Fixed Type 4-port RFID Reader IDRO900F User's Manual February 17th, 2020 Ver. 20021701 UHF RFID Reader Visible RFID Reader & Tag Visible Light Communication System DateCopyright(c)2011 by IDRO All right reserved #219, 17, Daehak 4-ro, Yeongtong-gu, Suwon-si, Gyeongi-do, Korea IDRO Co.,Ltd www.idro.co.kr...
IDentification with Radio and Optical Revision History IDRO Co,.Ltd. IDRO900F Reader document history IDRO900F User's Manual...
Page 5
IDentification with Radio and Optical 1. Revision History Document Description Revision Date Number 2020021701 Initial release February 2020 IDRO900F User's Manual...
IDentification with Radio and Optical 2. About This Guide 2. 1 Overview This document is for the setup and operation of the IDRO900F RFID Reader System. Before you use this device, you should be familiar with the following : •...
• Software version info. We will respond to e-mail, telephone or fax calls within the time specified in the service contract. If IDRO’s support does not solve the problem, you can return the device for repair service and receive specific instructions.
IDentification with Radio and Optical Getting Started This Chapter provides a brief overview of IDRO900F RFID Reader hardware and software. IDRO900F User's Manual...
3. Getting Started 3. 1 RFID Reader Hardware IDRO900F RFID Reader is an RFID system that operates in UHF RFID band. (860-960MHz frequency) Supports up to four TX/RX antennas, serial(RS232) and Ethernet interfaces, as shown below in Figure 3.1.1. Also, Two GPIO Inputs & Outputs are available.
IDentification with Radio and Optical There are 3 LED status indicators located at the bottom of IDRO900F RFID Reader, which represent the status of the reader as follows. [ Figure 3.1.2 ] IDRO900F Status LED [ Table 3.1.1 ] IDRO900F Status LED...
IDentification with Radio and Optical [ Figure 3.2.1 ] IDRO900F Reader@Express RFID Reader Installation This chapter describes the mechanical and electrical installation methods of IDRO900F RFID Reader. IDRO900F User's Manual...
4. 1 Mechanical Installation 4. 1. 1 Mounting the RFID Reader IDRO900F Reader has a mounting hole that allows 4 #10(M5) screws to be used. Drill the mounting surface in advance according to the dimension of [Figure 4.1.1]. The Mounting surface shall be capable of supporting up to 1.88lb (580g).
[Figure 4.2.2 ] IDRO900F Electrical Connections (RS232) IMPORTANT IDRO900F antenna port may be susceptible to damage due to static electricity(ESD) or other high voltages. Appropriate electrostatic precautions are required to avoid static incoming when handling or connecting IDRO900F antennas or communication ports. A Breakdown may occur if the antenna or communication port is exposed to the ESD.
4. 2. 4 Connecting Digital Inputs/Outputs IDRO900F has a General Purpose Digital Input/Output port that provides two optically isolated 0Vdc active input signals and two open-collector output signals. Digital input can be used for general purposes or to trigger RFID readers for tag reading.
IDentification with Radio and Optical RFID Reader Components This chapter describes the components provided with IDRO900F RFID Reader IDRO900F User's Manual...
IDentification with Radio and Optical 5. RFID Reader Components 5. 1 Components The Components provided with IDRO900F RFID Reader are shown below in [Table 5.1]. [ Table 5.1 ] IDRO900F RFID Reader Components Items Pictures RFID Reader (IDRO900F) DC 12V/3.33A Adaptor...
Page 19
The actual product may differ from the picture of the above components. AC/DC Adapter & Ethernet cable spec provided with the product may vary depending on our circumstances. Option products are not available when you purchase the reader, please contact IDRO sales team if necessary. IDRO900F User's Manual...
IDentification with Radio and Optical RFID Reader Electrical Specifications This chapter provides electrical and environmental information for IDRO900F RFID Reader IDRO900F User's Manual...
Table 6-3 : Reader Specifications Parameter Min. Typ. Max. Unit Conditions Supply Current Transmit Power : +30dBm (Active mode) Supply Current (Standby mode) RX input impedance Ω RX sensitivity TX Power Frequency See Appendix A Channel bandwidth IDRO900F User's Manual...
RJ-45 Ethernet 10/100 BaseT Indicators Yellow - Link LED Green - Act LED Table 6-4-2 : RS232 Specifications Parameter Min. Typ. Max. Unit Conditions Baud rate 115.2 921.6 kbaud Data bits Parity None Stop Flow control None IDRO900F User's Manual...
Output circuits Input Circuits Reader Device Device Reader INPUT OUTPUT A접점 A접점 Output Diagram Input Diagram 6. 5. 2 Connection Diagram and Operating method (1) GPIO Output Usually used for buzzer or lamp actions when tag reading. IDRO900F User's Manual...
Page 24
LAMP : RED BUZZER : BROWN BLACK 5~24VDC [Figure 6.5.2 ] IDRO900F GPIO Output Connections • Operating method ①. Click Properties on the Reader@Express → Click GPIO and set the Output like below → Apply → Close > OUTPUT LEVEL : Display the output level status before Inventory.
Page 25
(1) GPIO Intput Used as a sensor input, and it is used for the application system in which the reader operates when a sensor is detected. • Connection Diagram Use Power from external device (sensor) for power(V+,V-).. IDRO900F User's Manual...
Page 26
BROWN BLACK BLUE POWER (전원) [Figure 6.5.3 ] IDRO900F GPIO Input Connections • Operating method ①. Clinck Properties on the Reader@Express → Click GPIO and set the Input like below → Apply → Close > If INPUT DETECT is set as above and the DC Level changes to H→L or L→H in GPIO input 1, the reader performs Inventory operation.
Page 27
IDentification with Radio and Optical GPIO Input GPIO Output Toff [Figure 6.5.4 ] IDRO900F GPIO Input/Output Timing Time to GPIO Output after detection of GPIO Input 1.2 sec. Toff Time to release GPIO Output after GPIO Input is released 172 ms...
Page 28
③ Reader ON ④ Read the UHF tag in the vehicle. ⑤ Output the RELAY signal with GPIO output. ⑥ Door is open. For more detail, Please refer to " Reader Control Protocol specifications - IDRO900F ". IDRO900F User's Manual...
IDentification with Radio and Optical RFID Reader Mechanical Specifications This chapter provides mechanical information for IDRO900F RFID Reader. IDRO900F User's Manual...
IDentification with Radio and Optical RFID Reader Packing Dimension This chapter provides packaging information for IDRO900F RFID Reader. IDRO900F User's Manual...
IDentification with Radio and Optical Appendix A. RFID Reader Frequency This chapter provides channel and frequency information for IDRO900F RFID Reader. IDRO900F User's Manual...
CHINA only IDRO900F-CN CHINA JAPAN(1W) only IDRO900F-JP JAPAN(1W) Contact IDRO Co.,Ltd for other countries not in above table 8-1. These tables show each countries frequency channel Allocation status of IDRO KOREA CHANNEL No. Frequency (MHz) 917.3 917.9 918.5 919.1...
IDentification with Radio and Optical Appendix B. Cautions This chapter provides information about user Cautions for IDRO900F RFID Reader. IDRO900F User's Manual...
This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment must be installed and operated with at least 20cm and more between the radiator and person’s body (excluding extremities: hands, wrists, feet and ankles). IDRO900F User's Manual...
Page 45
IDentification with Radio and Optical UHF RFID Reader Visible RFID Reader & Tag Visible Light Communication System DateCopyright(c)2011 by IDRO All right reserved #219 17, Daehak 4-ro, Yeongtong-gu, Suwon-si, Gyeongi-do, Korea IDRO Co.,Ltd www.idro.co.kr IDRO900F User's Manual...
