Single-Display Sit-Stand
Wall-Mount Workstation
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY
(17.6 lb. / 8 kg). SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Eaton по адресу: Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website
verfügbar: Tripplite.Eaton.com support
PRODUCT
REGISTRATION
Register your product today for a
chance to win an ISOBAR
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Model: WWSS1332W
surge
®
1
Advertisement
Related Manuals for Eaton TRIPP LITE WWSS1332W
Summary of Contents for Eaton TRIPP LITE WWSS1332W
- Page 1 (17.6 lb. / 8 kg). SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support Русскоязычная версия настоящего руководства представлена на...
-
Page 2: Component Checklist
Component Checklist IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are missing or faulty, visit Tripplite.Eaton.com/support for service. Bracket Arm Support Mast Keyboard Shelf Decorative Cover M8 x 25 M4 x 12... - Page 3 Assembly Mount Bracket Arm to wall. 60mm 60mm (2.4") 2.4" ø 10mm (ø 3 /8") Mark the exact location of mounting holes Drill pilot holes √ Screw the wall mount onto the wall 1/4” (6 mm) WARNING • When mounting on a wood stud wall, make sure that mounting screws are anchored into the center of the studs.
- Page 4 Assembly Install Decorative Covers. Remove VESA Plate from Support Mast. Attach Keyboard Shelf to Support Mast.
- Page 5 Assembly Attach Keyboard Shelf and Support Mast Assembly to Bracket Arm. 3/16” (5 mm) Attach VESA plate to back of display. Note: Firmly secure the VESA plate to the display using the appropriate screws, washers and spacers (if necessary). Do not over-tighten screws.
- Page 6 Assembly Slide VESA plate and Display onto the Support Mast. Using an assistant or mechanical lifting equipment, lift the display with attached VESA plate. Slide the VESA plate over the Support Mast bracket. Reattach the top knob to secure the VESA mount (removed in step 3).
- Page 7 Assembly Adjust to the desired location or tilt. +15° -15° To correct the tilting angle, tighten the adjustment screws using the provided Hex Keys (or tighten the knob). Keyboard Shelf adjusts at multiple angles. 0° 10° 10 °...
-
Page 8: Warranty And Product Registration
PRODUCT REGISTRATION Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to win a FREE Eaton Tripp Lite series product!* *No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
