  • Page 1 N3-HV Series User Manual N3-HV-5.0 N3-HV-6.0 N3-HV-8.0 N3-HV-10.0-A N3-HV-10.0...

  • Page 4: Table Of Contents

    N3-HV Series User Manual Content 1. About this manual..............................4 1.1 Applicability ..............................4 1.2 Target group ............................... 4 1.3 Symbols used .............................. 4 2. Safety ................................. 4 2.1 General Safety ............................. 4 2.2 Important safety instructions ........................5 2.3 Explanation of symbols ..........................6 3.
  • Page 5 N3-HV Series User Manual 9. Decommissioning ............................. 48 9.1 Dismantling .............................. 48 9.2 Packing ..............................48 9.3 Storage ..............................49 9.4 Maintenance ............................49 9.5 Disposal ..............................49 Appendix A ................................50 Appendix B ................................51...
  • Page 6 Copyright Declaration All rights to the content of this manual are owned by RENAC Power Technology Co., Ltd. (hereinafter called as ‘RENAC Power’). Any corporation or individual should not plagiarize, partially or fully copy it, and reproduce or distribute it in any form or means without prior written permission from RENAC Power.

  • Page 7: About This Manual

    N3-HV Series User Manual 1. About this manual 1.1 Applicability Please read the product manual carefully before installation, operation or maintenance of the inverter. This manual contains important safety instructions and installation instructions that must be followed during installation and maintenance of the equipment.

  • Page 8: Important Safety Instructions

    ◆Electrical installation and maintenance must only be carried out by trained and qualified electrician, following all local regulations. NOTICE ◆Do not open inverter lid or change components without RENAC Power's authorization. Unauthorized work will invalidate warranty. ◆Operate inverter as explained in this manual, failure will damage equipment and invalidate warranty.

  • Page 9: Explanation Of Symbols

    Anti-Islanding Effect Islanding is a condition when grid connected PV/ batteries back feed energy into the Grid when Grid is turned off for maintenance work, putting maintenance personal at serious risk. N3-HV series inverters prevent islanding through Active Frequency Drift (AFD).

  • Page 10: Introduction

    3.2 Basic features The N3-HV Series hybrid inverters are designed to work with PV modules, battery, mains supply and electrical loads. Hybrid inverter helps to optimize on-site consumption, charge battery with surplus PV energy and supply energy from battery to meet load.

  • Page 11: Work Modes

    User Manual 3.3 Work modes The N3-HV Series hybrid inverter has the following work modes based on the configuration and connected equipment. Work mode: Self Use This mode is applicable to areas with low subsidies and high electricity prices. Self-consumption of PV renewable energy is the highest priority.
  • Page 12 N3-HV Series User Manual Figure 3-4 Time of Use Mode Work mode: Backup Use It is suitable for the areas with frequent power outages. When the grid is off, the battery is used as backup power to supply load. This mode ensures that the battery will have enough energy to supply loads during a grid outage. PV and battery could support the backup load in the event of a blackout.
  • Page 13 N3-HV Series User Manual Work mode: Feed in Use This mode applies to the area that has high feed-in tariff and export control. This model prioritizes grid feeds with sufficient PV power to maximize the tariff subsidy earned. a. When the PV power is sufficient, the PV generation will supply load first, then feed into grid, and the excess power will charge the battery last.

  • Page 14: Terminals

    N3-HV Series User Manual 3.4 Terminals Figure 3-7 Terminals of the inverter Object Description Object Description Communication port EPS port DC switch Grid port WIFI or 4G or Ethernet port SD port(Reserve) PV connectors USB port Battery connectors 3.5 Dimensions...

  • Page 15: Technical Data

    N3-HV Series User Manual 4. Technical data Model N3-HV-5.0 N3-HV-6.0 N3-HV-8.0 N3-HV-10.0-A N3-HV-10.0 PV Input Data Max. Recommended PV Power (W) 7500 9000 12000 15000 15000 Max. PV Input Voltage (V) 1000 MPPT Voltage Range (V) 160 ~ 950 Rated PV Input voltage (V) Start-up Voltage(V) No.
  • Page 16 N3-HV Series User Manual Model N3-HV-5.0 N3-HV-6.0 N3-HV-8.0 N3-HV-10.0-A N3-HV-10.0 Output THDi (@Rated Output) (%) < 3 Automatic Switch Time (ms) ≤ 20 Peak Apparent Power, Duration (VA, s) 7500, 60 9000, 60 12000, 60 15000, 60 15000, 60 Efficiency Max.

  • Page 17: Installation

    N3-HV Series User Manual 5. Installation 5.1 Unpacking Check the delivery for completeness. Contact your dealer at once if anything is missing. Figure 5-1 Packaging Object Quantity Description N3-HV inverter Mounting Bracket Battery Connectors (1* positive, 1*negative) PV Connectors (2* positive, 2* negative) & PV Pin contact (2* positive, 2* negative)

  • Page 18: Check For Transport Damage

    5.2 Check for transport damage On opening packaging, inspect product for any damage, in case of concern, please contact dealer immediately. 5.3 Installation precaution The N3-HV series inverter is designed for outdoor installation (IP65). Do not install inverter in direct sunlight. ...

  • Page 19: Preparation

    N3-HV Series User Manual 5.5 Preparation Tool Model Function Sprit level To ensure proper install Two-Speed Hammer Drill To drill holes on the wall Hammer Hanging the bracket Impact Wrench Set Hanging the bracket PV-AZM-410 Stripping plier for PV cable...

  • Page 20: Installation Steps

    N3-HV Series User Manual Loading capacity and hardness of the supporting surface, load rating of mounting bracket should be at least four times the  weight of the devices according to IEC62109-1. And supporting characteristics will be impaired by wear, corrosion, material fatigue or ageing.
  • Page 21 N3-HV Series User Manual PV panels N3 HV Series inverter CT direction Meter Grid Battery Critical loads Normal loads Figure 5-6 Note: Diagram below is for grid system without special requirement. PV panels N3 HV Series inverter CT direction Meter...

  • Page 22: Pv Connection

    Communication connection  5.7.1 PV Connection Before connecting PV strings to N3-HV Series hybrid inverter, ensure the following: The total short- circuit current of PV string must not exceed inverter’s maximum DC current.  Make sure that open circuit voltage of PV string is less than 1000V.

  • Page 23: Battery Connection

    To separate the DC- connector, push tool down from the bottom side. d. Separate the connectors by hands. 5.7.2 Battery Connection When building an on-site consumption storage system, high voltage battery is a necessary part. The N3-HV series inverter provides the necessary interfaces to connect the battery. WARNING! Make sure to select cables of the right specification.
  • Page 24 N3-HV Series User Manual Figure 5-12 6. Push the insert into the sleeve (Figure 5-13, C). 7. Tighten the cable gland to 2 Nm (Figure 5-13, D). Use a suitable and calibrated torque wrench of size 15. Use an open-jaw wrench, size 16, to hold the connector in place.

  • Page 25: Ac Output Connection

    Figure 5-16 5.7.3 AC Output Connection N3-HV series inverters have already integrated RCMU (residual current monitoring unit) inside, however if an external RCD is required, a type A RCD with rated residual current of 100mA or higher is recommended. There are two AC terminals and the assembly steps for both are the same, just need to check one for 'Grid' another for 'EPS'. The AC cable and normal load-breaker/external fuse specification for AC side of N3-HV series inverter as below.

  • Page 26: Earth Connection

    N3-HV Series User Manual Figure 5-18 3. Fully insert the conductors to the corresponding terminal and tighten the screws to torque of 0.8 Nm. Pull cables outward to check whether they are firmly installed. Figure 5-19 4. Assemble the housing, the terminal block and cable gland (torque 4–5 Nm). Make sure that the rib of the terminal block and the groove on the housing engage perfectly, with a click.

  • Page 27: Communication Connection

    N3-HV Series User Manual 5.7.5 Communication connection Communication interface The inverter has a serial communication interface besides WIFI or 4G or Ethernet(Optional). Dry contact, extended port, human and machine communication, etc., can be delivered to PC or other monitoring equipment via these interfaces.
  • Page 28 The function of meter port same as pin1 & pin2 of ADD interface. 4.1 Meter wiring diagram for Typical Energy Storage System The N3-HV series inverters can adopt two types of smart meters. One is our standard equipment, and the other is optional. Standard: EASTRON SDM630MCT(40mA) smart meter ...
  • Page 29 N3-HV Series User Manual Optional: EASTRON SDM630-ModbusV2 smart meter  The detailed connection line schematic can be found in Appendix B. SDM630- Modbus V2 Grid Load Grid RS485A N3-HV Battery RS485B Hybrid Inverter ADD interface Solar Panels Figure 5-27 The connect steps are as follows: Connect the meter output "L1, L2, L3, N"...
  • Page 30 4.2 Meter wiring diagram for AC Retrofit System Renac Hybrid inverters can be used in the following situations also. If the site already has a grid tied PV system and want to increase module capacity or provide back-up power. Additional meter between the grid-connected inverters and N3-HV hybrid inverter is required.
  • Page 31 N3-HV Series User Manual Note: 1) It is necessary to have the sequence of phases, CT1 must be connected to Grid phase line L1, CT2 must be connected to Grid phase line L2, CT3 must be connected to Grid phase line L3.

  • Page 32: Relay Connection

    N3-HV Series User Manual Currently, it is mandatory to respond to DRM0, which allows the network manager to remotely decouple the installation from the distribution network. b) In Germany grid code, this logic interface is for controlling and/or limiting the inverter's output power. The grid company uses the Ripple Control Receiver (RCR) to convert the grid dispatching signal and send it as a dry contact signal.

  • Page 33: Ats Connection (Optional)

    N3-HV Series User Manual connect the A1 and A2 of the contactor coil to the Pin7 and Pin8 of the ADD interface of the inverter. Grid +12VDC Load controlled by MCU Contactor Inverter Figure 5-33 Relay function electrical block diagram There are four function modes in total.

  • Page 34: Inverter Configuration

    N3-HV Series User Manual PV Panels Hybrid Inverter Battery EPS Grid Grid Meter Load Load Figure 5-34 ATS connection wiring diagram 5.8 Inverter configuration Start inverter after checking all the following: Check that the device is fixed well on the wall.

  • Page 35: Operation

    N3-HV Series User Manual Set the safety standard as in page 37; Set the system time as in page 36; Set work mode as in page 36; Set the communication address as in page 37; Set the EPS as in page 36; Set WIFI according to the WIFI User manual.

  • Page 36: Lcd Function

    N3-HV Series User Manual 6.2 LCD function Menu structure: =====Solar===== =====Solar===== =====Grid===== =====Grid===== =====Solar===== Vpv1: Ppv1: Ipv1: Vpv2: Ppv2: Ipv2: PV Conf: Multi =====BMS===== =====Grid===== =====Grid===== =====BMS===== =====Charger===== Vdis: Vbat: Vbat: Ichr: Ibat: Ibat: Idis: Pbat: Vchr: =====EPS===== =====EPS===== =====EPS=====...

  • Page 37: Lcd Operation

    N3-HV Series User Manual ====On-Grid==== ====Safety==== ==Volt Protect== ==Volt Protect== >Safety >AS4777 >Vac Upper Slow >Vac 10M Avg Grid 260.0V 255.0V Export Control ==Volt Protect== ==Volt Protect== ==Volt Protect== ====On-Grid==== =====Grid===== >Vac Lower Slow >Vac Upper Fast >Vac Lower Fast Safety >Volt Protect...
  • Page 38 N3-HV Series User Manual 2. Status Press ‘OK’ to enter the menu, check grid , solar, battery, EPS and temperature of the inverter. Press up and down to select, press ‘ESC’ to return to the Menu. ====Meter2==== ====Meter2==== ====Meter1==== ====Meter1====...
  • Page 39 N3-HV Series User Manual charge and discharge current. ‘+’ means in charging; ‘-’ means in discharging. Press up and down button to review the parameter. Press ‘ESC’ to return to Status. =====BMS===== =====BMS===== Vdis: Vbat: Ichr: Ibat: Idis: Vchr: 2.6) EPS EPS will only have data when the inverter is working in EPS mode, it will show the real time data of the EPS output, as voltage , current, power, frequency.
  • Page 40 N3-HV Series User Manual ===Work Mode=== ===Work Mode=== ===Work Mode=== ===Work Mode=== =====Settings===== >Self Use >Time of Use >Backup Use >Feedin Use Language Data&Time >Work Mode 4.4) Communication Address Press up or down button to change address of local and meter. Press ‘OK’ to confirm.
  • Page 41 N3-HV Series User Manual 4.5.1.2) Grid Press up or down button to change the value of grid voltage and grid frequency protect. Press ‘OK’ to confirm. ====On-Grid==== ==Volt Protect== ==Volt Protect== =====Grid===== Safety >Vac Upper Slow >Vac 10M Avg >Volt Protect >Grid...
  • Page 42 N3-HV Series User Manual 4.5.3) Bat Model Press up or down button to set the model of battery. Press ‘OK’ to confirm. ===Advanced*=== ===Bat Model=== ===Bat Model=== ===Bat Model=== On-Grid >RENAC-TURBO >DYNESS-TOWER&HV >YOSHOPO HV >Battery Bat Model 4.5.4) Relay Function Press up or down button to set the relay function.
  • Page 43 N3-HV Series User Manual 4.5.5) Feature Press up or down button to enable or disable Remote Control, DRM0, RCR, Meter Setting, and Bypass Relay. Press ‘OK’ to confirm. ===Advanced*=== ====Feature==== =Remote Control= Battery >Remote Control >Disable Bat Model DRM0 >Feature...
  • Page 44 N3-HV Series User Manual 4.5.8) USB Press up or down button to upgrade DSPM, DSPS, ARMC, BATM or BATS. Press ‘OK’ to confirm. ====Upgrade==== ==DSPM Upgrade== ===Advanced*=== =====USB===== >DSPM Upgrade New Password >Upgrade DSPS Upgrade >No< Reset ARMC Upgrade >USB...

  • Page 45: Parallel System

    7.1 System introduction In order to continuously deliver power to large loads in both on-grid and off-grid situations, the N3-HV series supports parallel connection. Parallel connection is divided into parallel connection in on-grid mode, which supports ten units in parallel, and parallel connection in off-grid mode, which supports five units in parallel.

  • Page 46: Work Modes

    User Manual In off-grid mode, the system should connect a large changeover device to achieve parallel functions in any conditions. We  recommend the EPS parallel box from RENAC. The system connection is schematically shown below: EPS Parallel Box GRID...

  • Page 47: Lcd Setting

    This section contains information and procedures for solving possible problems with the N3-HV series inverters, and provides you with troubleshooting tips to identify and solve most problems that could occur with the N3-HV series inverters. This section will help you narrow down the source of any problems you may encounter. Please read the following troubleshooting steps.
  • Page 48 N3-HV Series User Manual Fault Cause Solutions 1. Disconnect the AC output switch, DC input switch & Inverter over-current, battery over-current, or battery switch, then connect them 5 minutes later. HW Protect Fault PV over-current detected by hardware. 2. Contact the dealer or the after-sales service if the problem persists.
  • Page 49 N3-HV Series User Manual DCI OCP Fault DC component is out of limit in output current. 1. Disconnect the AC output switch, DC input switch & battery switch, then connect them 5 minutes later. DCV OVP Fault DC component is out of limit in output voltage.
  • Page 50 N3-HV Series User Manual persists. 1. Check whether the PE cable of the inverter is connected properly. Ground Conn. Inverter grounding issue. 2. Check whether the L cable and N cable are connected reversely if output of the PV string is grounded.
  • Page 51 Are the display panel and the communications cable are properly connected and undamaged?  Contact Renac Power Customer Service for further assistance. Please be prepared to describe details of your system installation and provide the model and serial number of the unit.
  • Page 52 N3-HV Series User Manual Can be fully closed.  9.3 Storage Store the inverter in dry place where ambient temperatures are always between -20 °C - +60 °C. 9.4 Maintenance Inverters generally do not need any daily or routine maintenance. Heat sink should not be blocked by dust, dirt or any other items.
  • Page 53 N3-HV Series User Manual Appendix A...
  • Page 54 N3-HV Series User Manual Appendix B Installation Center URL User Manual Download URL www.renacpower.com 422-00014-06...
