Summary of Contents for DTS 600 Elite
- Page 1 SLIDING GATE MOTOR INSTALLATION MANUAL DTS 600 Elite DTS SECURITY P.O.BOX 3399 Base plate-mounting instructions EDENVALE 1610 TELEPHONE 086 1000 387 Spartan +2711 392 5540 (H/O) Pretoria +2712 361 5528 Alberton +2711 907 8846 Natal +2731 916 4002 E-EEEE www.dtssecurity.co.za...
- Page 2 BASE PLATE MOUNTING INSTRUCTIONS 1. Assemble base plate by fastening M10x30 Hex set screws into base plate from under the base plate up and tightening into position. 2. Mount base plate with bolts 160mm from the centre of the gate track and centre of base plate a minimum of 250mm away from the gate opening.
-
Page 3: Rack Mounting Instructions
Gearbox mounting instructions 1. Fit gearbox over mounting bolts protruding from base plate. 2. Slide gate fully open and closed, insuring pinion gear has approximately 5mm clearance to gate at all times. 3. Fasten gearbox down firmly to base plate using M10 washers and nuts. How to override the gate motor for manual operation 1. -
Page 4: Power Connections
POWER CONNECTIONS Low voltage Plug in transformer. Connect DTS600, 16volt AC from transformer to 16/24V AC connectors on controller card. DO NOT CONNECT 220V DIRECTLY TO PCB Low voltage (OBT) (25 VA) transformer – 220V at gate. (DTS600 has a 500m/Amp fuse) Connect 220V AC wires to input side of 600/16volt AC transformer (black &... - Page 5 High access power supply unit – 220V at gate. ( DTS600, 120VA has a 2 Amp fuse) Connect 220V AC to LEN (Live/Earth/Neutral) connector on side of power supply unit. Black lead from power supply unit gets connected to – ( neg.) PSU connection on PCB. Red lead from power supply unit gets connected to + ( pos.) PSU connection on PCB.
- Page 6 DO ALL RUNTIME (Calibrating) AND TRANSMITTER PROGRAMMING BEFORE CONNECTING ANY ADDITIONAL INPUTS SUCH AS, –INTERCOM, EXTERNAL RECEIVERS, BEAMS, ETC. Diagram to connect IR Beams to PCB (Beam pins not bridged, the pins are next to the BT/SET button) With the beam pins bridged (Recommended, as the gate will not close should the beams become faulty) the S/Beam N/O must be connected to N/C on the RX (Beams Receiver).
- Page 7 PROGRAMMING 1 – Run Time (Calibrating) Setup (With total power up, AC and DC, on PCB) • Unlock and open the override lever on the gearbox. • Open the gate manually approximately 1metre. Close and lock the override lever on the gearbox. (PCB should beep 1-5 beeps pending on load pot setting).
- Page 8 Master Erase procedure. 5 flashes will confirm Open code and 10 flashes will confirm Full Keelog. On release of both buttons the procedure is completed. (Please note that with Full Keelog only the DTS TX4 with the blue buttons can now be used).
- Page 9 ELECTRONICS FEATURES: Standard mode. Easy motor direction change. Auto close facility. (Infra red beams must be fitted if auto close is activated). Party mode. (Auto close override) Condominium / Free exit loop facility. P.I.R.A.C. (Passive Infra Red Access Control) facility. Slowdown (Ramp down) facility.
- Page 10 6. Slowdown (Dipswitch 6) With dipswitch selected ON, the gate will have a long close and open controlled slow down distance of 800mm and with the dipswitch OFF, the close and open controlled slow down distance will be 400mm. NOTE – (800mm slow down distance is recommended if the limit is continuously being overrun).
- Page 11 Anti-hijack (Only available from Version 1.9 software) When the tamper alarm function is active and the gate receives a valid trigger but is obstructed and cannot move or did not move more than 150mm, the alarm or siren will activate. If the beams are obstructed or blocked when a trigger is received, the gate will open but will then also sound the alarm.
- Page 12 PCB Control card. Beam option jumper for N/O or N/C beams 500 m/Amp AUX. 2 Amp AC 25 Amp self-resettable fuse. self-resettable fuse. Load fuse. NOTE: With the infra red beam option pins not bridged the PCB operates as N/O beams. With the option jumper bridged the PCB operates as N/C beams.
-
Page 13: Troubleshooting
TROUBLESHOOTING SYMPTOMS CAUSES ACTION When pressing the remote Transmitter battery flat. Replace transmitter battery. transmitter or manual push button the gate operator will Transmitter or manual push Check with supplier. button is physically damaged. not respond at all. Transmitter has not been Follow the receiver setup programmed into the receiver instructions. - Page 14 The gate opens but will not The primary supply has failed Check the household main and the unit is running on supply, the transformer or close. battery reserve with the PSU and all related cabling. condominium/loop option selected and it has reached its low battery limit (9.5 Volt).
- Page 15 The unit gives two beeps and The pedestrian (PT) mode on Check equipment /cabling opens partially and stops, the PCB is being triggered. attached to the pedestrian (PT) gives two beeps and then on the PCB input. closes. A transmitter code has been Delete the transmitter and re- programmed incorrectly into program the transmitter into...
-
Page 16: Manufacturer's Warranty
(Remote batteries are consumables and therefore carry NO warranty) • All goods are warranted to be free from faulty components and manufacture. • Faulty goods will be repaired or replaced at the sole discretion of DTS Security Products, free of charge.
