- Page 1 BD Pyxis™ ES Refrigerator Tower Operation Manual APRIL 2024 360395 REV E...
- Page 2 Disclaimer This manual is a guide to provide the operator with necessary instructions on the proper use and maintenance of certain BD and Helmer Scientific products. Any failure to follow the instructions as described could result in impaired product function, injury to the operator or others, or void applicable product warranties.
-
Page 3: Table Of Contents
BD Pyxis ™ ES Refrigerator Tower Operation Manual Contents About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Intended Audience . -
Page 4: About This Manual
Intended Audience This manual is for end users of the iMX113 BD Pyxis™ ES Refrigerator Tower. For information on how to use the BD Pyxis MedStation™ ES which provides medication management capabilities to the iMX113 BD Pyxis™ ES Refrigerator Tower, please refer to the Pyxis MedStation™... -
Page 5: Avoiding Injury
BD Pyxis ™ ES Refrigerator Tower Operation Manual Symbols and Labels found on the units The following symbols may be found on the refrigerator or refrigerator packaging: Caution: Risk of damage to equipment or Earth / ground terminal danger to operator... -
Page 6: General Recommendations
BD Pyxis ™ ES Refrigerator Tower Operation Manual 1 .5 General Recommendations General Use Allow refrigerator to come to room temperature before switching power on. During initial startup, the high temperature alarm may appear while refrigerator reaches operating temperature. -
Page 7: Installation
BD Pyxis ™ ES Refrigerator Tower Operation Manual Installation 2 .1 Location Requirements Keep all ventilation openings in the enclosure or, in the structure for building-in, clear of obstruction. ♦ Has a grounded outlet meeting the electrical requirements listed on the product specification label. -
Page 8: Ac Power Cord
BD Pyxis ™ ES Refrigerator Tower Operation Manual 2 .3 AC Power Cord NOTICE Use manufacturer supplied power cord only. Install power cord If packaged with modular cord, insert plug securely into the refrigerator power receptacle prior to connecting to grounded outlet. -
Page 9: Operating The I .C
BD Pyxis ™ ES Refrigerator Tower Operation Manual Operating the i .C Monitoring System 3 .1 Initial Power-up 1. Plug power cord into grounded outlet that meets electrical requirements on the product specification label. 2. Switch AC ON/OFF switch ON. -
Page 10: Temperature Setpoint
BD Pyxis ™ ES Refrigerator Tower Operation Manual Note No password is required to view the Home screen. Home screen 3 .2 Temperature Setpoint Notes • The default settings password is 1234. • The default setpoint is 40°F. Change Temperature Setpoint 1. - Page 11 BD Pyxis ™ ES Refrigerator Tower Operation Manual Alarm Description Inverter Communication Failure Communication is lost between the i.C control board and the VCC inverter Low Battery Voltage Backup battery voltage is low Backup Battery Failure Backup battery voltage is deficient...
-
Page 12: Module Assembly Operation
BD Pyxis ™ ES Refrigerator Tower Operation Manual Module Assembly Operation Module Assembly 4 .1 Bin Operation Bins remain locked at all times unless unlocked by the Pyxis MedStation™ ES system. Bins will be illuminated and unlocked when specified via the Pyxis MedStation™... -
Page 13: Operation During Power Failure
Operation Manual Operation During Power Failure The iMX113 BD Pyxis ™ ES Refrigerator Tower is equipped with a backup battery system. The backup battery system provides electrical power to the i.C temperature monitoring system, alarm system, and magnetic door lock. Individual bins cannot be unlocked while the refrigerator is running on backup battery system power. -
Page 14: Operating The Refrigerator On An Emergency Power System
The BD Pyxis™ ES Refrigerator Tower may be accessed in two ways during an AC power failure. While the refrigerator is operating on backup battery power, the door may be unlocked using the BD Pyxis MedStation or by switching the door lock key switch OFF. - Page 15 BD Pyxis ™ ES Refrigerator Tower Operation Manual Figure 4 Figure 5 9. Replace the manual release cover by aligning the tabs on the cover with the slots in the bracket and slide downward to engage (Figure 4) 10. Push the locks in to lock the cover and close the refrigerator door.
-
Page 16: Product Specifications
BD Pyxis ™ ES Refrigerator Tower Operation Manual Product Specifications 6 .1 Operating Standards These units are designed to operate under the following environmental conditions: ♦ Non-residential, indoor use only ♦ Altitude (maximum): 6.56k ft (2000 m) ♦ Ambient temperature range: 59°F to 90°F (15°C to 32°C) ♦... - Page 17 BD Pyxis ™ ES Refrigerator Tower Operation Manual Notes • The maximum weight added per shelf is 6 lbs (3 kg) • The maximum weight added per standard module is 16 lbs (7 kg). • The maximum weight added per deep module is 20 lbs (9 kg).
-
Page 18: Compliance
BD Pyxis ™ ES Refrigerator Tower Operation Manual Compliance 7 .1 Regulatory Compliance This device complies with the requirements of the following directives: 2011/65/EU (Restriction of Hazardous Substances), 2014/30/EU (Electromagnetic Compatibility (EMC) Directive), and 2014/35/EU (Low Voltage Directive). This product is certified to applicable UL and CAN/CSA standards by a NRTL. - Page 19 Helmer Scientific Becton Dickinson and Company 14400 Bergen Boulevard, Noblesville, IN 46060 USA Franklin Lakes, NJ United States | 201.847.6800 | BD.com 360395/E Copyright © 2024 Helmer, Inc.
