Sennheiser MKH 60 Product Sheet

MKH 60 P 48
Microphones |
General Description
The MKH 60 is a lightweight short gun microphone. It is versatile and
easy to handle and its superb lateral sound muting makes it an excellent
choice for film and reporting applications. Its high degree of directivity
ensures high sound quality for distance applications.
Cable pictured is an accessory not supplied with the microphone
Features
Extremely low inherent self-noise
High sensitivity
High directivity throughout the whole frequency range
Transformerless and fully floating balanced output
Infra-sonic cut-off filter
Symmetrical transducer technology ensures extremely low distortion
Switchable pre-attenuation, switchable roll-off filter
and switchable treble emphasis
Rugged and weather-proof
Black, anodised light metal body
Delivery includes: 1 MKH 60, 1 MZQ 40 quick release clamp
Recommended Accessories
MZA 14 P 48 U battery power supply unit
MZT 100 table stand
MZT 441 table stand
MZQ 40 quick release clamp
MZS 40 shock mount
MZW 61 foam windshield
MZS 20-1 shock mount
MZW 60-1 basket windshield
MZH 60-1 hairy cover
Possible Combinations
Table stand: MZT 100 or MZT 441, MZQ 40
Suspension/windshield:
MZS 40, MZW 71 or MZS 20-1, MZW 70-1, MZH 70-1
RF Symmetrical Capsule
Condenser Microphone
Cat. No. 002960
Cat. No. 001883
Cat. No. 000799
Cat. No. 035077
Cat. No. 003017
Cat. No. 003194
Cat. No. 003609
Cat. No. 003607
Cat. No. 003224
Technical Data
Pick-up pattern ............................................... super-cardioid/lobar
Frequency response ................................................. 50 – 20,000 Hz
Sensitivity (free field, no load, 1 kHz)............... 40 (12.5) mV/Pa
Nominal impedance ................................................................. 150 Ω
Min. terminating impedance ..................................................... 1 kΩ
Equivalent noise level
A-weighted (DIN IEC 651)..................................................8 (15) dB
CCIR-weighted (CCIR 468-3)........................................... 18 (26) dB
Max. sound pressure level ......................... 125 (134) dB at 1 kHz
Power supply ........................................................phantom 48 ± 4 V
Supply current............................................................................. 2 mA
Dimensions ................................................................ Ø 25 x 280 mm
Weight ......................................................................................... 150 g
Values in parentheses with attenuator switched on (–10 dB)
Effect of switchable roll-off filter
Profile
Super-cardioid/lobar (short gun) interference tube micro-
phone with infrasonic cut-off filter, switchable pre-attenua-
tion, switchable roll-off filter and switchable treble empha-
sis. Frequency response 50 – 20,000 Hz, sensitivity (free
field, no load) 40 (12.5) mV/Pa at 1 kHz, nominal impedance
150 Ω, min. terminating impedance 1 kΩ, equivalent noise
level A-weighted 6 (14) dB, CCIR-weighted 18 (25) dB, max.
SPL 125 (134) dB at 1 kHz, phantom powering 48 ± 4 V, sup-
ply current 2 mA, dimensions Ø 25 x 280 mm, weight 150 g.
Values in parentheses with attenuator switched on (–10 dB).
Cat. No. 003148
Effect of switchable treble emphasis
