STEPR PRO+ User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRO+
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO+ and is the answer not in the manual?

Questions and answers

Related Manuals for STEPR PRO+

Summary of Contents for STEPR PRO+

  • Page 1 PRO+ USER MANUAL Tap. Zoom. Rotate with official interactive instructions on the BILT app.

  • Page 2: Table Of Contents

    WARNINGS AND SAFETY INFORMATION PROPER USAGE FCC INFORMATION ASSEMBLY MOVING THE STEPR CLASS SCREEN GROUNDING METHODS EXPLODED DRAWING PARTS LIST...

  • Page 3: Warnings And Safety Information

    Do not use attachments not recommended by the manufacturer. Never operate the STEPR if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the STEPR to a service center for examination and repair.
  • Page 4 STEPR by a person responsible for their safety. Keep children under the age of 13 away from the STEPR. Do not carry the STEPR by supply cord or use cord as a handle. SAVE THESE INSTRUCTIONS The specifications of the STEPR may vary slightly from the...
  • Page 5 STEPR, the assembly instructions must be reviewed and corrective actions should be taken. Never operate the STEPR if it has a damaged cord or plug, if it is not working properly, if it has been damaged, or immersed in water.
  • Page 6 Before starting any exercise program, consult with your physician or health professional. Check all the bolts locked. Never put the STEPR in the wetness area, or it will cause troubles. We take no responsibility for any troubles or hurts due to above reasons.
  • Page 7 ： That injuries to health may result from incorrect or excessive training. The STEPR can be used by children aged from 14 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been...
  • Page 8 Do not jump on the STEPR. At no time should more than one person be on the STEPR while in operation. The STEPR should not be used by persons weighing more than specified on this manual. Failure to comply will void the warranty.
  • Page 9 To disconnect, turn all controls to the off position, then remove plug from outlet. Do not use the STEPR in any location that is not temperature controlled, such as but not limited to garages, porches, pool rooms, bathrooms, car ports or outdoors.
  • Page 10 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. If you want to dismount the STEPR, you must stop the STEPR completely. Indication that the free area shall be not less than 0,6 m greater than the training area in the directions from which the STEPR is accessed.

  • Page 11: Proper Usage

    As shown in the figure below, after the user finishes exercising, click the stop button. After the stair trainer stops smoothly, the user exits the step area of the STEPR from the direction of the arrow.
  • Page 12 Figure 1.As shown in Figure 2, when the gap between the chain and the tube is adjusted to 35mm, you can continue to use the STEPR. FIGURE 1 FIGURE 2...
  • Page 13 If the start/stop button is damaged during use, you cannot continue to use the STEPR, and you need to replace the internal electronic parts before you continue to use the STEPR. The surface of stairs are plastic, which is easy to wear and tear.

  • Page 14: Fcc Information

    |f the STEPR does cause harmful interference to radio or television reception,which can be determined by turning the STEPR off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.

  • Page 15: Assembly

    ASSEMBLY STEPS Note: The floor area of this machine is 49.6“ 32.8” (1260x 835mm) Weigth: 380lbs (172kgs) STEP 1 Open the package, take out all parts and place the Main frame (1) on the flat ground.
  • Page 16 STEP 2 Pass the Switch upper wire 2(123) through the right Decorative cover (49R)to connect with the Switch lower wire2 (124); Cover the Decorative cover (49L / R) to the Upright tube (2L / R), then lock the Upright tube (2L/R) to the Main frame (1) with six M10*20 Hex socket screws (74) and six φ10*1.2 Lock washers (102).
  • Page 17 STEP 3 Connect the Console lower extension wire (119 )to the Console lower wire (120). Attach the Console mast 2 (5) to Main frame (1) with four M10*30 Hex socket screws(73) and four φ10 Flat washers(105).(Please don’t tighten them now)
  • Page 18 STEP 4 Lock the Console (132) to Mounting bracket (6) with four M10*20 Hex socket screws (74) and four φ10*1.2 Lock washers (102). Insert the Key board extension wire (128),Console upper extension wire (118), Wireless charging of the upper line (161 ,Switch lower wire (122) and ）...
  • Page 19 STEP 5 Connect the Console upper extension wire (118) to the Console lower extension wire (119) . Attach the Console mast 1 (4) to the Console mast 2 (5) with four M10*20 Hex socket screws (74) and four φ10*1.2 Lock washers (102).(Please don’t tighten them now ).
  • Page 20 STEP 6 Insert Key board lower wire a (129a) go through hole D of right Handrails (3R) and come out of hole C of right Handrails (3R) and slide the left Handrails (3L) and the right Handrails (3R) together.( Please be careful not to clip the wires ).
  • Page 21 Insert the Position G of the Handrails (3L/R) into Upright tube (2L/R), align the holes and then lock the Handrails (3L/R) to Upright tube (2L/R) with six M10*20 Hex socket screws (74) and six φ10*1.2 Lock washers (102).(Please don’t tighten them now) Align the holes of the Handrails (3L/R) to the connection tube of the Console mast (4),and then lock the Handrails (3L/R) to the connection tube of...
  • Page 22 STEP 8 Lock all the sixteen M10*20 Hex socket screws (74) and the four M10*30 Hex socket screws (73) that are not locked tightly in the previous assembly steps. Clip the snap joint at H of Decorative cover (49L/R) into Protective cover (44L/R), and then press the snap joint at K of Decorative cover (49L/R) down to Protective cover (44L/R).
  • Page 23 STEP 9 Connect Wireless charging of the upper line (161) to Wireless charging of the lower line (162) Place the Phone holder (133) to the Handrails (3L/R) and lock the Phone holder (133) to the Handrails (3L/R) with two ST4.0*16 Cross tapping screws (89). (Note:Please avoid board...
  • Page 24 STEP 10 Lock the Exterior decorative cover (41L/R) to Handrails (3L/R) with four ST4.0*16 Cross tapping screws (89). Lock the Interior decorative cover (42L/R) to Upright tube(2L/R) with four ST4.0*16 Cross tapping screws (89).
  • Page 25 STEP 11 Lock the Bottle holder (40) to the Console mast 2 (5) with two M6*25 Hex socket cap screws (79). Put the Console mast decorative cover (55)apart with hands and then cover it into the Console mast 2 (5).

  • Page 26: Moving The Stepr

    (1) , after the completion of moving machine, and screw the Transport handles (138) out and put them away for use next time. WARNING: the STEPR is heavy, use care and additional help if necessary when moving. Failure to follow these instructions could result in injury.

  • Page 29: Grounding Methods

    Check with a qualified electrician or serviceman if you are in doubt as to whether the the STEPR is properly grounded. Do not modify the plug provided with the the STEPR –...

  • Page 30: Exploded Drawing

    EXPLODED DRAWING...

  • Page 31: Parts List

    PARTS LIST...
  • Page 32 PARTS LIST...
  • Page 33 © STEPR 2024, | STEPR, INC. All rights reserved. getstepr.com...
