Brief
As a new generation of medium-sized PLC products independently developed by VEICHI, it
supports EtherCAT bus control and dual-port network switching functions. It can realize
encapsulation and reuse through FB/FC functions and multi-level network communication through
RS485, Ethernet, CAN and EtherCAT interfaces, with up to 16 expansion modules and expansion
functions like RS485, RS232, DI, DO, AD, DA, RTC clock and T-flash cards through expansion
boards.
This manual introduces the installation and wiring of products, including product information,
mechanical installation, electrical installation, etc.
Qualification
Certificate
CE
Version Change Log
Date
11/21/2023
Manual Acquisition
This manual is not shipped with products. If you need it, please log on to the official website
of VEICHI Electric (www.veichi.cn), "Services and Support-Data Download", search for keywords
and download the PDF file.
Warranty Description
If the product breaks down or is damaged under normal use, VEICHI will provide warranty
service within the stated period (please refer to the order form for the warranty period of the product).
Please note that we will take maintenance fees if it is not within the period any more. While
maintenance fees will be charged for product damages caused by the following conditions even
when it is during the warranty period:
Failure to operate this product according this manual.
Product damages caused by fire, flood and abnormal voltage.
Product damages caused by abnormal applications.
Product damages caused by exceeding the specified scope of use of products.
Secondary product damages caused by force majeure (natural disasters, earthquakes and
Preface
Directive
EMC
2014/30/EU
LVD
2014/35/EU
2011/65/EU
RoHS
amended by (EU)
Version
V1.0
EN 61010-2-201
EN IEC 63000
2015/863
Content
First version
Standard
EN 61131-2
EN 61010-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VH600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Veichi VH600

  • Page 1 PDF file. Warranty Description If the product breaks down or is damaged under normal use, VEICHI will provide warranty service within the stated period (please refer to the order form for the warranty period of the product).
  • Page 2 ⚫ VEICHI Electric will not bear any legal liability for personal safety accidents and property losses caused when users fail to observe the contents of this manual. Safety Level Failure to observe the precautions will cause deaths and serious personal injuries.
  • Page 3 the product, or there are missing or damaged parts. ⚫ Please check the packing list carefully. please do not install them if they don’t match the packing list. ⚫ Before unpacking, please check whether the outer packaging of the equipment is in good condition, whether it is damaged, soaked, damp or deformed.
  • Page 4 shock. ⚫ When installing the product in a closed environment (such as cabinet or case), please use a cooling device (such as fan or air conditioner), otherwise it may cause product overheat or fire. ⚫ Do not refit this product. ⚫...
  • Page 5 motor will run in reverse. ⚫ The cables used in wiring must meet the requirements in diameter and shielding, and the shielding layer of cables needs be grounded at one end. ⚫ Confirm that all cables are wired correctly and no screws, gaskets or bare cables are left inside the product after wiring, otherwise it may cause electric shock or product damages.
  • Page 6 Maintenance ⚫ It is forbidden to carry out equipment installation, wiring, maintenance, inspection or component replacement by non-professional personals. ⚫ It is forbidden to maintain the equipment when power is on, otherwise it may cause electric shock. ⚫ After cutting off the power of all equipment, please wait for at least the time specified on the warning label on the product before performing equipment maintenance and other operations.
  • Page 7 ⚫ Please process the equipment and products according to relevant national regulations and standards, otherwise it may cause casualties or property loss. ⚫ Scrapped equipment and products should be treated and recycled according to industrial waste treatment standards to avoid environmental pollution.
  • Page 8: Product Information

    1 Product Information 1.1 Model and Nameplate Empty: Main T: Transistor P:PNP output/input 600 series main Input Output module VEICHI series output N:NPN output/input module (8 here) (8 here) E:Expansion N: No output D:DI only module 1.2 Component Type Mark...
  • Page 9 OFF: Input or output is invalid ON: Power supply is Normal power normal Green supply OFF: Power supply is abnormal ON: User program is Normal running Green operation OFF: User program is stopped OFF: No serious errors Operation error Flash: A serious error has occurred Operation ON: Communication...
  • Page 10: Product Specification

    signal - Power ground Ground Signal ground 24V+ Power + Power 24V - Power - 8 channels of input/ 8 See chapter 3.1 for IO terminal channels of details output/ IO power supply ON: Communication For EtherCAT is successful EtherCAT EtherCAT Yellow communication...
  • Page 11: Power Specification

    125 max. slaves support disabling and scanning Two Ethernet ports share a network board and an IP address, supports network switching EtherNet/IP master/slave: when act as a master, it supports 16 slaves; when act as a slave, it supports 16 masters Ethernet Modb μ...
  • Page 12: Input Specification

    Bus output power rated current 2A (max at 5V) 24V input power protection Short circuit protection and reverse connection protection Module hot swap 1.3.3 Input Specification Item Specification Input type Digital input Input channel Input method Leakage Input voltage level 24V DC ±...
  • Page 13 ON(controlled by software) External inductive load protection When there is inductive load, users need to install freewheel diodes Note: When the output frequency is greater than or equal to 100KHz, an external 1KΩ resistor should be connected to 24V terminal. -12-...
  • Page 14: Mechanical Installation

    2 Mechanical Installation 2.1 Installation Environmental Requirements When installing the PLC to the lead rail, please take account of operability, maintainability and the surrounding environmental resistance. Item Specification Use environment Non-corrosive and combustible gas, slight conductive dust (dust) Altitude ≤ 2000m (80kPa) Pollution class Anti-interference Power cord 2kV (IEC 61000-4-4)
  • Page 15 minimum clearance must be reserved around this product, as shown in the following figure. Upward air 35 mm 30 mm 30 mm Downward air 35 mm If there are heat sources(heater, transformer, resistor, etc.) around this product, at least 100mm clearance should be reserved between them.
  • Page 16: Installation Precaution

    上 下 BOTTOM ——————————————————————————————————————— There are two requirements for vertical installation: ⚫ The PLC must be installed below all IO modules. ⚫ Please use trunking to hold the cables during wiring to avoid snap sliding on the lower lead rail. If this product is not to be fixed on the DIN lead rail, misoperation may occur. 2.3 Installation Precaution ⚫...
  • Page 17: Installation Dimension

    2.4 Installation Dimension Installation dimension information is shown in the following figure, and the unit is millimeter (mm). 100.6 2.5 Installation Method The master shall be installed tio the DIN lead rail, which shall conform to IEC 60715 standard (35mm wide and 1mm thick). The dimensional information is shown in the following figure, and the unit is millimeter (mm).
  • Page 18 导 轨 锁 扣 Snap DIN导 轨 DIN rail 2. Confirm that the DIN rail snaps are in place, and the locked and unlocked state are shown in the following figure. Snap Snap 导 轨 锁 扣 导 轨 锁 扣 5.5mm 9.6mm Locked...
  • Page 19 模 块 间 连 接 导 轨 Lead rail between modules Install a DIN snap on both the master and modules. When installing the rail snap, hook the bottom of it to the bottom of the rail and then rotate the snap so that the top end of it is hooked to the top end of the rail, and finally tighten the screws to lock the rail snap as shown in the following figure.
  • Page 20 螺 丝 刀 Screw DIN导 轨 锁扣 DIN snap -19-...
  • Page 21: Electrical Installation

    3 Electrical Installation 3.1 Terminal Arrangement Left signal Left terminal Right terminal Right signal X0 input X1 input X2 input X3 input X4 input X5 input X6 input X7 input ——————————————————————————————————————— The total extension distance of high-speed IO interface expansion cable should be shorter than When wiring, avoid bundling with power lines (high voltage, high current) and other cables that transmit strong interference signals.
  • Page 22 3.2 Input Terminal Wiring Internal equivalent circuit 内部地 外部地 External GND Internal GND 3.3 Output terminal wiring Internal equivalent circuit 内部地 外部地 Internal GND External GND Description When there is inductive load, it is necessary to connect freewheeling diodes externally, and the diodes can be 1N4001 or similar ones.
  • Page 23: Cable Selection

    4 Communication 4.1 Networking Ether CAT RS485 Ether net SD710-CA AC10 SD710-E SD700 series 4.2 Cable Selection In the following table, the lug diameter is for reference only, which can be calculated reasonably according to actual use and adjusted separately. Diameter GB/mm2 ANSI/AWG...
  • Page 24: Ethercat Communication

    Terminal definition Signal Left Right Signal RS485 differential RS485 differential 485 + 485 - pair positive pair negative CAN differential pair CAN differential pair CAN-H CAN-L positive negative Communication ground DC 24V power DC 24V power +24V supply positive supply negative ⚫...
  • Page 25 distance Slave qty Up to 127 Frame length 44 bytes ~ 1498 bytes Process data Single Ethernet frame with up to 1486 bytes ◼ Wiring PLC can realize EtherCAT bus communication through CN3 port, and the requirements for communication network cable are as follows: Communication network cable requirements Signal lead distribution Signal...
  • Page 26: Can Communication

    When fixing cables, do not bundle them with AC power lines and high-voltage cables to avoid interference among the communication signals. 4.7 Terminal Resistor Terminal resistor dip switch for CAN and RS485 is located on the left side of VH600 controller, -25-...
  • Page 27 and the left expansion cover plate needs to be opened. Its position is shown in the following figure. Dip switch See the following table for the corresponding relationship between terminal resistor and dip switch. Position Resistance Comment 120Ω RS485 terminal resistor 120Ω...
  • Page 28: Operation And Maintenance

    5 Operation and Maintenance 5.1 Start/Stop After the program is written into PLC, please follow the following steps to switch on and off. When the PLC is in STOP state and the program is written, please 1. Set the system to RUN. 2.
  • Page 29 Appendix: Expansion Selection Type Model Specification VH600-RS485 1-channel RS485 VH600-4DI 4-channel DI Left VH600-4DO (TN) 4-channel leakage DO expansion VH600-2AD1DA-I 2-channel AI, 1-channel AO, current mode. module VH600-2AD1DA-V 2-channel AI, 1-channel AO, voltage mode. VH600-RTC Real-time clock VH-1600END 16-channel DI module...
