L/R) down Upright tube, Attach Handrails(3L/R) and Upright tube (2L/R) with six Hex socket screw M10*20 (74) and six Lock washer Φ10*1.2 (102).
  • Page 21 STEP 8 Lock all the sixteen M10*20 Hex socket screws (74) and the four M10*30 Hex socket screws (73) that are not locked tightly in the previous assembly steps. Clip the snap joint at H of Decorative cover (49L/R) into Protective cover (44L/R), and then press the snap joint at K of Decorative cover (49L/R) to Protective cover (44L/R).
  • Page 22 STEP 9 Put the Exterior Decorative Cover (41L/41R) onto the outside of Handrail (3L/R) and Upright Tube (2L/R) joint, lock with two cross tapping screws (89). Put the Interior Decorative Cover (42L/42R) from the other side and lock them together with two ST4*16 Cross tapping screws (89) respectively.
  • Page 23 STEP 10 Lock the Bottle/Phone Holder (40) onto the Lower Console mast (5) with two Hex socket cap screw M6*25 (79). Put the Console mast decorative cover (55) apart with hands and then cover it into the Lower Console mast (5).

  • Page 24: Moving The Stepr

    MOVING THE STEPR Screw the two transport handles (131) into the main frame (1) when moving the STEPR. After completing the movement, unscrew the transport handles (131) and store them for future use. WARNING: This equipment is heavy. Exercise caution and seek additional assistance if needed when moving it.

  • Page 25: Console Onboarding Process

    CONSOLE ONBOARDING PROCESS...
  • Page 27 5 seconds. HEIGHT: Display motion height. The forward count ranges from 0 to 999999 meters, while the reverse count decreases from the set value to zero. When the countdown reaches 0, the STEPR slows down smoothly stops running, displaying "End".
  • Page 28 'End.' After a full stop of 5 seconds, it enters standby mode FLOORS: The STEPR displays the current floor value, with a display range of 0 to 999,999. SPM: The STEPR displays the steps per minute in operating mode.
  • Page 29 STEPR. Press this button during operation to temporarily pause the STEPR from running. STOP: During the movement process, this button can be used to halt the operation of the STEPR and reset it to zero.
  • Page 30 CONSOLE ONBOARDING PROCESS "UP" and "DOWN": In standby mode, this button is used to adjust the set value. After startup, it is utilized to adjust the speed, with an adjustment increment of 1 each time. When continuously held down for more than 0.5 seconds, it automatically increases or decreases continuously.
  • Page 31 CONSOLE ONBOARDING PROCESS After starting, use the DOWN and UP buttons to adjust the STEPR’s speed as needed. OPERATION DURING THE STEP 1 MOVEMENT PROCESS Pressing the 'UP' button will increase the running speed of the STEPR Console Pressing the 'DOWN' button will decrease the running speed of the STEPR.
  • Page 32 CONSOLE ONBOARDING PROCESS non-operating mode, pressing 'Manual/Program/Time/Height/Calories/Steps/F loor' button can swiftly switch modes. After switching modes (excluding manual mode), relevant parameter values can be adjusted using the '+/-' button. After selecting a mode setting, choose one of the settings and then press the start button to initiate the operation after a 3-second countdown.
  • Page 33 10 and 999,990. After selecting one of the five countdown modes, press the start button. The STEPR will begin running after a 3-second delay. You can change the current running gear through the control...
  • Page 34 'Bi-Bi-Bi' three times as a prompt. The STEPR will gradually slow down to a stop and display 'End'. After a complete stop, it will enter standby mode STEP 1 after 5 seconds.
  • Page 35 CONSOLE ONBOARDING PROCESS COMPETITIVE MODE STEP 1 In standby mode, press the 'Competition Mode' button to enter the competition mode. There are a total of 5 competition parameter options (floor, steps, calories, height, time). After selecting them, corresponding window parameter on the electronic display will start flashing.
  • Page 36 "Safety Stop Button Activated - Twist Emergency Stop Button to Unlock", accompanied by a "BB" alarm sound from the buzzer. In this state, the STEPR is unable to perform any other actions except for shutting down. To resume normal operation, simply turn the emergency...
  • Page 37 CONSOLE ONBOARDING PROCESS SHUT DOWN STEP 1 You can safely turn off the STEPR at any time by switching off the power, and this action will not cause any damage to the STEPR. MATTERS NEED ATTENTION STEP 1 The STEPR is equipped with a power-saving feature. If no...
  • Page 38 CONSOLE ONBOARDING PROCESS MEANINGS OF ERROR MESSAGE CODES STEP 1...

  • Page 39: Grounding Methods

    If you are uncertain about whether the STEPR is properly grounded, consult a qualified electrician or serviceman. Do not alter the plug provided with the STEPR. If it does not fit the outlet, have a suitable outlet installed by a qualified electrician.

  • Page 40: Exploded Drawing

    EXPLODED DRAWING...

  • Page 41: Parts List

    PARTS LIST...
  • Page 42 PARTS LIST...
  • Page 43 PARTS LIST...
  • Page 44 © STEPR 2024, | STEPR, INC. All rights reserved. getstepr.com...
