Application Programming Interface
Product Model
SW-740-TX
Document Revision
V1.2
March 2021
Document Date

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-740-TX and is the answer not in the manual?

Questions and answers

Related Manuals for Wyrestorm SW-740-TX

Summary of Contents for Wyrestorm SW-740-TX

  • Page 1 Application Programming Interface Product Model SW-740-TX Document Revision V1.2 March 2021 Document Date...

  • Page 2: Table Of Contents

    System Settings ........................13 Contacting Technical Support ....................15 Document Revision History ..................... 15 Publication Disclaimer ........................16 Copyright © 2021 WyreStorm Technologies | WyreStorm.com 2 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 210308...

  • Page 3: Overview

    2.1 LAN Connection The SW-740-TX is set to acquire an IP address from a DHCP server by default. Connect the switcher to your network and either check your DHCP server client list or perform a network scan to find the IP address.

  • Page 4: Command Overview

    Please note, most 3rd-party control software will either append these characters automatically or an option to specify them will be present. It is important that the last delimiter character is LF and not CR. Copyright © 2021 WyreStorm Technologies | WyreStorm.com 4 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 5: Controlling Matrix Switching

    AUTOSW_FN <PRM> <PRM> = on | off Example Command: SET AUTOSW_FN on Example Response: AUTOSW_FN on Copyright © 2021 WyreStorm Technologies | WyreStorm.com 5 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 6: Controlling Display Power Via Cec

    The switcher can automatically send a CEC Power On command through its output when an input signal is detected. CEC Power Off commands can also automatically be sent after “X” amount of time when a signal detection is lost. See “Set CEC Auto Power Off Delay” section for details. Copyright © 2021 WyreStorm Technologies | WyreStorm.com 6 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
  • Page 7 GET AUTOCEC_D Example Response: AUTOCEC_D 5 <PRM> is in minutes. A value of 5 is equal to a 5-minute delay. Copyright © 2021 WyreStorm Technologies | WyreStorm.com 7 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 8: Serial Passthrough Over Hdbt

    (must be hex format). Although this command appears to be hexadecimal format, it should be sent as an ASCII command to the switcher. Therefore, still requires <CR> <LF> delimiters in ASCII format. Copyright © 2021 WyreStorm Technologies | WyreStorm.com 8 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 9: Adjusting Video Settings

    SCALE auto When set to manual scaling mode, an additional scaling command will need to be sent. See the section “Set Output Scaling Resolution”. Copyright © 2021 WyreStorm Technologies | WyreStorm.com 9 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
  • Page 10 <PRM> = Output Resolution Value (See above for numeric RES <PRM> resolution values) Example Command: GET RES Example Response: RES 5 Copyright © 2021 WyreStorm Technologies | WyreStorm.com 10 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 11: Adjusting Audio Settings

    Command structure: GET AUDOUT_MUTE Response Syntax: AUDOUT_MUTE <PRM> Example Command: GET AUDOUT_MUTE Example Response: AUDOUT_MUTE on Copyright © 2021 WyreStorm Technologies | WyreStorm.com 11 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 12: Pir Settings

    Response Syntax: SENSOR <PRM> <PRM> = on | off Example Command: GET SENSOR Example Response: SENSOR on Copyright © 2021 WyreStorm Technologies | WyreStorm.com 12 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 13: System Settings

    <INPUT> = VGA, HDMI1, HDMI2, USB-C <PRM> = Have_Signal, No_Signal Example Command: GET SIG_S VGA Example Response: SIG_S Have_Signal Copyright © 2021 WyreStorm Technologies | WyreStorm.com 13 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...
  • Page 14 Reboot Switcher Command: REBOOT No Parameters Response: REBOOT Restore Factory Defaults Command: RESET No Parameters Response: RESET Copyright © 2021 WyreStorm Technologies | WyreStorm.com 14 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 15: Contacting Technical Support

    Changes: Added PIR Sensor commands V1.2 – March 2021 Communication settings for Telnet over TLS Changes: Copyright © 2020 WyreStorm Technologies | WyreStorm.com 15 of 16 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Switcher API | 201001...

  • Page 16: Publication Disclaimer

    WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions.
