Manual
AL-432-00-921 (KOREA)
EnOcean Sensor "EnoSense
for motion detection, PIR based (Passive infrared)
EnOcean 921.7 MHz / KOREA
Part names: AL-432-00-921
Version 1.01
© DEUTA Controls GmbH
27.03.2024
Technical data might change
Page 1 of 19
PIR Ceiling"
®
Paffrather Str. 140, 51465 Bergisch Gladbach
Hauptstraße 76, 32479 Hille
info@deuta-controls.de;
www.deuta-controls.net
Tel.:+49 2202 285 57- 61
Tel: +49 5734 51466 - 0
Fax:+49 5734 51466 - 28
Advertisement
Table of Contents
Related Manuals for DEUTA Controls EnOcean EnoSense PIR Ceiling
Summary of Contents for DEUTA Controls EnOcean EnoSense PIR Ceiling
- Page 1 ® for motion detection, PIR based (Passive infrared) EnOcean 921.7 MHz / KOREA Part names: AL-432-00-921 Version 1.01 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
- Page 2 Manual by third parties that violate pertinent copyright provisions is prohibited. Reproduction, translation, electronic and photo technical filing/archiving (e.g., photocopying) as well as any amendments require the written consent of DEUTA Controls GmbH, Bergisch Gladbach, Germany. Non-observance will involve the right to assert damage claims.
-
Page 3: Table Of Contents
6.3.3 Operating modes .....................13 Service / changing batteries ..................14 Safety remarks ......................14 Device labels .........................16 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... - Page 4 AL-432-00-921 (KOREA) Product manual Page 4 of 19 Ordering information ....................17 Revision history ......................19 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
-
Page 5: Validity Of This Documentation
The sensor element inside the device must be able to detect a vibration, caused by the occupancy. If this is not possible due to the construction of the table, this sensor type is not the best choice. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille... -
Page 6: Disposal
(EEP: A5-07-01). The following information is currently available for the evaluation: • Motion detected, 0..1 • Super Cap voltage: 8 bit, 0 .. 250 [mV/20] © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille... -
Page 7: External Product Interface
L-432-00-921 EnoSense PIR Ceiling must only be operated in compliance with ® the country-specific provisions regarding operation of radio equipment. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 8: Non-Conduction Mounting Surface
L-432-00-921 EnoSense PIR Ceiling is mounted on a non-conductive ® surface. If it is not, performance may be adversely affected. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 9: Technical Data
5.4 Housing / connection technology Connection technology Housing Plastic, PC, white / black / beige Table 4: Technical data / housing © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 10: Power Supply
Table 7: Technical data / dimensions and weight 5.8 Standards and approvals KC, AL-432-00-921 R-R-dcg-AL-432-00-921 Table 8: Technical data / Approval / Label © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 11: Functional Description In Detail
Simply push the service button for less than 1 second. The L-432-00-921 EnoSense ® PIR Ceiling will immediately send a learn telegram. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 12: Table Of Supported Eep's (Enocean Equipment Profiles)
0: Supply voltage not voltage supported availabilit 1: Supply voltage supported Table 10: EnOcean transmit data © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 13: Motion Detection / Data Transmission Rules
Success: 5x blink 1x very long > 8 s press Load factory defaults Error: - © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 14: Service / Changing Batteries
This product contains CR2032 type batteries. If a battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille... - Page 15 AL-432-00-921 (KOREA) Product manual Page 15 of 19 Keep new and used batteries away from children. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
-
Page 16: Device Labels
9 Device labels The following labels are placed on the bottom side of the L-432-00-921 EnoSense ® Ceiling: © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... - Page 17 96 hours running time without light, EnOcean 921 MHz, KC, KOREA; Dimensions: 114 x 66 x 31 mm, ambient temp. 0..60 ° C © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
- Page 18 Table 8: Technical data / Approval / Label ................10 Table 9: Technical data / EnOcean EEP for TX ..............12 Table 10: EnOcean transmit data ..................12 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille...
- Page 19 Initial release 1.01 Lehzen Pohl 27.3.2024 Added registration number ------------ End of document ----------- © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach 27.03.2024 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
