  • Page 1 IP3667 IP Door Access Control Quick Installation Guide...
  • Page 2: Table Of Contents

    IP3667 1. Package Contents................ 4 2. Physical Specifications............... 4 3. Installation..................8 4. Searching Door Phone..............11 5. SIP Door Access Control Setting..........12 6. Door Unlocking Setting............... 13...
  • Page 3: Package Contents

    IP3667 Package Contents Front Panel Infrared light Speaker Camera Photoresistor Numeric keypad (password and dialing) Lock Status Call Status RFID area Ring Status DSS Key Network and registration MICs Status Interface Description Physical Specifications Camera Get the video Device size 223 x 130 x 74mm Infrared light &...
  • Page 4 IP3667 Button Definition Port Definition Button Description After removing the back panel of device, there is one Press the Button to request to open the door terminal block connector for power and lock control DSS Key or call. connection as shown in the picture below Numeric Input password to open the door or call.
  • Page 5 IP3667 Network Connector JP1 Jumper There are two power supply modes for electric-lock as shown in the picture below. (The default is “Passive Mode:”). Passive Mode: When the electric-lock starting current is more than 12V/650mA, you must use the external drive mode, the electric lock interface for short circuit output control.
  • Page 6 IP3667 Wiring instructions NO: Normally Open Contact; COM: Common Contact; NC: Normally Close Contact Driving Mode Electric-lock Mode Connections Jumper No electricity Electrify Active Passive when open when open...
  • Page 7 IP3667...
  • Page 8: Installation

    Step 2: Drilling Rain Shade Back Panel Front Panel Main Part of Intercom Figure 1: Three Major Parts of IP3667 Figure 2: Wall Mounting Step 1: Installation preparation B. Tools that may be required: A. Check the following Hex wrench...
  • Page 9 IP3667 Power and Electric-lock Connector A. With L-shaped screwdriver, unpack the front panel Step 4: Back panel fixing and cabling according to diagram (3) (Counter-clockwise) and (4) Figure 6 Figure 7 Figure 3 Figure 4 B. With Phillips screwdriver, unpack the rain shade and A.
  • Page 10: Searching Door Phone

    IP3667 D. Test whether there is electricity by doing the following: Press the # button for 3 seconds to get Note: Make sure the screws have been tightened properly the IP address of intercom by voice. Input access for better waterproof effect.
  • Page 11 Note: It is strongly encouraged to assign either a static or reserved DHCP IP address to the IP3667, as well as any desk phones that will receive IP calls from the IP3667 or access its video feed. Otherwise the IP address may change and the function keys will no longer work as configured.
  • Page 12 IP3667 5. IP Door Phone Setting Step 1: Log into the door phone Step 3: Setting DSS key Input IP address (e.g. http://192.168.1.149) into Set the DSS key as shown below for a quick start. address bar of PC’s web browser. The default user Click “Apply”...
  • Page 13: Door Unlocking Setting

    IP3667 Step 4: Door Phone Setting 6. Door Unlocking Setting Local 1) Local Password Step 1: Go to EGS Setting Features Set Local Password (The default is “6789”). Step 2: Use the device’s Numeric Keyboard to input password and “#” key, and then the door will be...
  • Page 14 IP3667 2) Private Access Code Step 1: Go to EGS Access Access Rule Access Code. Step 2: Use the device’s Numeric Keyboard to input password and “#” key, and then the door will be unlocked. RFID Card Step 1: Go to EGS Access...
