Summary of Contents for MSI MS-15A1

  • Page 2 MS-15A1 SERVICE GUIDE LAPTOP...

  • Page 3: Table Of Contents

    Content Copyright and Trademarks Notice ................1-6 Revision History ......................1-6 How to Use This Service Guide ...................1-7 Safety Precautions .......................1-7 Other Notice .........................1-8 Conditional Warranty Service ..................1-8 Upgrade and Service ....................1-8 Publicly Available Service Information .................1-9 Data Sanitization ......................1-10 Disassembly and Assembly ............2-1 Product Components and Accessories ................2-2 Product Upgradeability &...
  • Page 4 Speakers ........................2-20 Speakers Disassembly ..................2-20 Speakers Assembly....................2-20 Touchpad Module .......................2-21 Touchpad Module Disassembly ................2-21 Touchpad Module Assembly .................2-21 Keyboard Module (Main Base) ..................2-22 Keyboard Module (Main Base) Disassembly ............2-22 Keyboard Module (Main Base) Assembly .............2-25 LCD Display Module ....................2-27 LCD Bezel Disassembly ..................2-27 LCD Bezel Assembly ....................2-29 LCD Panel Disassembly ..................2-30 LCD Panel Assembly ...................2-33...
  • Page 5 Using MSI Center .................3-1 Introduction ........................3-2 Login and Register .......................3-2 Create an Account....................3-2 Product Registration ....................3-4 Settings ........................3-5 Feature Sets -- Choose Your Features ................3-6 Features -- Use the Features Installed .................3-7 System Diagnosis....................3-8 Performance Analysis ...................3-14 Hardware Diagnosis ....................3-16 Hardware Monitoring ....................3-19...

  • Page 6: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

  • Page 7: How To Use This Service Guide

    Laptop. • Always handle electrostatic sensitive components, parts, and assemblies only at static- free work areas. • If there are any difficulties installing hardware devices, please contact MSI Service Center for further information.

  • Page 8: Other Notice

    • The software and hardware information contained in this guide are for reference only and may vary in accordance with actual system configuration. • No warranty as to accuracy or completeness is expressed or implied. MSI reserves the right to make changes to this document without prior notice.

  • Page 9: Publicly Available Service Information

    Publicly Available Service Information Service Information Section Disassembly instructions including identifying the required Product Components and tools. Accessories Necessary Tools Exploded diagram of parts. Product Components and Accessories List of spare parts including manufacturer-approved spare Product Upgradeability & Reparability parts and how to obtain them. Maintenance procedures or guidance on where to obtain System Diagnosis the procedures.

  • Page 10: Data Sanitization

    Data Sanitization MSI will not assume any responsibility or confidentiality obligation for the security of any data stored on the equipment submitted for recycling. Our customer is advised to back up and remove all data from the computers. In order to wipe out the data from the computers, we recommend using the recovery procedure to clean up the data.

  • Page 11: Disassembly And Assembly

    Disassembly and Assembly...

  • Page 12: Product Components And Accessories

    Disassembly and Assembly MSI provides the below list of components for the system configuration purchased and within 2 years after discontinuation of the product to increase the operational life of that product. Further services can be obtained by contacting MSI Online Customer Service.
  • Page 13 Back Cover Coin Battery Thermal Module Battery Pack Mainboard LCD Bezel Speakers LCD Panel Touchpad Module Front Cover Keyboard Module (Main Base) 14. Power Cord Camera Module External Power Adapter Power Supply SSD Card...

  • Page 14: Product Upgradeability & Reparability

    Hardware features for upgradeable, repairable or replaceable using only commonly available tools and listing of replaceable spare parts by-products can be obtained by contacting MSI Online Customer Service. For replacement, repair, or upgrade methods, please refer to the hyperlinks in the table below.

  • Page 15: Necessary Tools

    • The laptop, the reference figures, and the recommended procedures selected and shown herein may be varied depending on the actual model users purchased. • The peripheral devices or tools contained herein may be varied depending on the actual configuration. Necessary Tools The following tools may be needed while performing the disassembly and assembly procedures on the laptop.

  • Page 16: Screw List

    Disassembly and Assembly Screw List Please refer to the screw list below while proceeding the disassembly and assembly of the laptop. Note: this screw list provided is for reference only, and may be varied from models to models. It is always highly recommended to contact the authorized service center for further assistance.

  • Page 17: Power Cord Disconnection

    • Always use the power adapter and power cord approved by MSI, or a compatible one purchased from MSI. • Place the power cord in a way that people are unlikely to step on it. Do not place anything on top of the power cord.

  • Page 18: Back Cover

    Disassembly and Assembly • Place the laptop on a flat, level and stable surface. • Do not place the laptop in environments subject to mist, smoke, vibration, excessive dust, salty or greasy air, or other corrosive gases and fumes. • Do not perform any maintenance with wet hands.

  • Page 19: Back Cover Disassembly

    Back Cover Disassembly Go Top Remove all the screws that secure the back cover with a cross type screwdriver. Apply force from the upper left corner of the back cover to disengage the left upper and lower hooks and then disengage the right upper and lower hooks. Remove the back cover.

  • Page 20: Battery

    The swollen battery may impact the performance of the laptop and should not be used. Please dispose the swollen battery properly, and contact the authorized MSI service center or local dealer for battery replacement.

  • Page 21: Battery Pack Disassembly

    • It is suggested to use a grounded wrist strap while handling laptop components which are sensitive to ESD. When touching a sensitive component or assembly, ensure that it is properly grounded. • Always follow the instructions to disassemble or assemble the battery, or it may cause damage to the laptop, disaster of fire, or electric shock.

  • Page 22: Battery Pack Assembly

    Disassembly and Assembly Battery Pack Assembly Go Top  Place the battery pack into the battery tray properly.  Reattach all the screws and make sure they are fastened properly.  Connect the battery cable connector. Firmly insert the battery cable connector into the slot, and then press down the connector.

  • Page 23: Coin Battery Disassembly

    WARNING: Do not ingest battery. If the coin / button cell battery is swallowed, it can cause severe internal burns and can lead to death. Keep new and used batteries away from children. Coin Battery Disassembly Go Top  Locate the coin battery and find the battery cable. ...

  • Page 24: Coin Battery Assembly

    Disassembly and Assembly Coin Battery Assembly Go Top  Place the coin battery back to the correct position.  Connect the coin battery cable. 2-14...

  • Page 25: Ssd Card

    SSD Card SSD Card Disassembly Go Top Locate the SSD card.   Loosen the screw with a cross type screwdriver, and remove the SSD card. SSD Card Assembly Go Top To assemble the SSD card, align and insert the SSD card into the slot with 30 ...

  • Page 26: Thermal Module

    Disassembly and Assembly Thermal Module Thermal Module Disassembly Go Top  Disconnect the fan cable connector.  Loosen all the screws that secure the thermal module with a cross type screwdriver.  Remove the thermal module vertically with care. 2-16...

  • Page 27: Thermal Module Assembly

    Thermal Module Assembly Go Top To assemble the thermal module, align and install the thermal module with the correct  orientation.  Secure the thermal module with screws.  Connect the fan cable connector. 2-17...

  • Page 28: Mainboard

    Disassembly and Assembly Mainboard Mainboard Disassembly Go Top   Disconnect the fingerprint cable connector , camera cable connector , LCD cable    connector , speaker cable connector , board-to-board cable connector , and  MAIN (black) and AUX (red) antenna cable joint , and then the touchpad cable connector, keyboard LED cable connector, and keyboard cable connector front left to ...

  • Page 29: Mainboard Assembly

    Mainboard Assembly Go Top   Place the mainboard and sub-board to its position with the correct orientation.   Secure the mainboard and sub-board with all the screws.   Connect the fingerprint cable connector , camera cable connector , LCD cable ...

  • Page 30: Speakers

    Disassembly and Assembly Speakers Speakers Disassembly Go Top   Locate the left and right speakers. Pull out the speakers vertically with care. Gently pull out the speaker cable from the cable management ditch. Go Top Speakers Assembly   To assemble the speakers, insert the left and right speakers vertically with care.

  • Page 31: Touchpad Module

    Touchpad Module Touchpad Module Disassembly Go Top  Loosen the screws that secure the touchpad module with a cross type screwdriver, and then remove the touchpad module. Go Top Touchpad Module Assembly Place the touchpad module back to its position with the correct orientation and then ...

  • Page 32: Keyboard Module (Main Base)

    Disassembly and Assembly Keyboard Module (Main Base) Keyboard Module (Main Base) Disassembly Go Top Turn over the laptop and open the LCD display front cover to check the keyboard   module (main base) and the LCD display. 2-22...
  • Page 33  Loosen screws that secure the metal cover with a cross type screwdriver, and then remove the metal cover.  Loosen screws that secure the middle cover with a cross type screwdriver, and then remove the middle cover.   Locate the left and right hinges.
  • Page 34 Disassembly and Assembly   Slightly lift up the keyboard module (main base) from the LCD display.   Separate the keyboard module (main base) and the LCD display. 2-24...

  • Page 35: Keyboard Module (Main Base) Assembly

    Keyboard Module (Main Base) Assembly Go Top  Leave the LCD display seated on a flat surface. Align the keyboard module (main    base) to the left and right hinges. Secure the both hinges to the laptop with screws on each side. ...
  • Page 36 Disassembly and Assembly  Place the metal cover back to its position with the correct orientation and then reattach the screws to secure the metal cover. 2-26...

  • Page 37: Lcd Display Module

    LCD Display Module LCD Bezel Disassembly Go Top   Follow the direction marks shown below to separate the LCD bezel from the LCD display with a pry tool. 2-27...
  • Page 38 Disassembly and Assembly  Remove the LCD bezel from the LCD display with care. 2-28...

  • Page 39: Lcd Bezel Assembly

    LCD Bezel Assembly Go Top   Align the LCD bezel with the lower left and right edge of the LCD display.  Follow the direction marks to assemble the LCD bezel to the LCD display.   Align the camera hole of the LCD bezel to the camera module , and use fingers to fasten the LCD bezel to the LCD display from the middle to both sides.

  • Page 40: Lcd Panel Disassembly

    Disassembly and Assembly LCD Panel Disassembly Go Top Loosen screws that secure the LCD panel on each side with a cross type  screwdriver.   Use a cross type screwdriver to loosen the screws that secure the left and right ...
  • Page 41  Pull the edge of the stretch remove tape and pull it out slowly and carefully to avoid breakage. 2-31...
  • Page 42 Disassembly and Assembly    Slightly lift up the LCD panel and separate the LCD panel from the front cover of the laptop. 2-32...

  • Page 43: Lcd Panel Assembly

    LCD Panel Assembly Go Top   Align the LCD panel and the front cover of the laptop with correct orientation.  Install the LCD panel back to its position. 2-33...
  • Page 44 Disassembly and Assembly   Align the left and right hinges to LCD display with correct orientation.   and right Use a cross type screwdriver to fasten all screws to secure the left hinges.  Reattach the screws to secure the LCD panel on each side. 2-34...

  • Page 45: Camera Module

    Camera Module Camera Module Disassembly Go Top  Follow the direction marks shown below to tear off the camera cable.  Use a tweezers to gently separate and remove the camera module from the front  cover with care. 2-35...

  • Page 46: Camera Module Assembly

    Disassembly and Assembly Camera Module Assembly Go Top    Follow the direction marks to paste the camera cable onto the front cover the laptop.  Install the camera module with correct orientation and with care. 2-36...

  • Page 47: Front Cover

    Front Cover   This is the front cover’s outer side and its inner side. Front Cover Disassembly Go Top Refer to the previous instructions to remove LCD display module and camera module. Front Cover Assembly Refer to the previous instructions to install camera module and LCD display module. 2-37...

  • Page 48: Ac Power Connection And Power On The Laptop

    (earthed) AC outlet. Do not remove the grounding pin of the power cord, since it is an important safety feature. • Always use the power adapter and power cord approved by MSI, or a compatible one purchased from MSI.

  • Page 49: Troubleshooting

    You may refer to the troubleshooting articles listed below for quick and easy self- examination when running into problems. It is always suggested to contact the authorized MSI service center for advanced assistance, if needed. ▶ How to fix a PC that shows no sign of power? ▶...

  • Page 50: Recycling Procedures

    Disassembly and Assembly Recycling Procedures Front Cover Go Top   This is the front cover’s outer side and its inner side. Remove all sponge tapes or stickers of the front cover. Please recycle the front cover to qualified recyclers. 2-40...

  • Page 51: Back Cover

    Back Cover Go Top   This is the back cover's outer side and its inner side. Remove all sponge tapes or stickers of the back cover. Please recycle the plastic back cover to qualified recyclers. 2-41...

  • Page 52: Keyboard Module (Main Base)

    Disassembly and Assembly Keyboard Module (Main Base) Go Top  Turn over the keyboard module (main base).  Remove the mylar tape.  Remove all the screws on the keyboard.  The removed upper case can be recycled to qualified recyclers. 2-42...

  • Page 53: External Power Adapter Power Supply

    External Power Adapter Power Supply Go Top  Use diagonal pliers to cut the external power supply DC cable    Use heat gun to heat the betweens of upper and lower cases of the power adapter, and then use parallel screwdriver to separate the cases. ...

  • Page 54: Product End-Of-Life Instructions

    Disassembly and Assembly Product End-of-Life Instructions MSI Environmental Information Information on MSI’s Environmental initiatives, policies, programs and goals MSI ESH Policy. can be found at Purpose This information is to provide the guidance to recyclers on the presence of materials and components at the product level, as required by the EU WEEE and amending Directive.

  • Page 55: Product Take-Back Services

    Product Take-Back Services Waste electrical equipment may contain hazardous substances and thus endanger human health & the environment. Proper disposal is therefore required. MSI provides free recycling of EPEAT-registered products to ensure that the product reaches the end of its useful life and that it is recycled responsibly.
  • Page 56 Disassembly and Assembly 2-46...

  • Page 57: Using Msi Center

    Using MSI Center...

  • Page 58: Introduction

    Login and Register Before using MSI Center, it is recommended to create your own account and register your MSI product to get your full benefits from MSI Center at once. To have the complete function of MSI Center, keep the Windows system login with a single administrator account as specific functions require higher system privileges in order to work (e.g.
  • Page 59 Connect a MSI device to your laptop, if any. You can also enter the Login page by clicking on [Sign up/ Log in]. Select [Join MSI Member] to create an account, and then follow the on-screen instructions to apply a personal account and register your MSI product.

  • Page 60: Product Registration

    Once a personal account is created, and logged in the account, you may start to register your products. The laptop you are using will be detected by MSI Center automatically, follow the on- screen instructions to complete the registration. To register MSI multi-media accessories which are connected to the laptop, click [+]...

  • Page 61: Settings

    Settings Before using MSI Center, you may decide the appearance and the language of the user interface according to your personal preferences in Settings page. Move the mose cursor to the [Setting] icon at the upper right corner and click on it.

  • Page 62: Feature Sets -- Choose Your Features

    Using MSI Center Feature Sets -- Choose Your Features Within the latest MSI Center, you are able to choose your own style and features. Simply install or update your favorite features in Feature Sets page. Experience the convenience that MSI Center brings to you! Move the mouse cursor to the [Feature Sets] icon at the upper right corner and click on it.

  • Page 63: Features -- Use The Features Installed

    Features -- Use the Features Installed Activate MSI Center and click on Features. Find the features which are selected and installed in Feature Sets. Now, let’s get familiar to these MSI exclusive features. Here comes the brief introductions to each feature, and you may read it before going any further.

  • Page 64: System Diagnosis

    Battery Master Go to MSI Center [Features > System Diagnostics] and find [Battery Master]. Users may distinguish the battery health status by the colors of the battery icon. Select a suitable Battery modes for different usage.
  • Page 65 Battery Calibration Go to MSI Center [Support > System Diagnostics] and find Battery Calibration. Click on the [Battery Calibration] icon. If you are using the Battery Calibration process for the very first time, at the [Status] field, there will be no information telling the date of last calibration.
  • Page 66 Using MSI Center 3-10...
  • Page 67 3-11...
  • Page 68 Using MSI Center System Checker Go to MSI Center [Features > System Diagnosis]. Users may read the real-time status of the HDD and SSD storage and memory usage. To clean up the disk, move the mouse cursor to [Clean Up Disk] and right click on it to bring the dialog window of [Disk Cleanup for Windows], and then follow the on-screen instructions to clean up the disk.
  • Page 69 SSD status provides the information of SSD model, capacity, temperature, health status. Users may distinguish the SSD health status by the colors of the SSD icon. Click the refresh icon to get the SSD status refreshed when it is needed. Status Performance Level Healthy...

  • Page 70: Performance Analysis

    Performance Analysis provides system performance analysis report of the laptop. With this function, users may be able to learn the basic system performance whenever is needed. Go to MSI Center [Features > Performance Analysis]. Click on [New] to create a new Performance Analysis report. Specify a time period.
  • Page 71 3-15...

  • Page 72: Hardware Diagnosis

    Hardware Diagnosis is capable of doing a quick self-examination for the hardware devices of the laptop. Go to MSI Center [Features > Hardware Diagnosis], and follow the on-screen instructions to continue the self-examination procedures. One-Click Scan: check the status of the battery, LAN, WLAN, Fan module, etc.
  • Page 73 3-17...
  • Page 74 Using MSI Center 3-18...

  • Page 75: Hardware Monitoring

    Hardware Monitoring Monitor provides a real-time status of the CPU Usage and GPU Usage. Activate MSI Center and click on Monitor to browse the page. Click and follow the on-screen instructions to clean up the appointed disk. Click to free up the memory.

  • Page 76: Support

    Live Update Live Update Connect to Internet, and go to MSI Center [Support > Live Update]. Move the mouse cursor to [Scan] icon, and click on it. Live Update is capable to analyze the system automatically and give a list with every latest drivers and utilities available for updating.
  • Page 77 To use this function for the very first time, analyzing the system by Live Update is a must. Connect to internet, go to MSI Center [Support > Live Update], and click [Scan] icon. Go to Micorsoft app now, users will get a list with compatible utilities.

  • Page 78: System Info

    System Info: Read-only system information provided here. Export System Info: Export the current system information data to a .txt file. Content Transfer: Use this function when contacting MSI online customer service agents. Follow the instructions given by the online agent to continue.
  • Page 79 3-23...

  • Page 80: Service

    Go to MSI Center [Support > Service]. Users can search for related information by searching for the keywords in the search toolbar. Move the mose cursor to click on [More] to get more information at MSI official website. 3-24...

  • Page 81: Msi Recovery

    Be aware of backing up the important data to other storage devices before using this recovery function is a must. Go to WinPE to Use MSI Recovery Go to MSI Center [Support > MSI Recovery]. Click [Start] and then [Yes] to enter MSI Recovery main page under WinPE. 3-25...
  • Page 82 Create a MSI Rescue USB disk To use MSI Recovery function for the very first time, it is a must to make a MSI Rescue USB disk first. With MSI Rescue USB disk, users may be able to fix or restore the system back to the factory default settings while the system encountering problems booting to Windows.
  • Page 83 Click [Next] to continue. Select the path of the inserted USB flash disk and then click [Select] to continue. Be noted that making a MSI Rescue USB disk, the USB flash disk will be formated, all data will lost. Follow the on-screen instructions to complete creating the MSI Rescue USB disk.
  • Page 84 Using MSI Center 3-28...
  • Page 85 Create a Customize Image Backup To make a Customize Image Backup, always be sure to have the MSI Rescue USB disk inserted to the laptop. Insert another USB flash disk or connect a hard disk with available capacity required. Select [Customize Image Backup] to continue.
  • Page 86 Backup which you made in advance. Go to MSI Recovery main page, and select [Restore]. To perform the Restore function, always make sure that the MSI Rescue USB disk is inserted to the laptop. Connect the storage drive, where you can find the Customize Image Backup *.wim file, to your laptop.
  • Page 87 3-31...
  • Page 88 Using MSI Center 3-32...
  • Page 89 3-33...
