1. GETTING TO KNOW YOUR CLEANER

MAIN COMPONENTS:
A. Mode Button
B. Handheld Unit
C. On/Off Power Button
D. Turbo Button
E. LED Display
F. Wall Mount Socket
G. Battery Charger Inlet
H. Battery LED Indicator
I. Battery Releasing Button
J. Battery Pack
K. Handheld Release Button
L. Main Body
M. Folding Button
N. Dust Bin Left Sliding Button
O. Dust Bin Right Sliding Button
P. Upper Dust Bin
Q. Bottom Dust Bin
R. Dust Bin Bottom Cover
S. Corner Genie™
T. Product Folding Handle
U. Brush Bar
V. Nozzle Window
W. Nozzle
X. Nozzle Led Lights
Y. Nozzle Release Pedal
Z. Nozzle Window Release Latch
AA. Nozzle Status Indicator Light
AB. Brush Bar Releasing Latch
