IDentification with Radio and Optical 2. About This Guide 2. 1 Overview This document is for the setup and operation of the IDRO900FE RFID Reader System. Before you use this device, you should be familiar with the following : •...
• Software version info. We will respond to e-mail, telephone or fax calls within the time specified in the service contract. If IDRO’s support does not solve the problem, you can return the device for repair service and receive specific instructions.
IDentification with Radio and Optical Getting Started This Chapter provides a brief overview of IDRO900FE RFID Reader hardware and software. IDRO900FE User's Manual...
IDentification with Radio and Optical 3. Getting Started 3. 1 RFID Reader Hardware IDRO900FE RFID Reader is an RFID system that operates in UHF RFID band. (860-960MHz frequency) Supports up to four TX/RX antennas, Serial(RS-232) and Ethernet interfaces, as shown below in Figure 3.1.1.
IDentification with Radio and Optical There are 3-LED status indicators located at the bottom of IDRO900FE RFID Reader, which represent the status of the reader as follows. [ Figure 3.1.2 ] IDRO900FE Status LED [ Table 3.1.1 ] IDRO900FE Status LED...
IDentification with Radio and Optical RFID Reader Installation This chapter describes the mechanical and electrical installation methods of IDRO900FE RFID Reader. IDRO900FE User's Manual...
4. 1 Mechanical Installation 4. 1. 1 Mounting the RFID Reader IDRO900FE Reader has a mounting hole that allows 4 #10(M5) screws to be used. Drill the mounting surface in advance according to the dimension of [Figure 4.1.1]. The Mounting surface shall be capable of supporting up to 1.88lb (580g).
IDentification with Radio and Optical IMPORTANT IDRO900FE antenna port may be susceptible to damage due to static electricity (ESD) or other high voltages. Appropriate electrostatic precautions are required to avoid static incoming when handling or connecting IDRO900FE antennas or communication ports. A Breakdown may occur if the antenna or communication port is exposed to the ESD.
IDentification with Radio and Optical 4. 2. 4 Connecting Digital Inputs/Outputs IDRO900FE has a General Purpose Digital Input/Output port that provides two optically isolated 0Vdc active input signals and two open-collector output signals. Digital input can be used for general purposes or to trigger RFID readers for tag reading.
IDentification with Radio and Optical RFID Reader Components This chapter describes the components provided with IDRO900FE RFID Reader IDRO900FE User's Manual...
IDentification with Radio and Optical 5. RFID Reader Components 5. 1 Components The Components provided with IDRO900FE RFID Reader are shown below in [Table 5.1]. [ Table 5.1] IDRO900FE RFID Reader Components Items Pictures RFID Reader (IDRO900FE) DC 12V/3.0A Adaptor...
Page 19
AC/DC Adapter & Ethernet cable spec provided with the product may vary depending on our circumstances. Option products are not available when you purchase the reader, please contact IDRO sales team if necessary. When using third-party antennas and cables, ensure that the maximum gain of...
IDentification with Radio and Optical RFID Reader Electrical Properties This chapter provides electrical and environmental information for IDRO900FE RFID Reader IDRO900FE User's Manual...
VCC=12V, typical values at 25℃, unless otherwise noted. Table 6-3 : Reader Specifications Parameter Min. Typ. Max. Unit Conditions Supply Current Transmit Power : +30dBm (Active mode) Supply Current (Standby mode) RX input impedance Ω RX sensitivity TX Power Frequency See Appendix A IDRO900FE User's Manual...
RJ-45 Ethernet 10/100 BaseT Indicators Yellow - Link LED Green - Act LED Table 6-4-2 : RS-232 Specifications Parameter Min. Typ. Max. Unit Conditions Baud rate 115.2 921.6 kbaud Data bits Parity None Stop Flow control None IDRO900FE User's Manual...
LAMP : RED BUZZER : BROWN BLACK POWER (전원) [Figure 6.5.2 ] IDRO900FE GPIO Output Connections • Operating method ①. Click Properties on the Reader@Express → Click GPIO and set the Output like below → Apply → Close > OUTPUT LEVEL : Display the output level status before Inventory.
Page 25
Generally intended to control the GPIO output in HOST, used to test whether the reader is functioning normally. (1) GPIO Input Used as a sensor input, and it is used for the application system in which the reader operates when a sensor is detected. IDRO900FE User's Manual...
Page 26
BROWN BLACK BLUE POWER (전원) [Figure 6.5.3 ] IDRO900FE GPIO Input Connections • Operating method ①. Click Properties on the Reader@Express → Click GPIO and set the Input like below → Apply→ Close > If INPUT DETECT is set as above and the DC Level changes to H→L or L→H in GPIO input 1, the reader performs Inventory operation.
Page 27
① Click Properties on the Reader@Express → Click GPIO and set the Input & Output like below → Apply → Close GPIO Input GPIO Output Toff [Figure 6.5.4 ] IDRO900FE GPIO Input/Output Timing 1.2 sec. Time to GPIO Output after detection of GPIO Input Toff 172 ms...
Page 28
③ Reader ON ④ Read the UHF tag in the vehicle. ⑤ Output the RELAY signal with GPIO output. ⑥ Door is open For more detail, Please refer to " Reader Control Protocol specifications - IDRO900FE " IDRO900FE User's Manual...
IDentification with Radio and Optical RFID Reader Mechanical Properties This chapter provides mechanical information for IDRO900FE RFID Reader. IDRO900FE User's Manual...
IDentification with Radio and Optical RFID Reader Packing Dimension This chapter provides packaging information for IDRO900FE RFID Reader. IDRO900FE User's Manual...
IDentification with Radio and Optical Appendix A. RFID Reader Frequency This chapter provides channel and frequency information for IDRO900FE RFID Reader. IDRO900FE User's Manual...
CHINA only IDRO900FE-CN CHINA JAPAN(1W) only IDRO900FE-JP JAPAN(1W) Contact IDRO Co.,Ltd for other countries not in above table 8-1. These tables show each countries frequency channel Allocation status of IDRO KOREA CHANNEL No. Frequency (MHz) 917.3 917.9 918.5 919.1...
Appendix B. CAUTIONS This chapter provides information about user Cautions for IDRO900FE RFID Reader. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. IDRO900FE User's Manual...
Page 44
