Sennheiser MKH 418-S Product Sheet

MKH 418S
Frequency Response
Polar Pattern M Polar Pattern S

MKH 418S Shotgun Microphone

The MKH 418S is a compact MS stereo shotgun microphone utilizing Sennheiser's
exclusive RF condenser microphone technology. The MKH418S incorporates a mid
capsule based on that of the legendary MKH416 which is combined with a newly
designed figure-of-eight side capsule. Its high constant articulation, excellent feedback
rejection and functional versatility make the MKH418S a superb all-round cost-effec -
tive choice for film, television, and multi-media applications.

Features and Benefits

·
Matt black finished brass body is rugged and weather resistant
·
Low inherent self noise insures an optimal signal to noise ratio
·
Rugged MKH capsules are impervious to extreme climate conditions
·
Independant capsule outputs allow variable matrixing capabilities and
multi-functional use.

Technical Data

Acoustic operating principle
Pick-up pattern
Sensitivity at 1K Hz
Frequency response
Max. SPL
Max. output voltage
Equivalent noise level
Output impedance at 1 kHz
Min. load impedance
Power supply P48:
Connector
Dimensions
Weight
Operating temperature range
Humidity range
Delivery includes
Case
User manual
M:pressure gradient/interference tube
S: pressure gradient
M: super cardioid/lobar
S: figure-of-eight
M: 25 mV/Pa (-32 dBV)
S: 10 mV/Pa (-40 dBV)
40 - 20,000 Hz
130 dB SPL (63 Pa)
1.5 V
M: 14 dB-A / 26 dB-CCIR
S: 22 dB-A / 34 dB-CCIR
< 25 ohms
1 kohms
48 ± 4 V / 2 x 2.3 mA
5-pin XLR, male
Ø 19 mm x 280 mm
220 g
-20 to +60 °C
< 95 % relative humidity
Continued
